Jet Hybrid Style Specification Sheet

Hybrid style tablesaw
Xacta Fence II system
®

with T-square design and HDPE sideboards
Enclosed cabinet

Channels dust to a 4" port for fast, clean dust collection
Poly-V belt drive system

Reduces vibration and heat build up resulting in better power transfer
Left tilting

for more controlled beveled cutting
cast iron wings

for longer work surface and support area
Independent leaf safety guard

Protects operator from blade while cutting, even at 45° tilt
Moveable power switch with reset and power light

lets you customize the position of your on/off switch for convenience, safety
Large heavy-duty handwheels

Helps you make precise adjustments with less effort
OptiOnal accesOries
Mobile Base Zero Clearance Insert
708119 708791
Poly-V belt
drive system
Independent
leaf safety
guard
Moveable power
switch with
reset and power
light
Roller Stand
709207
Features an Xacta
Fence II System that
holds securely to
constantly ensure
accurate cuts
stock number
Model Number
Table Type
Right Rip Capacity (in.)
Motor (TEFC)
Miter Gauge Type
Blade Diameter (in.)
Arbor Diameter (in.)
Maximum Depth of Cut (in.)
Maximum Cut Depth at 45º (in.)
Table in Front of Blade
at Maximum Cut (in.)
Maximum Cross Cut (in.)
Blade to Front of Table (in.)
Maximum Width of Dado (in.)
Maximum Dado Diameter (in.) requires zero clearance insert
Table Height (in.)
Table Size without Wings (L x W/in.)
Overall Dimensions (W x D x H/in.)
Arbor Speed (RPM)
Dust Port (in.)
Distance Between Sliding Table and Blade (in.)
Net Weight (lbs.)
®
708780K
JWSS-10CSPF
Stationary
30
1-3/4HP, 1Ph,
115V
Standard
10
5/8
3-1/3
2-1/8
11-1/2
28-1/2
11-1/2
13/16
8
35-1/4
21-1/4 x 27
60 x 40 x 40
4,000 rPM
4
409
jettools.com
