- Page 1 G14xx Series VIDEO SURVEILLANCE SYSTEM For more exciting new products please visit our website: Australia: www.uniden.com.au New Zealand: www.uniden.co.nz...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This manual contains important information about this product’s operation. If you are installing this product for others, you must leave this manual or a copy with the end user. When using your equipment, always follow basic safety precautions to reduce the risk of fire, electric shock and injury to persons, including the following: • This equipment is NOT waterproof. - Page 3 • Clean only with a dry cloth. Failure to follow the instructions in this operating manual will void the warranty. Uniden assumes no liability for damages to property or injury to persons caused by improper handling or failure to comply with these safety...
-
Page 4: Table Of Contents
Contents WHAt’s In tHe BoX? ..................5 InstALLAtIon ....................6 General Placement Considerations ...................... 6 Installing the Monitor ..........................7 Installing the Camera ..........................7 BAsIC oPeRAtIon ....................10 Monitor ................................10 Camera ................................ 13 LCD Display ..............................14 UsInG tHe G14 seRIes ..................16 Viewing Modes ............................ -
Page 5: What's In The Box
• If any item is missing or damaged, contact your place of purchase immediately. Never use damaged products! • Need help? Get answers at our website: www.uniden.com.au for Australian model www.uniden.co.nz for New Zealand model. All trademarks are registered trademarks of their respective owners. -
Page 6: Installation
InstALLAtIon General Placement Considerations • The cameras included with your monitor are weatherproof and have an IP65 weather rating. Water can be sprayed on them and they will still work; however, the cameras cannot be submerged underwater. • Although the cameras can be exposed directly to the rain, it is recommended that, if they are used outdoors, they be mounted under some type of cover like a patio overhang or eave. -
Page 7: Installing The Monitor
Installing the Monitor Out of the box, your monitor has enough power to be used when you place and install the cameras. You can check the camera placement and angle before you physically screw the camera stands into place. After you have installed the cameras and set up the monitor, plug the DC 5V AC adaptor power output cable into the 5V POWER input of the cradle or monitor. -
Page 8: Attach The Camera
Attach the Camera Attach the camera Tighten the brace against to the mounting the camera to screw and turn it secure it to the desired in place. direction. Loosen the wingnut to Adjust the post to unlock the the correct angle, mounting then tighten the post. -
Page 9: Night Vision
1. Press and hold the POWER button on the left side of the monitor for 1 - 2 seconds to turn it on. 2. The monitor displays the Uniden title screen and then displays the live view, if the paired camera has been powered on. Otherwise Out of Range message displays. -
Page 10: Basic Operation
BAsIC oPeRAtIon Monitor No Keys/Indicators Function Antenna Receives video and audio signals from the camera. LCD Screen Displays video from the cameras Zoom (+/-) Set the image to double size. In Zoom mode, use the navigation buttons to see the parts of the image not displayed on the LCD screen. - Page 11 Navigation Controls Use the controls in Live view, Menu mode, Playback mode and Zoom mode. ▼Vol, ▲Vol • Move up or down in Menu mode. • Increase or decrease the volume in Live view. • Play and Pause in Playback mode (▲Vol). • Stop in Playback mode (▼Vol). • Move left in Menu mode. • Press this button to change viewing camera channel in Live view.
- Page 12 Manual Rec Press this button to start Manual Recording mode. Press again to stop recording. Power Button Turns monitor on and off. (Press and hold a few seconds longer to turn monitor off.) microSD microSD card slot. USB Port Uses USB cable to connect the monitor to the computer for remote access using Skype™.
-
Page 13: Camera
Camera FRONT BACK No Keys/Indicators Function Camera Antenna Sends signals to the monitor. Light sensor Measures light intensity to activate IR LEDs for night vision. Microphone Receives sounds from the area near the camera PIR sensor Detects motion within camera’s line of sight. Camera Lens Mechanism through which the cameras view surroundings and record images. -
Page 14: Lcd Display
LCD Display 2 3 4 5 6 7 Rec 055920-1.AVI 2013.11.25 06:34:24 No Keys/Indicators Function Signal Indicator Shows the camera’s signal strength. Signal Strength Indicator Warning Perfect None Good None Fair None None No Signal None Channel indicator Displays the current channel number. Press Displays the current channel number. - Page 15 Battery Indicates the amount of power remaining in the batteries. The icon displays when the battery is charging. The icon flickers when charging is nearly complete. Current Recording Displays when the monitor is recording video. Status The file name displays in hour/minute/second/ recording camera format (055920-1).
-
Page 16: Using The G14 Series
UsInG tHe G14 seRIes Viewing Modes In Live view, video displays live images from the camera in the following modes: • Quad mode: Monitor displays video from all cameras on a single screen in 4 quadrants. • Single mode: Monitor displays video from one camera at a time. • Scan mode: Monitor displays video from one camera at a time, but cycles through all cameras one by one. - Page 17 Set the date and time See System/Date&Time, page 20. Transfer a recording from Remove the memory card from the monitor the monitor’s SD card to the and insert it into an adaptor. computer. Insert the SD adaptor into your PC. Select a destination to store the files.
