Summary of Contents for Maxum Sport Decks
-
Page 3: Engine Serial Number
This document discloses subject matter in which Maxum has proprietary rights. The information and design disclosed herein were originated by and are the prop- erty of Maxum. Neither receipt nor possession thereof confers or transfers any right to reproduce, copy, alter or disclose the document or any part thereof, any information contained therein, or to construct boats or any item from it, except by written permission from or written agreement with Maxum. -
Page 4: Table Of Contents
CONTENTS Chapter 1: Welcome Aboard! Chapter 4: Propulsion & Related Systems Dealer Service Engine Warranty Information Bilge Blower System Boating Experience Fuel System Engine & Accessories Guidelines 22 Fuel Fill & Vent 2 Propeller 22 Fuel Filters Engine & Accessories Literature 23 Anti-siphon Valve Qualified Maintenance Fire Suppression System (If Equipped) - Page 5 Chapter 7: Deck Equipment Chapter 11: Electrical System Cleats and Tow Eyes 12-Volt DC System 45 Batteries Ski Tow Ring 45 Battery Switch (If Equipped With One Battery) Ski-Tow Tower (If Equipped) 45 Battery Switch (If Equipped With 37 Attaching the Ski-Tow Rope Two Batteries) 38 Folding Ski-Tow Tower 46 Battery Switch Positions...
- Page 6 Hazard Boxes & Symbols The hazard boxes and symbols shown below are used throughout this Supplement to call attention to potentially dan- gerous situations which could lead to either personal injury or product damage. Read ALL warnings carefully and follow all safety instructions. DANGER! This box alerts you to immediate hazards which WILL cause severe personal injury or death if the warning is ignored.
-
Page 7: Chapter 1: Welcome Aboard
• Maxum offers a Limited Warranty on each new Maxum purchased through an authorized Maxum dealer. • A copy of the Limited Warranty was included in your owner’s packet. • If you did not receive a copy of the Limited Warranty, please contact your Maxum dealer or call 360-435-8957 for a copy. -
Page 8: Engine & Accessories Guidelines
Refer to the engine manual for engine RPM ratings. The engine should reach, but not exceed its full rated RPM when full-throttle is applied. Immediately contact your local Maxum dealer if: • The engine cannot reach its full rated RPM when full-throttle is applied, or;... -
Page 9: Qualified Maintenance
Chapter 1: Welcome Aboard! Qualified Maintenance WARNING! To maintain the integrity and safety of your boat, allow only qualified personnel to perform maintenance on, or in any way modify the: • Steering System • Propulsion System • Engine Control System •... -
Page 10: Safety Standards
Chapter 1: Welcome Aboard! Safety Standards DANGER! FALLING and ROTATING PROPELLER HAZARD! • NEVER allow anyone to ride on parts of the boat not designed for such use. • Sitting on seat backs, lounging on the forward deck, bow riding, gunwale riding or occupying the transom platform while underway is especially hazardous and will cause personal injury or death. -
Page 11: Carbon Monoxide (Co)
Chapter 1: Welcome Aboard! Carbon Monoxide (CO) DANGER! • Carbon monoxide gas (CO) is colorless, odorless, tasteless, and extremely dangerous. • All engines, generators, and fuel burning appliances produce CO as exhaust. • Prolonged exposure to low concentrations or very quick exposure to high concentrations will cause BRAIN DAMAGE or DEATH. -
