Summary of Contents for Petsafe PIF00-13652
- Page 1 Model number Pif00-13652 Please read this entire guide before beginning...
- Page 2 1-800-732-2677...
- Page 3 To get the most protection out of your warranty, please register your product within 30 days at www.petsafe.net. By registering and keeping your receipt, you will enjoy the product’s full warranty and should you ever need to call the Customer Care Center, we will be able to help you faster.
-
Page 4: Important Safety Information
Important Safety Information Explanation of Attention Words and Symbols used in this guide This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury. - Page 5 While physically close to the outside door: PET LEAVING THE HOUSE: 1. Place Receiver Collar on your pet and fit it correctly with the PetSafe logo upright facing towards your dog’s chin, and facing away from your dog’s body as shown in Figure 6B on page 22.
- Page 6 • This PetSafe® Wireless Mapping Fence is NOT a solid barrier. The system is designed to act as a deterrent to remind pets by Static Correction to remain in the boundary established. It is important that you reinforce training with your pet on a regular basis. Since the tolerance level to Static Correction varies from pet to pet, Radio Systems®...
- Page 7 Receiver Collar back to level 1 tone only. • Do not charge your Receiver Collar every night. Charging too often can reduce battery life. Charge your Receiver Collar when the Receiver Indicator Light blinks red/green; or when the light blinks red. www.petsafe.net...
-
Page 8: How The System Works
The Wireless Mapping Fence may be used with a privacy fence if you have problems with your dog digging under the fence. The PetSafe Wireless Mapping Fence has been proven safe, comfortable, and effective for pets over 15 pounds. ®... -
Page 9: Receiver Collar
Receiver Collar Mode Button Contact Receiver Receiver Points Indicator Light Charge Jack www.petsafe.net... -
Page 10: Charge The Receiver Collar
Operating Guide Step Charge the Receiver Collar Do not charge your Receiver Collar every night. Frequent charging can have a negative effect on the battery life. We recommend that the Receiver Collar be used until the Receiver Indicator Light blinks red/green or red. To Charge the Receiver Collar 1. -
Page 11: Prepare The Receiver Collar
Receiver Collar is ® working and ready to use. When you remove the Receiver Collar from the charger, the receiver’s internal diagnostics will check that the battery charge is full and that all circuits are working correctly. www.petsafe.net... -
Page 12: Receiver Collar Status Indicators
Receiver Collar Status Indicators The Receiver Collar uses colored LEDs and an Alarm Tone to indicate the functional and operational status of the receiver. Refer to the table below to understand the operation of the lights and tones for the Receiver Collar. - Page 13 Anti-linger static correction being delivered with the Receiver Collar (3 flashes per second) warning tone in the Warning Zone area Fast pulsating red High frequency Run through static correction being delivered with the Receiver Collar (3 flashes per second) warning tone beyond the mapped boundary point area www.petsafe.net...
-
Page 14: Set The Static Correction Level
Set the Static Correction Level The Static Correction Level can be changed by two methods. Set Static Correction Level Using Receiver Collar 1. Press the Receiver Collar Mode Button briefly when the unit is turned ON. The indicator light will light red when the button is pressed. - Page 15 If your dog leaves the Pet Area, this feature limits the Static Correction duration to 15 seconds. While the system locks out further Static Correction, the green light will remain ON for 10 seconds. The Static Correction will remain locked out until your pet has remained back in the Pet Area for at least 10 seconds. www.petsafe.net...
- Page 16 Receiver Collar Settings Within the BPU system settings are user selectable features that allow you to customize the way the system functions. This section describes each of these features and how they function. Correction Level: Used to program the Static Correction Level into the Receiver Collar. Warning Zone Width: Used to program the distance between the Warning Zone and the Static Correction Area.
-
Page 17: Prepare The Receiver Collar For Programming
Receiver Mounting Bracket on the Receiver Handle. The Receiver Collar must be installed with the arrow on the Receiver Mounting Bracket pointing toward the Receiver Collar PetSafe ® logo (3A). Orient Receiver Handle so that the arrow on the Receiver Handle is pointing up (3B). - Page 18 Warning Zone and Static Correction Areas. You may program an unlimited number of Receiver Collars using this same boundary. If you’d like to set-up a unique boundary for another pet you will need to refer to your PetSafe Wireless Mapping Fence Operating ®...
-
Page 19: Set The Warning Zone
Through Prevention Static Correction is generated. This setting would also be appropriate if you have a stubborn dog. 4. If you have a very timid dog, consider setting the Warning Zone width to Max. to allow more distance before the higher level Run-Through Prevention Static Correction is generated. www.petsafe.net... - Page 20 Area. Don’t move the Receiver Collar back and forth like a pendulum. Do not walk or move the Receiver Collar backwards. Always hold the Receiver Handle so that the PetSafe logo on the Receiver Collar is facing toward your direction of motion.
