Digital Power Supply Unit for LED Lights
Safety Precautions
Thank you for purchasing PDS Power Supply for LED lights. Please read this Instruction
Guide carefully before using the product, and follow its instructions to ensure safe
operation. We also recommend keeping this Instruction Guide together with the product
for future reference.
Be sure to pay special attention to the information marked with "
or "
Caution". The information is provided to prevent injury, electric shock and other
damages.
Indication symbols
This instruction guide contains following symbols which indicate precautions in order to
prevent injury or property damages. To ensure safe operations, please adhere to the
information provided in this instruction guide.
Indicates an imminently hazardous situation which, if not avoided, will result
Danger
in death or serious injury, as well as severe property damage.
Warning Indicates incorrect usage may result in serious injury or death.
Caution Indicates incorrect usage may result in injury or equipment damage.
Examples of indication symbols
Symbols indicate caution (also including danger and warning).
Specific examples are shown in the diagram (A diagram on the left indicates
electric shock warning).
Symbols indicate prohibition.
Specific examples are shown in the diagram. (A diagram on the left indicates
prohibition to disassemble)
Symbols indicate instruction for specific actions.
Specific examples are shown in the diagram. (A diagram on the left indicates
unplugging a power cord)
PDS-30 Instruction Guide
*Please read this instruction guide before using the product.
Danger," "
Warning,"