Page 12: Where And How Co Can Accumulate
Chapter 1: Welcome Aboard! Where and How CO Can Accumulate Stationary Conditions That Increase CO Accumulations Include: A. Using engine, generator, or other fuel burn- B. Mooring too close to another boat that is ing device when boat is moored in a con- using its engine, generator, or other fuel fined space. -
Page 13: Co Checklists
Chapter 1: Welcome Aboard! CO Checklists Trip Checklist Make sure you know where the exhaust outlets are located on your boat. Educate all passengers about the symptoms of CO poisoning and where CO may accumulate. When docked, or rafted with another boat, be aware of exhaust emissions from the other boat. Listen for any change in exhaust sound, which could indicate an exhaust component failure. -
Page 14: Chapter 2: Product Specifications
Chapter 2: Product Specifications 2100SD Overall Bridge Draft Draft Fuel Freshwater Beam Length Clearance (Drive Up) (Drive Down) Capacity Capacity 21' 1" 4' 10" 8' 6" 1' 7" 3' 0" 55 Gallons 10 Gallons 2400SD Overall Bridge Draft Draft Fuel Freshwater Clearance Beam Length... -
Page 15: Chapter 3: Locations
Chapter 3: Locations Exterior Views Hull Views STARBOARD DOCKING LIGHT (IF EQUIPPED) ENTERTAINMENT CENTER DRAIN (2400SD ONLY) BILGE PUMP DECK DRAIN DRAIN (2400SD ONLY) STARBOARD HULLSIDE BOW EYE PORT DOCKING LIGHT (IF EQUIPPED) SINK DRAIN PORTLIGHT (2100SD ONLY) DECK DRAIN (2400SD ONLY) PORT HULLSIDE SINK DRAIN... -
Page 16: 2100Sd Deck View
Chapter 3: Locations 2100SD Deck View PORT NAVIGATION LIGHT BOARDING LADDER STORAGE CLEAT PULL-OUT FAUCET STARBOARD NAVIGATION LIGHT ALL-ROUND LIGHT SOCKET HORN FRESHWATER FILL DECK FITTING FRESHWATER TANK VENT CLEATS SKI TOW RING FUEL FILL DECK FITTING BOARDING LADDER FUEL TANK VENT GRAB HANDLE... -
Page 17: 2400Sd Deck View
Chapter 3: Locations 2400SD Deck View PORT NAVIGATION LIGHT BOARDING LADDER STORAGE CLEAT STARBOARD NAVIGATION LIGHT ALL-ROUND LIGHT SOCKET HORN FRESHWATER FILL DECK FITTING FRESHWATER TANK VENT CLEAT COCKPIT SINK SKI TOW RING FUEL FILL DECK FITTING FUEL TANK VENT GRAB BOARDING HANDLE... -
Page 18: Helm
Chapter 3: Locations Helm NOTE: TYPICAL HELM LAYOUT SHOWN ACTUAL LAYOUT MAY VARY DEPENDING ON ENGINE AND ACCESSORY OPTIONS TACHOMETER SPEEDOMETER OIL PRESSURE GAUGE TEMPERATURE GAUGE FUEL GAUGE VOLTMETER TRIM GAUGE DEPTH SOUNDER (IF EQUIPPED) FRESHWATER HORN SWITCH PUMP SWITCH 12-VOLT OUTLET IGNITION SWITCH BLOWER... -
Page 19: Component Locations
Chapter 3: Locations Component Locations 12-Volt Accessory Outlets: One is located at the helm on the starboard switch panel and one is located next to the shifter. 12-VOLT OUTLETS Battery or Batteries: Located on the port side of the engine room. BATTERIES Battery Switch: Located on the port side... - Page 20 Chapter 3: Locations Blower Switch: Located at the helm on the ignition switch panel. BLOWER SWITCH Depth Sounder Transducer (If Equipped): Located in the engine compartment bilge, forward of the engine. TRANSDUCER Engine Circuit Breaker: Located on the engine. ENGINE CIRCUIT BREAKER...
- Page 21 Chapter 3: Locations Freshwater Fill & Vent Deck Fittings: Located on the starboard side of the deck. FRESHWATER FILL & VENT DECK FITTINGS Freshwater Pump: Located in the cockpit floor hatch. FRESHWATER PUMP Freshwater Pump Switch: Located at the helm on the starboard switch panel.
