- Page 1 KT-380EE DX-174S 2-WAY RADIO VHF FM PROFESSIONAL TRANSCEIVER 136-175 MHz 5W INSTRUCTION MANUAL MANUALE DI ISTRUZIONI...
-
Page 2: Declaration Of Conformity
(to EC Directive 99/5-89/336-93/68-73/23) DECLARATION OF CONFORMITY With the present declaration, we certify that the following products : INTEK DX-174S comply with all the technical regulations applicable to the above mentioned products in accordance with the EC Directives 73/23/EEC, 89/336/EEC and 99/5/EC. -
Page 3: Table Of Contents
INTEK S.R.L. declines any responsibility concerning any modification of the product, made by the user or by a third party, after delivery of the product. -
Page 4: Notice
As regulations are usually subject to possible modifications, please check the current regulations in your country with your dealer or local supplier. INTEK does not take any responsibility for illegal use and operation of this product not in accordance with the regulation of the country where the product is used. -
Page 5: Unpacking And Checking Parts
Unpacking and Checking Parts - Supplied Accessories Unpacking and checking parts Carefully unpack the product. Please identify all the parts listed below, before wasting the packaging. If any part is missing or if the packaging shows any damage, please contact your dealer immediately. Supplied accessories Rubber flexible antenna with SMA connector 7.2V 1200mAh Li-Ion Rechargeable Battery Pack... -
Page 6: Preliminary Steps
Preliminary Steps Battery charging Connect the 230VAC adaptor charger to the desk type battery charger and to a 230VAC outlet. The Red Led will flash to confirm that the charger is powered. Insert the empty battery or the transceiver with the battery pack in the battery charger. - Page 7 Preliminary Steps To remove the battery To remove the battery, press the battery locker placed on the rear side of the radio and slide the battery away from the radio. Warning ! Please do not waste used batteries into the environment and do not trash them with the common garbage.
- Page 8 Preliminary Steps Install the external earset-microphone jack rubber cover. If an external earset-microphone is not used, please install the earset- microphone jack rubber cover. Install the earset-microphone jack rubber cover, by matching the three rubber tabs with the holes on the radio, as showed on the drawing. If the earset-microphone jack rubber cover is removed, radio will not be splash proof.
-
Page 9: Getting Acquainted With The Product
Getting Acquainted with the Product GETTING ACQUAINTED WITH THE PRODUCT Antenna Rubber flexible antenna with SMA connector. Rotary Switch Frequency, channel and functions selector. Power ON switch and volume control Switch on the transceiver turning the knob clockwise or counterclockwise to switch it off. To increase the volume, turn the knob clockwise or counterclockwise to decrease it. - Page 10 Getting Acquainted with the Product FUN Key Function key to quickly access several functions of the radio. 10. UP/DOWN Keys Channels and menu operation selection keys. Microphone Built-in microphone. 12. Speaker Built-in speaker. 13. RX/TX LED Indicator The LED indicator will light in green colour when the radio is receiving a signal and in red colour during transmission.
- Page 11 Getting Acquainted with the Product LCD DISPLAY Signal Digital Bar Meter Indicates the received signal strenght in the receive mode. CT Indication The CT indication is lighted when the CTCSS function is enabled. T Indication Not available on this model. DCS Indication The DCS indication is lighted when the DCS function is enabled.
-
Page 12: Getting Started
Getting Acquainted with the Product - Getting Started VOX Indication The VOX icon is lighted when the VOX function has been enabled. Frequency Reading (25-5-75). It shows the KHz decimal figures of the frequency. RF Digital Meter It indicates the transmitter RF output power. Dot Matrix Indication It provides full information on channel, frequency and all enabled functions. -
Page 13: Menu Operation
Menu Operation MENU OPERATION In stand-by status, press FUN (9) key to enter the menu. Press the UP/DOWN (10) keys to choose menu items. Channel Mode / Frequency Mode CHANNEL MODE Press the UP/DOWN (10) keys or use the rotary switch (2) to choose desired channel. SCAN --->... - Page 14 Menu Operation CT/DCS (CTCSS / DCS selection) In the stand-by status, press the FUN (9) key to enter menu page, then press the UP/DOWN (10) keys to confirm (you will see CT/DCS). Then press the MENU (5) key to enter. Press the UP/DOWN (10) keys to choose CTCSS or DCS.
-
Page 15: Menu Shortcut Keys
Menu Operation - Menu Shortcut Keys SQL : Squelch level setup In the stand-by status, press the FUN (9) key and then UP/DOWN (10) keys, and when the display shows SQL ?, press the MENU/CONFIRMATION (5) key to enter. Press the UP/DOWN (10) keys to choose the desired squelch level and confirm the selection by pressing the MENU/CONFIRMATION (5) key. -
Page 16: Specifications
Specifications - Optional Accessories SPECIFICATIONS General Frequency 136.000 - 174.9875 MHz Channels Channel spacing 12.5, 25 KHz DC input voltage 7.2 VDC Operating temperature -20/+55° Dimensions mm 58 x 120 x 35 Weight 235 gr. (with battery and antenna) Receiver Sensitivity (12dB Sinad) 0.16 µV Selectivity...
