Data Link Connectors • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Ford and Lincoln/Mercury Cars, Light Trucks & Vans
MODEL
Bronco II
E-Series,
Econoline Van
Explorer
F-Series Pickup 4.9L, 5.0L, 5.8L,
Ranger
Windstar
* Early models are equipped with the EEC III diagnostic system which is not supported by this tool.
A
A – 6• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
ENGINES DLC
2.8L, 2.9L EEC-IV
4.9L, 5.0L, 5.8L, EEC-IV
7.3L D, 7.3L TD
7.5L Calif. >14,000 EEC-IV
GVW
7.5L 49 States EEC-IV
5.8L > GVW EEC-IV
4.0L EEC-IV
EEC-IV
7.3L D,
7.3L TD, 7.5L
5.8L > 8500 GVW EEC-IV
7.0L EEC-IV
7.0L > 14,000 GVW EEC-IV
7.5L W/Fed Emiss EEC-IV
7.5L > 8,500 GVW EEC-IV
49 States
7.5L > 14,000 GVW EEC-IV
2.3L MCU
2.3L, 2.8L, 2.9L, EEC-IV
3.0L, 4.0L
2.3L, 3.0L, 4.0L EEC-V
3.0L, 3.8L EEC-V
YEAR
84-88 Right inner fender near starter relay.
89-90 Right fender panel below engine
compartment fuse block.
84-91 Right front fender near starter relay.
92-95 Left front corner of engine compartment.
96 Left front corner of engine compartment.
96 Left front corner of engine compartment.
96 Left front corner of engine compartment.
91-95 Right rear of engine compartment.
84-87 Right inner fender near starter relay.
88-95 Left front fender apron in rear of engine
compartment.
96-98 Left rear of engine compartment.
91-96 Left rear of engine compartment.
97-98 Left rear of engine compartment.
96 Left rear of engine compartment.
97-98 Left rear of engine compartment.
97-98 Left rear of engine compartment.
84 Right front inner fender panel.
84-85 Right front inner fender panel.
86-92 Right rear fender apron near fuel pump relay.
Left front inner fender by fuse/relay block.
92-94
95 Below instrument panel, right of steering
wheel.
95 Below instrument panel, right of steering
wheel.
LOCATION
