JDS Uniphase HST-3000 Product Manual

HST-3000
ISDN BRI Service Interface Module (SIM)
:
www.jdsu.com/test
WEBSITE
COMMUNICATIONS TEST & MEASUREMENT SOLUTIONS
• Emulation of the NT1, NT1/TE, and TE for testing voice,
Key Features
56/64K data, and 3.1K audio call types on U interface
• U monitor capability allows bi-directional monitoring
of in-service D-channel messages
• Auto SPID feature allows technicians to automatically
assign SPID values
• Enables IDSL service pre-qualification with 128 K and
144 K BER testing
• Layer 1, 2, and 3 results, including plain English decodes
of D-channel cause codes
The HST-3000 is a powerful and versatile handheld solution that tests ISDN BRI,
copper, T1, and ISDN PRI. Hand-held, rugged, and easy-to-use, the HST-3000 is
ideal for field use. Its modular design provides a scalable, all-in-one solution for
testing ISDN BRI, as well as thorough testing of the facilities over which it is
provided.
ISDN BRI provides enhanced network services to many residential and small
business customers as well as a significant revenue stream for service providers.
Not only is installation and maintenance of ISDN BRI more complex than POTS,
but providers are often struggling daily to meet tighter deadlines with reduced
budgets and smaller workforces. To meet these challenges, an easy-to-use, versatile
test solution is required that helps reduce failures and repeat troubles while
improving efficiency.
Equipped with the ISDN BRI option, the HST-3000 is ideal for the installation
and troubleshooting of ISDN BRI circuits. As a field tool, the HST-3000 can place
or receive calls to verify switch translations. As a Central Office (CO) tool, tech-
nicians can verify pair assignments, service activation, and service translations.
The HST-3000 also offers an IDSL BERT mode to test B1, B1, 2B or 2B+D config-
urations to verify service before delivery to the customer.
Compact and rugged for field technicians, the HST-3000 can be used in all
conditions, from inside an office environment to a noisy, wet outdoor span
repeater. The HST-3000 also boasts automated setups and advanced features that
ensure consistent adherence to service provider methods and procedures. Each
HST-3000 is built to order and can easily be field-upgraded with new modules
and software as application and technology needs change.
