How you connect microphones depends on how you power your phone,
whether you have a one or two-phone setup, and if your phone is connected
to a Polycom HDX system or Polycom RealPresence Group system:
• For information on how to connect microphones to a single phone setup,
see Connecting Microphones to a Single Phone Setup
• For information on connecting microphones to a two-phone setup, see
Connecting Microphones to a Two-Phone Setup
• For information on attaching microphones to your phone when your
phone is connected to a Polycom HDX system or Polycom RealPresence
Group system, see
Connecting Microphones to a Single Phone Setup
You can attach up to two analog expansion microphones or three Polycom
Microphone Arrays to a single phone setup. You can daisy-chain two or three
Polycom Microphone Arrays. You cannot daisy-chain analog expansion
microphones.
When you connect Polycom Microphone Arrays to your phone, you must connect
Note
your phone to an AC power source and a Multi-Interface Module. For information on
connecting your phone using AC power and a Multi-Interface Module, see
Connecting Network and Power Sources
To connect microphones to a single phone setup:
Connect the free end of a microphone cable to one of the microphone
>>
connectors on your phone.
To attach two microphones, connect the free end of the other microphone
cable to the other microphone connector on your phone. (Or, if you are
attaching Polycom Microphone Arrays, you can daisy chain two
microphones to one microphone connector on your phone.)
If you want to attach three Polycom Microphone Arrays to your phone,
daisy chain three microphones to one microphone connector on your
phone. Or, daisy chain two microphones to one microphone connector,
and connect the third microphone to the other microphone connector on
your phone.
Connecting Microphones to a Two-Phone Setup
You can attach up to two analog expansion microphones or one Polycom
Microphone Array to a two-phone setup.
You can connect an analog expansion microphone to just one of the phones, or
connect an analog expansion microphone to each phone. You can connect a
Polycom Microphone Array to one phone only; you cannot connect a Polycom
Microphone Array to each phone.
Connecting Optional Video Components
on page 1-5.
Setting Up Your Phone
on page 1-9.
on page 1-9.
on page 1-13.
1 - 9
