imaging Series
NTSC/PAL to 4:2:2
ASD - 231i
Adaptive Decoder
with TBC
Guide to Installation and Operation
M212-0900-101
Copyright 2002 Miranda Technologies Inc.
Specifications may be subject to change.
Printed in Canada
August 2002
Miranda
Technologies inc.
3499 Douglas-Floreani, St-Laurent
(Québec) Canada, H4S 2C6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASD-231i and is the answer not in the manual?

Questions and answers

Related Manuals for Miranda ASD-231i

Summary of Contents for Miranda ASD-231i

  • Page 1 Series NTSC/PAL to 4:2:2 ASD - 231i Adaptive Decoder with TBC Guide to Installation and Operation M212-0900-101 Copyright 2002 Miranda Technologies Inc. Specifications may be subject to change. Printed in Canada August 2002 Miranda Technologies inc. 3499 Douglas-Floreani, St-Laurent...
  • Page 2 Miranda’s liability for any cause, including breach of contract, breach of warranty, or negligence, with respect to products sold by it, is limited to repair or replacement by Miranda, at its sole discretion. In no event shall Miranda Technologies Inc.

  • Page 3: Safety Compliance

    - This equipment complies with the requirements of EN55022 Class A, Electromagnetic Emissions, En 61000-3-2, Disturbance in Supply Systems and EN55025, Electromagnetic Immunity. How to contact us: Head Office Miranda Europe Miranda Asia Miranda Technologies Inc. 222, 226 Rue De Rosny Mita Nexus Bldg. 2F 3499 Douglas-B.-Floreani 93100 Montreuil 1-3-33 Mita, Minato-Ku St.

  • Page 4: Table Of Contents

    CONTENTS page 1 ASD-231i NTSC/PAL to 4:2:2 Adaptive Decoder with TBC..1 Introduction....................1 Features....................... 1 2 Installation............…..... 3 Unpacking....................3 ASD-231i Mechanical Installation..............3 2.2.1 imaging Quartet Series Frames............. 3 2.2.2 imaging Symphonie Frame……………........... 2.2.3 imaging Solo Frame................ Rear Panel Label..................4 2.3.1...

  • Page 5: Asd-231I Ntsc/Pal To 4:2:2 Adaptive Decoder With Tbc

    4:2:2 video to a local reference input. If no external reference is detected, the ASD-231i locks on to the composite input. If the input signal degrades or disappears, the ASD-231i can be set to freeze on the last error- free field, switch to black, or disable the output 4:2:2 signals.
  • Page 6 • 4 serial 4:2:2 outputs conforming to the SMPTE 259M-C standard • Built-in frame synchronizer • Built-in Automatic Gain Control (AGC) • Adaptive Time-Base Corrector: automatic selection of 2D comb or bandsplit filtering on Y channel • 2X oversampling • 3D adaptive decoding •...

  • Page 7: Installation

    M-A110, Symphonie (using Symphonie-R-M rear module), or Solo imaging frames in order to provide power to the module. This section describes how to install the ASD-231i in any of these frames. It is not necessary to switch off the power from these frames when installing or removing the ASD-231i.

  • Page 8: Rear Panel Label

    3. Replace the frame's front panel. 2.3 Rear Panel Label Connector labels have been shipped with the ASD-231i. These labels are to be installed on the frames’ rear panel in order to identify the module's external connectors. 2.3.1 imaging Quartet Series/Solo Frames To install the Quartet/Quartet-C/Quartet-M/Quartet-M-A75/Quartet-M-A110/Solo label, follow these steps while referring to Figure 2.1.

  • Page 9: Imaging Symphonie Frame

    2.3.2 imaging Symphonie Frame To install the Symphonie label, follow these steps while referring to Figure 2.2. 1. On Symphonie’s rear panel, locate the appropriate connectors. 2. Remove the rear label mounting screws from the rear module. 3. Carefully apply the label to the connectors making sure the label’s text is read from top to bottom.

  • Page 10: Asd-231I Electrical Installation

    REF IN - reference input with passive loop through If you wish to reference the ASD-231i to the rest of your facilities, connect a studio reference signal to the BNC labeled REF IN. The ASD-231i accepts SMPTE 170M/PAL ITU 624-4 or 2 Vpp/4 Vpp composite sync reference signals.
  • Page 11 Figure 2.2 ASD-231i electrical installation Composite loop through output ASD-231i NTSC/PAL TO 4:2:2 DECODER WITH TBC DELAY Quartet-M Quartet-M-A75 Quartet-M-A110 Symphonie-R-M COMPOSITE IN 4:2:2 OUT REF IN Video processing delay output Analog composite input SMPTE 259M-C Studio reference (NTSC, PAL, PAL-M,...

