PAC24 Installation Kit: 250-291-0000
PAC24 installation rack assembly
Molex Connector Shell w/key, 50 pin, key 17/18
Gold Plated Crimp Pins
4 40 X 7/16 screw w/nylon patch
Grounding bar
6-32 X 3/4 pan head Phillips screw
6-32 Nut Flat
6-32 Lock Nut
Cable Clamp
#6-32 x ½" Flat head Phillips screw
#6-32 Clip Nut
Parts identification sheet
1.7

EQUIPMENT REQUIRED BUT NOT SUPPLIED

a) Circuit Breaker: 1 ea. 3 amp
Cockpit Speaker, 4 Ω recommended
b)
Cabin or External Speaker 4 Ω recommended
c)
d) Headphone Jacks (as required)
e) Microphone Jacks (as required)
Headphones, 150 Ω as required
f)
g) Microphones, as required
h) Interconnect Wiring
1.8

LICENSE REQUIREMENTS

None
200-240-0010
PS Engineering
PAC24 Series Audio Selector Panel and Intercom System
Installation and Operator's Manual
Description
Page 1-4
Quantity Part
Number
1 475-240-0040
1 120-425-5002
50 425-001-0002
4 475-440-0009
1 430-007-0001
2 475-632-0038
2 475-632-0003
2 475-632-0004
1 625-001-0002
6 475-632-0012
6 475-630-0002
1 002-250-0240
