HST-3000
ADSL2+ Service Interface Module (SIM)
Highlights
• Test the technology, test the service,
improve the process
• Thoroughly qualifies ADSL2+ access
service: Attenuation, Noise Margin,
Bits per Tone, Actual bit rate,
Maximum bit rate, % Capacity, and
Estimated Loop Length
• Backward compatible to ADSL1
• Supports RE-ADSL (Reach
Extended-ADSL2)
• Data layer test options: PPPoE,
PPPoA, IPoA, FTP throughput, and
Web Browser
• Test interfaces: ADSL2+ 2-wire and
Ethernet 10/100
• Test modes: Terminate, Through, and
TE (Terminal Equipment)
• Flexible, modular design allows you
to buy what you need now and easily
upgrade later in the field
:
www.jdsu.com
WEBSITE
ACTERNA TEST & MEASUREMENT SOLUTIONS
In one lightweight, robust, battery operated tester, the JDSU HST-3000 offers
more testing power than any other handheld tester on the market. Its scalable,
modular design cost-effectively addresses today's needs. Upgrade later in the field
to meet emerging requirements through plug-in hardware modules and software
options.
JDSU's HST-3000 ADSL2+ SIM delivers comprehensive ADSL test support
including ADSL1, ADSL2, and ADSL2+ in one module. Optional data service test
support includes: PPPoE, PPPoA, IPoA, Bridged Ethernet, DNS client, DHCP
client and server, as well as FTP throughput, Web Browser, IP PING, and IP Trace
Route. Test modes include: Terminate Mode (ADSL2+ modem emulation),
Through mode (ADSL2+ to Ethernet), and TE mode (Ethernet). With a simple to
use GUI, the ability to store multiple configurations and auto test routines,
ADSL2+ service provisioning and troubleshooting becomes efficient and
thorough. Using scripting features of the HST, specific test scenarios can be
consistently performed. Using the results storage and export features of the
HST-3000, key ADSL2+ line parameters can be captured for benchmarking and
later used in trouble resolution.

Advertisement

loading

Summary of Contents for JDS Uniphase IP Video Test Option HST-3000

  • Page 1 HST-3000 ADSL2+ Service Interface Module (SIM) Highlights • Test the technology, test the service, improve the process • Thoroughly qualifies ADSL2+ access service: Attenuation, Noise Margin, Bits per Tone, Actual bit rate, Maximum bit rate, % Capacity, and Estimated Loop Length •...
  • Page 2 Test the Technology – Max bit rate – Actual bit rate – Loop attenuation – Noise Margin – Percent (%) capacity – Bits per tone – Far end DELT stats – Estimated loop length Test the Service – Data PPPoE, PPPoA, IPoA, Bridged Ethernet –...