- Page 22 Chapter 3: Locations Freshwater Tank: Located in the cockpit floor hatch. FRESHWATER TANK Fuel Fill & Vent Deck Fittings: Located on the starboard aft corner of the deck. FUEL FILL & VENT DECK FITTINGS Fuel Tank: Located in the engine room, for- ward of the engine.
- Page 23 Chapter 3: Locations Fuse Block: Located behind the access curtain on the aft wall of the starboard storage compartment ACCESS CURTAIN Navigation Lights: • Red and green lights at the bow. BOW NAVIGATION LIGHTS • White all-round light on the transom. •...
- Page 24 Chapter 3: Locations Portable Toilet Pump-out & Vent Deck Fittings (If Equipped): Located on the port side of the deck. PORTABLE TOILET PUMP-OUT & VENT DECK FITTINGS Showers & Faucets - Bow Shower (If Equipped): Located inside the bow board- ing ladder storage compartment.
- Page 25 Chapter 3: Locations Showers & Faucets - Head Faucet/Shower - 2100SD: Located on the port dash. HEAD FAUCET/ SHOWER Showers & Faucets - Head Faucet/ Shower - 2400SD: Located inside the head compartment. HEAD COMPARTMENT Showers & Faucets - Transom Shower: Located on the starboard side of the cockpit walk-thru.
- Page 26 Chapter 3: Locations Trim Tab Hydraulic Fluid Reservoir (2400SD Only) (If Equipped): Located on the port side of the engine compartment. TRIM TAB HYDRAULIC FLUID RESERVOIR...
-
Page 27: Chapter 4: Propulsion & Related Systems
Chapter 4: Propulsion & Related Systems Engine Read the engine operation and maintenance manuals before starting or doing any maintenance on the engine. Bilge Blower System WARNING! FIRE/EXPLOSION HAZARD • Use of the bilge blower system is NOT A GUARANTEE that explosive fumes have been removed. -
Page 28: Fuel System
Chapter 4: Propulsion & Related Systems Fuel System WARNING! FIRE, EXPLOSION AND OPEN FLAME HAZARD! • It is very important that the fuel system be inspected thoroughly the first time it is filled and at each subsequent filling. • The fueling instructions in the Sport Boat Owner’s Manual and the fuel recommendations in the engine operation manual must be followed. -
Page 29: Anti-Siphon Valve
Chapter 4: Propulsion & Related Systems Anti-siphon Valve NOTICE • If an engine running problem is diagnosed as fuel starvation, check the anti-siphon valve. • If the valve is stuck or clogged, change or replace it while the engine is shut down. •... -
Page 30: Quick Oil Drain System
Chapter 4: Propulsion & Related Systems Quick Oil Drain System The quick oil drain hose was attached to the engine oil pan at the factory. However, some minor assembly is still needed before you can use this system. How to install the quick oil drain system: 1. -
Page 31: Chapter 5: Controls & Gauges
Chapter 5: Controls & Gauges Steering • Your boat features a power assisted rack-and-pinion steering system. • For information about the 'power assist fluid reservoir', refer to the engine operation and maintenance manual. • Boat steering is not self-centering. • Refer to the engine manual for more steering system details. Shift/Throttle Controls WARNING! LOSS OF CONTROL HAZARD! -
Page 32: Trim Tabs (2400Sd Only) (If Equipped)
Chapter 5: Controls & Gauges Trim Tabs (2400SD Only) (If Equipped) WARNING! LOSS OF CONTROL HAZARD! Improper use of trim tabs will cause loss of control! • Do NOT allow anyone unfamiliar with trim tabs to use them. • Do NOT use trim tabs in a following sea as they will cause broaching or other unsafe handling characteristics. -
Page 33: Gauges
Chapter 5: Controls & Gauges Gauges Cleaning Gauges CAUTION PRODUCT or PROPERTY DAMAGE HAZARD! • Use only mild soap and water to clean the gauge lenses and bezels. • Use of other cleaners, including common window cleaning solutions, may cause the lenses to crack. -
Page 34: Chapter 6: Plumbing
Chapter 6: Plumbing Bilge Pump NOTICE Discharge of oil, oil waste or fuel into navigable waters is prohibited by law. Violators are subject to legal action by the local authorities. • Your boat is equipped with a bilge pump for pumping water out of the bilge. -
Page 35: Bilge Pump Testing
Chapter 6: Plumbing Bilge Pump Testing • The bilge pump is vital to the safety of your boat. • Test the bilge pump often to make sure it is working properly. To test the bilge pump: 1. Turn On the bilge pump switch at the helm. 2. - Page 36 Chapter 6: Plumbing Autofloat Switch • The automatic bilge pump uses a float (autofloat) switch to automatically turn On the pump whenever water rises to a preset level in the bilge. • The autofloat switch is normally mounted next to the bilge pump it controls. •...
