Jackson Grills Patio Fire Instructions Manual

For outdoor use only
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
J
ACKSON
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of life.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switches; do not use the phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
WARNING: Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Read the
installation, operation and maintenance instructions thoroughly before
installing or servicing this equipment.
G
RILLS
F
IRE
Tested by:
Tested to: ANSI Z21.97-2010 & CSA CAN 1-2.21-M85
WARNING: For Outdoor Use
Only.
P
ATIO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Patio Fire and is the answer not in the manual?

Questions and answers

Related Manuals for Jackson Grills Patio Fire

Summary of Contents for Jackson Grills Patio Fire

  • Page 1 PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE ACKSON RILLS ATIO Tested by: Tested to: ANSI Z21.97-2010 & CSA CAN 1-2.21-M85 WARNING: For Outdoor Use Only. WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 2: Table Of Contents

    ABLE OF ONTENTS Safety Precautions..................……… 3 Specifications....................……… 4 Assembly......................……… 4 Campfire Placement..................……… 4 Lighting Instructions..................……… 5 Turning Off Gas To Campfire................……… 6 Log & Ember Placement..................Natural Gas Conversion…………………………………………………………………………………………. 8 Care & Maintenance....................Storage......................……… 10 Warranty......................

  • Page 3: Safety Precautions

    PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: GENERAL • The Patio Fire must be installed in accordance with their instructions. Carefully read all the instructions in this manual first. Consult the building authority having jurisdiction to determine the need for a permit prior to commencing the installation.

  • Page 4: Specifications

    PECIFICATIONS Input: 48,500 BTU•h (4.12 KW•h) Manifold Pressure: 11 inch W.C. (2.74 KPa) Maximum Gas Supply Pressure: 13 inch W.C. (3.50 KPa) LP Orifice Size: # 47. NG Orifice Size: # 35 Recommended LP-gas supply cylinder size: 20 lbs Hours of operation using a 20 lb Cylinder of Propane: 8 to 10 hours SSEMBLY 1.

  • Page 5: Lighting Instructions

    IGHTING NSTRUCTIONS 1. Inspect the hose and burner for wear or damage. DO NOT LIGHT THE FIRE PIT IF DAMAGE OR WEAR IS FOUND. 2. Attach the regulator assembly to your propane cylinder. MAKE SURE YOUR PROPANE CYLINDER VALVE IS CLOSED 3.

  • Page 6: Turning Off Gas To Campfire

    Figure 4 shows the Jackson Grills Patio Fire burner clean and empty. The burner ports and alignment pins are highlighted for reference. When placing the logs ensure that they do not cover any of the burner ports.
  • Page 7 Figures 7 through 10: Place logs 3 to 6 using the images below. Figure 7 Figure 8 Figure 9 Figure 10 Place the ember fibers over the burner making sure to cover all the burner slots.

  • Page 8: Natural Gas Conversion

    ATURAL ONVERSION Tools required to convert this unit from propane gas to natural gas: # 2 Phillips screwdriver 8 and 18 mm wrenches Adjustable wrench The outdoor gas appliance and its individual shut off valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of ½...

  • Page 9: Care & Maintenance

    & M AINTENANCE - Should your campfire be left out in the rain, simply light it as usual and burn until the log set and embers have dried out and begin to glow. - Scratches and stains on the wind guard can be buffed out using a Scotch-Brite pad. Be sure to buff “with the grain”...

  • Page 10: Storage

    If the Patio Fire is to be transported or stored, the hose and regulator assembly must be wrapped around the center of the base. Do not wrap so tight as to kink the hose at the base connection end.

  • Page 11: Warranty

    ARRANTY A one-year warranty is offered for the Patio Fire against manufacturing defects. This warranty covers defects in materials and workmanship only if the product has been installed and used according to the manual’s instructions. If the product is damaged or broken as a result of misuse or mishandling, the warranty does not apply.

  • Page 12: Parts List

    ARTS Replacement parts can be ordered from your dealer or distributor. Part Number Part Description TPR18THA Tee Handle Assembly TPR18LID TPR18WG Wind guard TPR18LS Log set TPR18EMB Embers (2 bags) TPR18LPB LP Burner TPR18BDY Body TPR18HRA Hose & Regulator Assembly TPR18LPOFA LP Orifice Fitting Assembly TPR18BC...
