Sun Microsystems Sun Fire X4100 Service Manual page 243

SAS Topology Screen 5, Initiator Capabilities
********************************************************************************
* SAS Topology -- SAS1064
*
* SAS1064(02:03:00)
* * PHY 0
* * PHY 1
* * PHY 2
* * PHY 3
*
*
*
*
*
* Esc=Exit F1=Help
* Alt+D=Device Properties
********************************************************************************
TABLE F-5
Field
Device Identifier
Discovery Status
Device Info
Negotiated Link
Speed
Device Identifier
SEAGATE ST936701LSUN36G 0456
SEAGATE ST973401LSUN72G 0356
Alt+M=More Keys
Alt+E=Expander Properties
SAS Topology Screens Field Descriptions
Description
The ASCII device identifier string extracted from the device's inquiry
data.
The status of SAS topology discovery on this directly attached PHY
or on an expander. This field is only an indicator of an error being
encountered. For specific details and the error value, see the
Expander Properties page for expanders and the PHY Properties
page for directly attached PHYs.
Indicates whether a device is SAS or SATA, and whether the device
has been selected as the boot device.
(SATA is not supported on Sun Fire X4100 or Sun Fire X4200 servers
at this time.)
The negotiated link speed for this PHY, in Gbits/s. This field also
indicates whether the PHY has been disabled.
Appendix F
Initiator
Capabilities
Serial Attached SCSI BIOS Configuration Utility
*
*
*
*
*
*
*
*
*
*
*
*
*
*
F-13