-
Page 37: Freshwater System
Chapter 6: Plumbing Freshwater System WARNING! • Only use safe drinking (potable) water in your boat’s freshwater system. • Only use an FDA approved, white 'drinking water safe' hose to fill the freshwater tank. • NEVER use a common garden hose for drinking water. 2100SD FRESHWATER SYSTEM TRANSOM SHOWER WATER FILL... - Page 38 Chapter 6: Plumbing 2400SD FRESHWATER SYSTEM TRANSOM SHOWER COCKPIT SINK WATER FILL DECK FITTING WATER TANK VENT WATER TANK HEAD SINK WATER PUMP BOW SHOWER (IF EQUIPPED) • Read the Freshwater System section in the Sport Boat Owner’s Manual. • Your boat is equipped with a pressure type (demand) freshwater (potable) system. •...
-
Page 39: Freshwater System Winterization
Chapter 6: Plumbing Freshwater System Winterization CAUTION WATER SYSTEM DAMAGE HAZARD! NEVER blow compressed air through the water system when all of the faucets are Closed. 1. Turn On the freshwater pump switch. 2. Open all of the faucets and showers and let the freshwater system drain completely. 3. -
Page 40: Drain Systems
Chapter 6: Plumbing Drain Systems Deck Drains • Water on the deck is drained overboard through the deck drains. • Keep the deck drains free of debris. Sink Drains The sink drain is above the waterline and are gravity drained overboard Portable Toilet (If Equipped) NOTICE Check with local authorities for regulations regarding the legal use of marine head systems. -
Page 41: Portable Toilet Pump-Out (If Equipped)
Chapter 6: Plumbing Portable Toilet Pump-Out (If Equipped) Read and follow the manufacturer’s operating instruc- tions before using this feature. PUMP-OUT PUMP-OUT VENT DECK FITTING PORTABLE TOILET... -
Page 42: Chapter 7: Deck Equipment
Chapter 7: Deck Equipment Cleats and Tow Eyes WARNING! PERSONAL INJURY and /or PRODUCT or PROPERTY DAMAGE HAZARD! NEVER lift the boat using the bow and stern eyes or the cleats. Read the section on towing in the Sport Boat Owner’s Manual before: •... -
Page 43: Ski-Tow Tower (If Equipped)
Chapter 7: Deck Equipment Ski-Tow Tower (If Equipped) WARNING! PERSONAL INJURY and /or PRODUCT or PROPERTY DAMAGE HAZARD! Failure to follow these guidelines can result in injury or death: • Read all warning labels on ski-tow tower. • Before each use, make sure all bolts are in place and tight. •... -
Page 44: Folding Ski-Tow Tower
Chapter 7: Deck Equipment Folding Ski-Tow Tower WARNING! PERSONAL INJURY and /or PRODUCT or PROPERTY DAMAGE HAZARD! • Folding or unfolding the ski-tow tower is a two person task. • Before each use of the folding ski-tow tower, make sure all four lock-down bolts are tightened firmly. -
Page 45: Canvas
Chapter 7: Deck Equipment Canvas CAUTION PRODUCT or PROPERTY DAMAGE HAZARD! Take down and securely stow ALL canvas before transporting your boat by road. NOTICE Two people are needed for most of the tasks listed in this section. NOTICE Before cleaning and/or stowing your canvas or vinyl, read the sections later in this chapter, Canvas Care and Vinyl Care. -
Page 46: Canvas Care
