Stereo Audio USB External Sound Card with
SPDIF & Built-in Microphone
ICUSBAUDIOMH
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 10/17/2013
*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com ICUSBAUDIOMH
Summary of Contents for StarTech.com ICUSBAUDIOMH
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 10/17/2013...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Product Overview ..................1 Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Installation .....................2 Hardware Installation ..........................2 Software Installation (Windows only) ....................2 Verifying Installation ..........................3 Specifications ..................5 Technical Support ..................6 Warranty Information ................6 Instruction Manual... -
Page 4: Product Overview
Product Overview A. 3.5mm Stereo headphone & S/PDIF output combo jack B. Built-in mono microphone C. 44.1 KHz playback or recording sample rate indicator D. 48 KHz playback or recording sample rate indicator E. 96 KHz playback or recording sample rate indicator F. -
Page 5: Introduction
Introduction Packaging Contents • 1 x USB Stereo Audio Adapter • 1 x Software CD • 1 x Instruction Manual System Requirements • Available USB Port Installation Hardware Installation 1. Plug the USB connection into an available USB port on your desktop or laptop computer. -
Page 6: Verifying Installation
Verifying Installation Windows 1. Open the Device Manager by right-clicking on Computer, and then select Manage. In the new Computer Management window, select Device Manager from the left window panel (For Windows 8, open the Control Panel and select Device Manager). - Page 7 Mac OS 1. Open the System Profiler by clicking the Apple symbol in the top left corner, selecting About this Mac, then select System Report 2. Expand the “Hardware” section and click “USB” in the left column. With the adapter connected, you should see the following device in the list.
-
Page 8: Specifications
Specifications Host Interface USB 2.0 Chipset VIA - VT1630A 1 x 3.5 mm Mini-Jack Female Connectors 1 x 3.5mm / Mini-Toslink (SPDIF) Female 1 x USB A Male Audio Specifications 96KHz/24bit Hi-Fi USB Audio Power Adapter USB-Powered Enclosure Material Plastic Operating Temperature 0°C to 60°C (32°F to 140°F) Storage Temperature... -
Page 9: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 10 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
