Removing Seat Cover - CYBEX ONYX 2011 Owner's Manual

Removing Seat Cover

1. First, remove canopy and items
from the storage basket.
2. Unhook both right and left seat
fabric hooks at top of seat.
3. Unsnap both right and left side seat
anchor straps from the frame.
4. Unhook both hook and loop straps under
the seat near the footrest on both sides.
5. Feed the central harness strap out of the
plastic housing from the bottom up.
6. Pull seat cover up and over the
adjustment strap button.
12
7. Release the shoulder straps
from the splitter plate located on
the back of the stroller under the
lower part of the seat cover.
8. From the front of the stroller, pull the
shoulder straps out of the seat fabric.
9. Feed shoulder straps, tongues,
and the harness buckle through
the slits in the seat cover.
10. Lift up and slide fabric seat off stroller frame.
11. To reassemble reverse this process.
eNSURe stroller frame and components
are out of children's reach.
Removing Seat Cover
13
