CCS PFB3-20SW-SJT Series User Manual

Hyper led light source
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
LED Light Source
HYPER
PFB3-20SW-SJT(A)
Thank you for purchasing a CCS product. In order
to properly use this product, please read this User
Manual before using and keep it for future reference.
Series
Introduction
Page
Important Equipment Safety
Information
Page
Name and Function of Each Part
Page
Installation
Page
Connecting Cables
Page
Preparation Capture Images
Page
Manual Operation
Page
Remote Operation
Page
Reference
Page
Troubleshooting
Page
Main Specifications
Page
1
3
5
7
9
14
15
16
19
21
22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFB3-20SW-SJT Series and is the answer not in the manual?

Questions and answers

Related Manuals for CCS PFB3-20SW-SJT Series

Summary of Contents for CCS PFB3-20SW-SJT Series

  • Page 1 LED Light Source HYPER Reference Page PFB3-20SW-SJT(A) Series Troubleshooting Page Main Specifications Page Thank you for purchasing a CCS product. In order to properly use this product, please read this User Manual before using and keep it for future reference.
  • Page 2 Introduction Introduction Features • This HYPER LED Light Source Unit is mainly used as a light source for image processing and industrial inspection. It is used with a Light Guide attached. This enables a high output and the selection of a lighting pattern that is suitable for the application. •...
  • Page 3 Checking the Product and Its Accessories Before installing the product, please check that all the items shown below are included in your product package. If any of these items are missing, please contact CCS Inc. LED Light Source Unit (Main Unit)
  • Page 4 -Read Before Use- -Read Before Use- Important Equipment Safety Information Important Equipment Safety Information This product has been designed with full consideration of safety. However, incorrectncorrect usage of the product may result in fire, electric shock, or other serious damage. Please ensure to follow the conditions below. Symbol descriptions Warning Indicates that incorrect usage may result in serious injury or death.
  • Page 5 Important Equipment Safety Information Caution Always use one of the following power cord when using the AC adaptor. 100 to 120V range: SVT or SJT type, AWG18, length: 3m max., dielectric strength: 125V min. 200 to 240V range: H05VV-F type, AWG18, length: 3m max., dielectric strength: 250V min. FIRE HAZARD Do not place product under direct sunlight or in a high humidity environment.

  • Page 6: Name And Function Of Each Part

    Name and Function of Each Part Name and Function of Each Part Light Source Unit Front Screw for securing the light guide Power indicator lamp Light guide attachment adaptor Fan air inlets 16 types of adaptors are available. Error indicator lamp Light guide insertion port The LED light source is Power switch...

  • Page 7: Power Input Connector

    Connect to pin 7 Not connected An optional CCS external control cable EXCB2-9-9-3-ST (a 3m long cable with a connector) is sold separately. The user may prepare a shielded control cable as long as the length does not exceed 3m.

  • Page 8: Installation Environment

    Installation Installation Installation Environment Please use products in locations with following conditions. Incorrect Caution installation location may cause product failure. • On a flat and stable location with minimal vibration. • Well ventilated places with minimal dust. • Places free from corrosive or combustible gas. •...
  • Page 9 Installation Making the Unit Secure Securing the Side Insert holding fixture into the slit on the side of the unit. Tighten the installation screws to secure the unit. Note: The holding fixture, installation screws, and stationary plate must be provided by the user. * Holding fixture Installation screws Stationary plate...

  • Page 10: Connecting Cables

    Connecting Cables Connecting Cables Before connection, make sure that the power is turned OFF. Making Warning connections with the power ON may result in a fire or electric shock. Insert the Light Guide Checking the Light Guide Check the model of the PFB3-20SW-SJT(A) that you purchased and then select an applicable Light Guide from the following table.
  • Page 11 Connecting Cables Connecting the Light Guide Insert the light guide into the insertion port, then tighten the screw to secure the light guide. Screw for securing the light guide Light guide attachment adaptor Camera Macro lens Light guide Light guide insertion port Connecting the Power Cable or AC Adaptor Using an AC adaptor Using a power cable...
  • Page 12 Connecting Cables Using a Power Cable Connect a power cable from a 24V DC source to the terminal block on the back of the unit. (The power cable must be provided by the user.) Detach the terminal block cover. Terminal block Terminal block cover Lift up Loosen the screw with a Philips screwdriver, attach the power cable, and retighten the screw.