Chapter 7: Deck Equipment Canvas Care (see also, ‘Clear Vinyl Care’ on next page) • After each use, especially in saltwater, rinse the canvas with cold freshwater. • Before stowing, let the canvas air dry completely. • The canvas can be rolled or folded for stowage. Cleaning Canvas CAUTION NEVER use detergents when washing the canvas. -
Page 47: Chapter 8: Entertainment Systems
Chapter 8: Entertainment Systems Audio Equipment NOTICE AM radio reception may be impaired anytime the engine is running. Read the manufacturer’s instruction manual before using the audio equipment. -
Page 48: Chapter 9: Convertible Seats, Beds, & Tables
Chapter 9: Convertible Seats, Beds, & Tables Bow Conversion (If Equipped) 1. Place the forward filler board (A) and the aft filler board (B) so that they fit securely on the edge lips. 2. Place the filler cushion (C) on top of the filler boards. -
Page 49: Chapter 10: Lights
Chapter 10: Lights Care and Maintenance All of the lights installed on your boat are of top quality, but you should be aware that failure may periodically occur for a variety of reasons: 1. There may be a blown fuse - replace the fuse. 2. -
Page 50: Chapter 11: Electrical System
Chapter 11: Electrical System DANGER! EXTREME FIRE, SHOCK & EXPLOSION HAZARD! • To minimize the risks of fire and explosion, NEVER install knife switches or other arcing devices in the fuel compartment. • NEVER substitute automotive parts for marine parts. Electrical, ignition and fuel system parts were designed and manufactured to comply with rules and regulations that minimize risks of fire and explosion. -
Page 51: 12-Volt Dc System
Chapter 11: Electrical System 12-Volt DC System Batteries The batteries supply electricity for lights, 12-volt accessories, and engine starting. The Electrical section of Chapter 8, in the Sport Boat Owner’s Manual, provides battery care and maintenance instructions. Battery Switch (If Equipped With One Battery) CAUTION SHOCK &... -
Page 52: Battery Switch Positions
Chapter 11: Electrical System Battery Switch Positions NOTICE Since your boat’s batteries were installed by your dealer, the battery switch positions listed below may vary. Make sure your selling dealer fully explains how to use the battery switches. BATTERY SWITCH ENGINE ENGINE ACCESSORIES &... -
Page 53: Electrical Routings
Chapter 11: Electrical System Electrical Routings 2100SD Deck Electrical Harness NOTE: VIEW IS OF UNDERSIDE OF DECK STARBOARD DOCKING PORT DOCKING LIGHT (IF EQUIPPED) LIGHT (IF EQUIPPED) PORT BOW STARBOARD LIGHT BOW LIGHT SPEAKER SPEAKER COURTESY LIGHT DOME LIGHT STEREO FUSE BLOCK HORN... -
Page 54: 2400Sd Deck Electrical Harness
Chapter 11: Electrical System 2400SD Deck Electrical Harness NOTE: VIEW IS OF UNDERSIDE OF DECK STARBOARD DOCKING PORT DOCKING LIGHT (IF EQUIPPED) LIGHT (IF EQUIPPED) STARBOARD PORT BOW BOW LIGHT LIGHT SPEAKER SPEAKER COURTESY LIGHT STEREO DOME LIGHT FUSE BLOCK HORN 12-VOLT DOME... -
Page 55: Hull Electrical Harness
Chapter 11: Electrical System Hull Electrical Harness BATTERY SWITCH BLOWER BATTERIES TO DECK HARNESS ENGINE STARTER ENGINE GROUND BILGE PUMP... -
Page 56: Wiring Diagram
Chapter 11: Electrical System Wiring Diagram... -
