Page 1: User Manual
ADP-215 USER MANUAL V.12.12 Lynx Pro Audio S.L. Valencia, Spain www.lynxproaudio.com - info@lynxproaudio.com... - Page 2 ADP-215 Class D Powered (bi-amplified) Integrated Digital Processing Internal temperature control Electronic protection High quality components Online monitoring available LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com -info@lynxproaudio.com...
- Page 3 CB SCHEME, IEC SYSTEM FOR CONFORMITY TESTING AND CERTIFICATION OF ELECTRICAL EQUIPMENT CE CERTIFICACTION, EUROPEAN PRODUCT This user manual is property of Lynx Pro Audio S.L. Any reproduction of this manual, by any means is strictly prohibited. Copyright 2012. All rights reserved.
-
Page 4: Table Of Contents
- CONFIGURING THE CABINET DSP OPTIONS PRESET LIST FIR FILTERS CONFIGURATION PANEL SELECT AND RUN PRESET - ONLINE CONTROL SYSTEM - CONFIGURING ETHERNET - SOFTWARE, RAINBOW ACOUSTICAL PREDICTION SOFTWARE FEATURES - ACCESSORIES - GUARANTEE LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com -info@lynxproaudio.com... - Page 5 Do not hang the cabinets from the handles or from any other part other than the designated hanging point. When flying this system please observe the technical and “Lynx On Stage” software data carefully. Never exceed the maximum safe working loads or ignore the instructions included within this manual.
-
Page 6: Specifications
ADP-215 INTRODUCTION To facilitate, correct and reliable use of the powered cabinet ADP-215 we have designed this instruction manual. Please read the manual carefully before proceeding to install the system. Please observe the technical data carefully and do not ignore the instructions included within this manual. -
Page 7: Back Panel
5.- USB. 6.- DSP CONTROL. 7.-ETHERNET (optional) CONNECTORS AND CONNECTIONS XLR AEREAL CONNECTORS Connect to input 1 Earth 2 Live(+) 3 Live(-) Connect to output 1 Earth 2 Live(+) 3 Live(-) LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com -info@lynxproaudio.com... - Page 8 N - Neutral CAUTION: Do not connect or disconnect the AC Power - Earth connectors under load. CONNECTION EXAMPLE: 6 ADP-215 CABINETS Connect to AC output Connect to AC output Connect to signal output CAUTION: DO NOT CONNECT OR DISCONNECT THE AC POWER CONNECTORS UNDER LOAD.
-
Page 9: Configuring The Cabinet Dsp Options
Finite Impulse Response (FIR) filters are used in the signal processing of the ADP-215 cabinet. FIR is a type of digital filter with linear phase characteristics. This frees system designers from the constraints of phase anomalies associated with analogue filters or their digital versions (IIR, Infinite Impulse Response). When properly used, FIR filtering can audibly improve a system’s impulse response and reduce crossover interference. -
Page 10: Configuration Panel
Once found, press OK (Fig2(3)) until the progress bar finishes (Fig3). The display will indicate “Loading DSP” (Fig4) Fig 3 Fig 4 Fig 2 Note: In case of a power cut, the DSP will save its last configuration when restarted. LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com -info@lynxproaudio.com... -
Page 11: Online Control System
ADP-215 ONLINE CONTROL SYSTEM Who is it for? Users of Self powered DSP incorporated Lynx Pro Audio Cabinets where the user has requested the cabinets be supplied with the Ethernet Module kit. What is it for? Obtain detailed information of cabinet behaviour and monitor the cabinet/s in real time. You can change the preset, gain, mute, polarity and phase. -
Page 12: Configuring Ethernet
ADP-215 CONFIGURING ETHERNET TO WORK WITH THE ADP-215 There are two possible ways to connect: 1.- Connecting through an ETHERNET SWITCH/HUB:: - You will need a normal CAT5 Cable. 2.- Connecting through a Wirless ETHERNET. Let us now proceed to configure the Ethernet network, setting the IP address of the computer as static. To do this go to: START >... - Page 13 Open the O.M.S Software and from the Initial Screen choose ETHERNET. It will open a different screen, as follows, there you can see your Network configuration, and the cabinets currently connected. LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com -info@lynxproaudio.com...
- Page 14 Remember there cannot be two devices with exactly the same IP address, the last set of three numbers has to be different and unique to each one of the devices. LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com -info@lynxproaudio.com...
- Page 15 Returning to the main screen, we can see each cabinet showing: Model, IP address and Name, as well as monitoring: RMS Level, Input Clip, Cabinet angulation, amplifier temperature and fan speed. LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com -info@lynxproaudio.com...
- Page 16 It will open the cmd.exe from where you can type the IPCONFIG command ( ipconfig + Enter), which will show your actual IP settings. Here we can see that this PC has IP set as 192.168.2.99. LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com -info@lynxproaudio.com...
- Page 17 If the IP is in use, the device will respond to the Ping, and we will obtain this information: You now have the Cabinets working in the ETHERNET Network Enviroment. LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com -info@lynxproaudio.com...
-
Page 18: Acoustical Prediction Software
The Rainbow software has been designed by and for sound technicians. Its aim is to help installers and users of Lynx products. This software is able to import WMF Vector Files with technical drawings and insert them directly into the prediction window and thus enabling real measurement predictions. -
Page 19: Features
- Coverage curves on the hearing zones. - Export of SPL Map and coverage curves on jpg or bmp format - Print project report (SPL prediction, flying points, weights, cabinet inclination, polarities, process aplied, EQ Curves…) LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com -info@lynxproaudio.com... -
Page 20: Accessories
The ADP series include some accessories for installation, rigging and transport. SC-FC2 Heavyweight install stud STK-218 Adaptor to stack ADP-215 over vertical LX-218S FD-ADP215 Nylon transport protection cover for the ADP-215 FD-ADP15NL Rain cover LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com -info@lynxproaudio.com... -
Page 21: Guarantee
Lynx Pro Audio S.L. In the case that the product could not be returned to the factory for checking and repairing, Lynx Pro Audio S.L.