  • Page 13: Operation

    3 Operation 3.1 ASD-231i User Interface Figure 3.1 illustrates the ASD-231i's user interface situated at the front end of the module. The interface components include the following: • 4-character dot matrix display and 4 push-buttons for menu access • Input status monitoring: reference and composite source signals •...
  • Page 14 Automatic Exit From Menu After 1-Minute Interval If the menu is currently being accessed and no push-button has been pressed for 1 minute, the ASD-231i automatically exits from the menu thereby returning to normal mode. Also, changes made to the current parameter will be stored.
  • Page 15 Figure 3.2 ASD-231i menu structure format E FRMT S E [AUTO,NTSC,PAL,PALM,PALN,SECM,BW] E FLTR S E [A-3D,A-2D,3D,2D,SPLT] (Studio/Satellite) [SPLT,AUTO] (VCR) (No FLTR selection during SECAM) E TIMG S E VERT S E [0,…,524] (step=1, unit=LINE) (NTSC/PAL-M) [0,…,624] (step=1, unit=LINE) (PAL/PAL-N/SECAM) E HOR S E [0,…,63.5] (step=0.04, unit=us) (NTSC/PAL-M) [0,…,64.0] (step=0.04, unit=us) (PAL/PAL-N/SECAM)

  • Page 16: Input Status Monitoring

    Automatic Format Detection During this mode of detection, the ASD-231i detects the type of input and automatically switches to that format by loading the decoder with the format’s parameters. To enable automatic input detection follow these steps: 1.

  • Page 17: Decoding Filter

    NTSC format and a 625-line format will load the PAL format. 3.6 Decoding Filter The ASD-231i provides the 5 types of decoding filters which are listed in Table 3.1. The selection of a decoding filter will depend highly on the nature of the input composite signal. For example, choosing between A-3D and A-2D will depend highly on the content of your source.

  • Page 18: Vertical Timing

    is in Frame Synchronizer mode: the timing adjustment sets the processing delay between the reference and output signals. 3.7.1 Vertical Timing The vertical timing adjustment is made in increments of 1 video line up to 524 lines in NTSC and PAL-M and 624 lines in PAL, PAL-N, and SECAM.

  • Page 19: Gain

    5. Press SELECT to enable the horizontal timing menu. The current timing delay in us is displayed. 6. Press UP(+) to increase the timing delay and press DOWN(-) to decrease the timing delay. Press UP(+) and DOWN(-) simultaneously to set the timing to 0 us. 7.

  • Page 20: Setup

    6. To return to normal mode, press ESCAPE. 3.10 Hue The ASD-231i can adjust hue level when in NTSC input mode, from –180º to +180º in increment of 0.25 degrees (1.5 degrees in VCR mode). Follow these steps in order to set the hue level: 1.

  • Page 21: Freeze Selection

    3.11 Freeze Selection The ASD-231i can automatically freeze to a predefined freeze selection if it has detected an input signal loss or it has detected errors on the input composite signal. Refer to Table 3.4 for a description of each possible setting.

  • Page 22: Closed Captioning Selection

    2. Press the DOWN(-) push-button until VANC is displayed. 3. Press SELECT to enable the VANC menu. PROC is displayed. 4. Press SELECT to enter the PROC menu. The current VANC processing option is displayed. 5. Press the UP(+) or DOWN(-) push-button until the desired VANC processing option is displayed.

  • Page 23: Factory Reset

    3. Press SELECT to enter the FACT menu. NO is displayed. 4. Press the (+) push-button until YES is displayed. Selecting NO or pressing ESC will return the user to the main menu without resetting the ASD-231i. Selecting YES restores default parameter values and erases all user settings.
  • Page 24 3. To disable the color bar generator press TEST(+) when in normal mode.

  • Page 25: Stored Configurations

    4 Stored Configurations Table 4.1 provides the stored parameters for each format. When a new format is selected, all stored parameters for that format are loaded. Global parameters apply to all formats. Table 4.1 Stored parameters NTSC PAL-M PAL-N SECAM Studio Satellite VCR Studio Satellite VCR Studio Satellite VCR Studio Satellite VCR Studio Satellite VCR Source type Format...

  • Page 27: Specifications

    4:2:2 SMPTE 259M-C (270 Mbps) Return loss: > 15 dB up to 270 MHz Jitter (wideband): < 0.2 UI (0.74ns) pp Video Delay Signal: Differential signal (Miranda proprietary video delay tracking pulse) Processing Performance Quantization: 12 bits Sampling: 27 MHz (2X oversampling) Frequency response: ±0.1 dB up to 5.75 MHz...