-
Page 21: Test Light Instructions
1. Set the Correction Level to 2 or above. 2. Hold the Test Light Contacts to the Receiver Collar Contact Points (5A). 3. When moving, the PetSafe logo must be pointed in the direction of forward motion. PetSafe logo must ®... -
Page 22: Fit The Receiver Collar
To assure a proper fit, please follow these steps: 1. Make sure the Receiver Collar is turned OFF. 2. Start with your pet standing comfortably (6A). 3. Make sure PetSafe logo is upright, facing the dog’s chin (6B). ® 4. Center the Contact Points underneath your pet’s neck, touching the skin. - Page 23 Remove the Receiver Collar from your pet and cut off the excess. c. Before placing the Receiver Collar back onto your pet, seal the edge of the cut collar by applying a flame along the frayed edge. www.petsafe.net...
-
Page 24: To Re-Thread The Collar
To Re-Thread the Collar Slide Buckle The slide buckle prevents the collar from becoming loose around your pet’s neck. Ridges The ridges must be facing up; the collar will slip if it is not properly threaded. Always remove the Receiver Collar from your pet when indoors to avoid accidental activation of the Receiver Collar. -
Page 25: Taking Your Pet Out Of The Pet Area
You may initially need to convince your pet to leave the Pet Area with a food treat and lots of praise. Note: You may also carry your pet out of the Pet Area. Please refer to your PetSafe Wireless Mapping Fence Operating and ®... -
Page 26: Troubleshooting
4-5 seconds. Warning Zone. • Charge Receiver Collar. • Be sure the Receiver’s PetSafe logo always faces the direction of motion ® when carried by hand. • Be sure the logo always faces toward the dog’s chin when collar is on dog. - Page 27 Receiver Collar is activating. There may be something underground that may be causing the Transmitter signal to be distorted in that area. • Be sure the Receiver’s PetSafe logo always faces the direction of motion when ®...
- Page 28 The Receiver Collar is beeping • Make sure the Static Correction Level is set at 2 or above. but my pet is not responding to • Test the Receiver Collar with the Test Light. the Static Correction. • If the Test Light flashes, check the fit of the Receiver Collar. •...
- Page 29 BPU is connected to the • Charge the Receiver Collar if needed. Receiver Collar. The Receiver Collar no longer • Be sure the Receiver’s PetSafe logo always faces the direction of motion ® properly detects the boundary when carried by hand.
-
Page 30: Terms Of Use And Limitation Of Liability
Terms of Use and Limitation of Liability 1. Terms of Use This Product is offered to you conditioned upon your acceptance without modification of the terms, conditions and notices contained herein. Usage of this Product implies acceptance of all such terms, conditions, and notices. 2. - Page 31 Unauthorized changes or modifications to the equipment, not approved by Radio Systems Corporation, could result in ® not meeting compliance with FCC regulations and void the user’s authority to operate the equipment. Australia This device complies with the applicable EMC requirements specified by the ACMA (Australian Communications and Media Authority). www.petsafe.net...
-
Page 32: Customer Care International
Customer Care International USA & Canada - Tel: 800-732-2677 Monday - Friday 8 AM - 8 PM / Saturday 9 AM – 5 PM Australia - Tel: 1800 786 608 Monday - Friday 8:30 AM - 5 PM New Zealand - Tel: 0800 543 054 Monday - Friday 10:30 AM - 7 PM 1-800-732-2677... -
Page 33: Warranty
This Product has the benefit of a limited manufacturer’s warranty. Complete details of the warranty applicable to this Product and its terms can be found at www.petsafe.net. Australia/New Zealand - In compliance with the Australian Consumer Law, Warranties Against Defects, effective January... -
Page 34: Claims Procedure
Claims Procedure Any claim made under this Warranty should be made directly to Radio Systems Australia Pty Ltd Customer Care Centre at: Radio Systems Australia Pty Ltd PO Box 765, Mudgeeraba QLD 4213 Australia Residents: 1800 786 608 New Zealand Residents: 0800 543 054 Email: info@petsafeaustralia.com.au To file a claim, a proof of purchase must be provided. - Page 35 www.petsafe.net...
- Page 36 Radio Systems Corporation ® 10427 PetSafe Way Knoxville, TN 37932 1-800-732-2677 www.petsafe.net Protected by US Patent 7,656,291. 400-1631 ©2013 Radio Systems Corporation...
