A voice activated (VOX) intercom is included in the PAC24. This system has PS Engineering's exclusive
IntelliVox® circuitry that eliminates manual adjustments. The system contains six separate VOX mic cir-
cuits, and only opens the specific microphone channel in use.
The intercom system incorporates pilot isolate and crew modes, a monaural music input with "Soft Mute,"
and LED indicators transmit indications. Intercom control is through front panel-mounted knob and 3 po-
sition mode switch. A single volume controls intercom level for the pilot and copilot. Passenger headphone
volume is factory set, and adjusted in flight with headset-mounted volume controls. Passenger volume con-
trol is further adjustable through screwdriver access in the top of the unit. Intercom squelch is automatic.
The PAC24 is form fit and function compatible with the King Radio KMA24H, part number 066-1055-71,
and may be compatible with 066-1055-70.
1.4

APPROVAL BASIS -

FAA-TSO Approval.
The PAC24 Audio Selector Panels are FAA approved under TSO C50c (Audio Amplifiers). In addition,
the PAC24 is JAA-JTSO approved under LBA.N-O.10.510/003JTSO.
All systems comply with relevant portions of EUROCAE ED-14C/DO-160D (Environmental Conditions and Test
Procedures for Airborne Equipment), ED12B/DO-178B (Software Considerations for Airborne Equipment) and ED-
18/DO-214 (Audio Systems Characteristics and Minimum Operational Performance Standards for Aircraft Audio Sys-
tems).
NOTE: The recorder contained in Option 1 is not TSO-approved, and the installer must determine the relevant ap-
proval basis prior to installation. Contact PS Engineering for information regarding FAA approval.
Operation is subject to the following conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired opera-
tion.
1.5

SPECIFICATIONS

Audio Selector/Intercom:
APPLICABLE DOCUMENTS:
ENVIRONMENTAL Qualifications:
Temperature Range:
Operating:
Storage:
Altitude:
DIMENSIONS:
WEIGHT (With Rack & Connectors):
200-240-0010
PS Engineering
PAC24 Series Audio Selector Panel and Intercom System
Installation and Operator's Manual
TSO COMPLIANCE
C50c, Class A
RTCA/DO-214
RTCA/DO-160D
RTCA/DO-178B
B1ZCABSRXXXXXXZBBBATMXXE2XXX
-20ºC to +55ºC with short term operating at +70°C
-55ºC to +85ºC
Up to 50,000 feet in a non-pressurized area of the
cockpit.
Height: 1.3 in. (3.3 cm) Width: 6.25 in. (16.9 cm)
Depth: 6.8 in. (17.3 cm) behind panel
1.5 lb. (0.54 kg)
Page 1-2 Rev. 13, Sept. 2007