-
Page 18: System Menus
sYsteM MenUs Press MENU/OK button on the monitor to access the system menu options. Use the navigating buttons to navigate up/down/left/right in the menu, and press MENU/OK to confirm a setting. The Main menu options are: • Alert • Power Save • System • Camera • Record... -
Page 19: Power Save Menu
PoWeR sAVe MenU This option allows you to enable/disable the Power Save function. Enable this function to turn off the LCD backlight after 2 minutes of inactivity. The monitor “wakes up” if it detects motion or if you press any key. (Default = Off) sYsteM MenU These system setup options allow you to configure your system according to your personal preferences. - Page 20 Date & Time The Month option is automatically selected when you select Date & Time. 1. Press ▼Vol, ▲Vol to scroll through the options for that selection. 2. Press or to switch to another section of the date or time. Press▼Vol, ▲Vol to Press or to switch to another section of the date or time. Press▼Vol, ▲Vol to Press or to switch to another section of the date or time. Press▼Vol, ▲Vol to scroll through the options as before. 3. Press MENU/OK to save the current setting and return to the System screen. # Time displays in “Military”...
- Page 21 AV Out This option allows you to select the TV output format. (Default = PAL) PAL is the TV standard in Australia. 1. Press ▲Vol or ▼Vol to select either NTSC or PAL for this option. 2. Press MENU/OK; the System screen displays. Language This option allows you to select the display language for the system.
-
Page 22: Camera Menu
Default This option allows you to restore the G14 Series to factory settings. (Default = No) Camera pairings and date/time settings are not affected by a reset. 1. Press ▲Vol or ▼Vol to select either No or Yes for this option. 2. Press MENU/OK after you make your selection. The System screen displays. CAMeRA MenU This options allows you to pair the monitor with up to 4 cameras or turn on/off... -
Page 23: Record Menu
On/Off This option allows you to turn on or off an individual channel. The camera will remain powered on but the monitor will no longer receive video and audio. 1. Press ▲Vol or ▼Vol to select the channel whose status you want to change. 2. Press Press Press to change the setting (On or Off). to change the setting (On or Off). -
Page 24: Video Quality
Video Quality This option allows you to preset the output video quality for the unit. (Default = Low 320 × 240) 1. Press ▲Vol or ▼Vol to choose between higher quality (High 640x480) and lower quality (Low 320x240) video output. 2. Press MENU/OK. The Record screen displays. -
Page 25: Motion Sensitivity
Motion Sensitivity This option allows you to set the motion sensitivity for each channel individually. For example, if Camera 1 is an outside camera, you could set the sensitivity lower. This could stop the cameras from detecting small movements, such as the wind moving a tree branch. -
Page 26: Schedule Recording
Schedule Recording This option allows you to create a weekly recording schedule. This weeky schedule repeats until you change it. You can set each day separately, and you can also set that day’s schedule to turn on or off. For example, if you have camera 1 set to record your backyard every evening from 20:00 hours (8:00 PM) until 23:00 hours (11:00 PM) but you will be having a party in the backyard that evening, you can turn off that day’s scheduled recording. -
Page 27: Using Your System
UsInG YoUR sYsteM ReCoRDInG VIDeo Video records on the 4GB microSD card included in your package (the G14 Series will support up to a 32GB microSD card). When the receiver records (motion, schedule, manual, etc) all the buttons are disabled except MANUAL REC. The system responds normally after the recording has ended. -
Page 28: Deleting Recorded Files
Deleting Recorded files You can delete a specific recorded video file or an entire folder of files. A red “X” displays to the right of the folders and recorded video files on the Play File screen. 1. Press Press to highlight the red “X” beside the folder or file you want to delete and to highlight the red “X”... -
Page 29: Remote Viewing Using Skype™ Application
ReMote VIeWInG UsInG sKYPe™ APPLICAtIon To set up remote viewing via Skype™, first follow the procedures to view on your computer (page 28). # Be sure that the Skype™ account that is linked to the G14 Series is set to “Auto Answer”... -
Page 30: Using The Intercom
Using the Intercom The Intercom feature lets you talk to whomever is within camera range. 1. Make the camera you want to establish an intercom link with the full screen live view camera. 2. Press and hold Press and hold on the monitor. -
Page 31: Troubleshooting
tRoUBLesHootInG Problem Solution No picture • Check all camera connections. • Verify that the AC adaptor is plugged in. • Make sure the monitor is ON. • Make sure the camera is in range. The picture keeps dropping • Move the camera closer to the monitor. • Reposition the camera, monitor, or both to improve reception. -
Page 32: Specification
sPeCIfICAtIon MONITOR Operating frequency range 2.400 ~ 2.4835GHz RX sensitivity – 81dBm Spread spectrum FHSS Modulation type GFSK Data Rate 2 Mbps Communication range 150ms Line of Sight Display size/type 4.3” TFT LCD Resolution H: 480; V: 272 Power requirement 5.0V DC ±... - Page 33 CAMERA Operating frequency range 2.400 ~ 2.4835GHz TX power 15dBm (typical) Spread spectrum FHSS Modulation type GFSK Data Rate 2 Mbps Communication range 150ms Line of Sight Image sensor type 1/4” color CMOS image sensor (Manufacturer/Model #) Effective pixel H: 640; V: 480 Image processing MJPEG Image resolution...
-
Page 34: One-Year Limited Warranty
Warrantor The warrantor is either Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”) or Uniden New Zealand Limited (“Uniden NZ”) as the case may be. Terms of Warranty Uniden Aust/NZ warrants to the original retail purchaser only that the G14 Series (“the Product”), will be free from defects in materials and craftsmanship for the duration of... - Page 35 Product does not conform with this warranty, you should deliver the Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden at the addresses shown below. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
- Page 36 ©2013 Uniden Australia Pty Ltd/Uniden New Zealand Limited Printed in PRC...
