LOCATION OF MAIN COMPONENTS

The following figure illustrates the main external components of the printer.
1
Figure 1 - 2 Location of main external components
1 Cover
2 Display
3 Console
4 Rear slot
5 Mains connector cable
The following figure illustrates the main internal components of the printer.
1
7
Figure 1 - 3 Position of main internal components
1 Printhead
2 Carriage transport motor
3 Upper part of mechanical assembly
4 Magnetic options board
1-4
2
3
9
10
6
7
8
9
10
2
5
6
7
Service Manual
4
8
7
USB interface connector
Parallel interface connector
Standard serial interface connector
Front slot
ON/OFF switch
3
6
View without casing
Motherboard
Power supply unit
Services motor
5
6
4
5
XZAC4219-05