  • Page 13: Using An Ac Adaptor

    Connecting Cables Using an AC Adaptor Connect the AC adaptor (optional item, sold separately) to the DC jack on the rear side. DC jack AC adaptor Insert the adaptor all the way into the jack. Outside drawing of the AC adaptor (optional item, sold separately) Unit: mm Model: ADP2460-PFB-JTLV6 Center plus...
  • Page 14 Connecting Cables Connect the External Control Cable ( Used when external control is require ) Make sure that the product and external control equipment are turned OFF. Refer to the page 6 connector configuration table, and connect to the external control equipment.

  • Page 15: Turning Power On And Off

    Preparation Capture Images Preparation Capture Images Do not look into the light guide insertion port with the power turned Warning ON. Depending on the light radiant quantity, there is a danger that this could have an adverse effect on the eye. Turning Power ON and OFF Push the power switch to turn the power ON.

  • Page 16: Manual Operation

    Manual Operation Manual Operation Check the Mode Set the Remote/Manual selection switch to the Manual position. Remote / Manual Control Light Intensity Adjust the intensity control knob on the front panel to set the light intensity. The light intensity control is stepless from a minimum intensity of 1 to a maximum intensity of 10. Note: The light intensity of this product is very faint when the intensity control knob is set to the minimum intensity.

  • Page 17: Remote Operation

    Remote Operation Remote Operation Check the Mode Set the Remote/Manual selection switch to the Remote position. Remote / Manual Note: Do not switch during communications. Use External Control Connect the external control cable and send a command with reference to the following “List of Functions”...

  • Page 18: Communications Specifications

    Remote Operation Communications Specifications Protocol Text string Data bit length 8 bits ASCII code Stop bit Parity check None Baud rate 9600bps Command formats Transmit command Header Prefix Command Write flag Check sum Delimiter 00 (fixed) Transmit command 0 (fixed) Upper Lower Receive command...
  • Page 19 *1 The errors can be detected by the send command (QS) externally. Refer to the page 16 "List of functions" for details. *2 The light source turns OFF and the error indicator lamp blinks. Immediately turn the power switch and the power supply on the supply side OFF, and please contact CCS Inc.
  • Page 20 Reference Reference Intensity Control Characteristics (reference graph) Intensity control characteristics Note: Attach a straight light guide with a join diameter of 8 mm and measure the value at a position 50mm from the end of the fiber Light intensity (%) (values are not guaranteed).
  • Page 21 Reference Efficient use of LED Light Source If the LED is used at high temperatures, the lifetime of the LED light source is shortened. LED light source have the property of degrading radiant quantity and accelerating deterioration through heat generation of the LED itself. For long-life operation •...

  • Page 22: Troubleshooting

    Troubleshooting If you have any problems during product usage, please look up the cause in this chart. If the situation does not improve, or an unexpected situation occurs, please contact CCS Inc. Items to check for fixing the problem Symptom...

  • Page 23: Main Specifications

    Main Specifications Main Specifications Product name HYPER LED Light Source Model PFB3-20SW-SJT-xx(A) (xx: depends on the light guide attachment adaptor) LED color White LED wavelength properties (reference values) Wavelength (nm) Correlated color temperature (typ.) 5,700K Lighting method Constant lighting Drive method Constant-current system Light intensity control method Variable current control Number of channels...
  • Page 24 Main Specifications An error indicator lamp on the front panel flashes (0.5 sec) and output stops <Error details> • LED open failure detected Error detection • LED abnormal temperature detected • Fan shutdown detected (The output will not stop.) • Microcontroller oscillator shutdown detected Note: Recovery by cycling power supply The RS-232C communications command returns error command Error detection output...
  • Page 25 4xM4x6 (For Installation) 37.5 * The dimensions of the light guide attachment adaptor vary for each series. For the dimensions of each series, please contact CCS Inc. Accessing the download page Access the CCS website on the Internet at http://www.ccs-grp.com/.
  • Page 26 MEMO MEMO...
  • Page 27 MEMO...
  • Page 28 Contents of this Instruction Guide may be changed without prior notice. Illustrations used in this Instruction Guide may differ from actual products. CCS maintains the copyright on this Instruction Guide. Unauthorized transfer or reproduction is strictly prohibited. http://www.ccs-grp.com/ Copyright © 2021 CCS Inc. All Rights Reserved.
