MC-SERIES
S E R V I C E
M A N U A L
For all MC-Series models manufactured from January 2001
Part No. 32Z3329e Issue No. 5
CAUTION MICROWAVE EMISSIONS
DO NOT BECOME EXPOSED TO EMISSIONS FROM THE MICROWAVE
GENERATOR OR PARTS CONDUCTING MICROWAVE ENERGY
MC Series Ovens 32Z3329 Issue 4
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC-SERIES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Merrychef MC-SERIES

  • Page 1 MC-SERIES S E R V I C E M A N U A L For all MC-Series models manufactured from January 2001 Part No. 32Z3329e Issue No. 5 CAUTION MICROWAVE EMISSIONS DO NOT BECOME EXPOSED TO EMISSIONS FROM THE MICROWAVE...
  • Page 2: Table Of Contents

    Door Servicing ..............14 Interlock Details ..............15 Membrane Panel Circuit ............16 Input Wiring Details ............. 17 Part Number Identification List ........18-19 Wiring Diagram MC-series ..........20 Manual Corrections and Modifications ........ 21 Merrychef Limited, Station Road West, Ash Vale, Aldershot,...
  • Page 3: Safety Code

    SAFETY CODE This manual is designed to assist engineers who have been on a recognised product familiarisation and training course run by Merrychef Limited. It has been prepared to offer technical guidance for the Merrychef MC Series Commercial Microwave Ovens.
  • Page 4: Product Specifications Mc Series

    PRODUCT SPECIFICATIONS Model N . MC-Seies Model Number Specification: Model N . + Voltage + Frequency + Country Voltage 220-230V a.c. 230-240V a.c. Frequency 50 Hz 60 Hz Country UK = United Kingdom EX = Export Power Requirements MC1000C45UK 230-240V ac 50 Hz 13.0A Single Phase 2 Wire + Earth MC1000C25EX 220-230V ac 50 Hz 14.2A Single Phase 2 Wire + Earth MC1400C45UK...
  • Page 5: Installation Instructions

    INSTALLATION INSTRUCTIONS MC Series Ovens Power Supply Requirements The MC–Series oven should be connected to a suitable electricity supply, which can cope with the switching-on surge that occurs with certain types of catering equipment, such as microwaves. Because of this requirement, we strongly recommend that a separate, suitably rated supply is installed for the oven.
  • Page 6: Error Codes And Diagnostics

    Error Codes and Diagnostics The MC–Series oven will identify some of the most common problems by flashing an error message code in the time display window. These are the error messages, and suggestions for repairing them. Door not fully shut. Close door fully.
  • Page 7: A - Power Output Testing To Bs En 60335-2-25:1996

    Procedure A - Power Output Test in accordance with BS EN 60335-2-25:1996 Annex AA This test is given in the BSI test standard for microwave ovens. It is reproduced below - not so that you can follow it, but to show you why it is impractical in normal conditions. A simplified procedure, which gives a good approximation to the BSI power output, is given in Procedure B which follows.
  • Page 8: B - Power Output Testing

    Procedure B - Simplified Power Test You will need: A thermometer capable of reading to ±0.1°C. A Polypropylene tray approximately 200 mm x 200 mm. A measuring jug. A calculator. Water which is at a temperature of 10°C ± 2°C. 1 Measure 1 litre of cold water into the tray using the measuring jug.
  • Page 9: D - High Voltage Capacitor Test

    Procedure D - High Voltage Capacitor Test You will need: A Digital Multi-meter (D.M.M.) A Megger or similar resistance meter using 500V d.c. 1 Isolate the oven from the mains supply. WARNING: High voltages and large currents are present at the High Voltage Capacitor. It is very dangerous to work near this part when the oven is on.
  • Page 10: F - Interlock Operation

    DOOR INTERLOCK OPERATION Door Interlock Operation The door on the oven is monitored by four microswitches. Three of these are used in the conventional “Primary, Secondary and Monitor” switch arrangement shown below, while the fourth is a low-voltage switch linked directly to the control circuitry. MC–...
  • Page 11: Exploded View Mc Series

    Exploded View – MC Series Note: Model MC1000 has only one Magnetron assembly parts 51, 61 MC Series Ovens 32Z3329 Issue 4 Page 11...
  • Page 12: Door Assembly

    Door Assembly MC Series Ovens 32Z3329 Issue 4 Page 12...
  • Page 13: Door Replacement And Adjustment

    Door Replacement and Door Adjustment DOOR REPLACEMENT Remove four screws holding the Upper and Lower Hinge Plate [14] to the oven cavity. Remove Door Assembly [80] by pulling it forward. On re-installing new door assembly, secure the upper and lower oven hinges with the four mounting screws to the oven cavity.
  • Page 14: Door Servicing

    Door Servicing CHOKE COVER REMOVAL 1. Insert a flat type screw driver into the gap between the Choke Cover [16] and Door Body [7] as shown below to free the engaging clips. A protective piece of tape should be used so as not to damage the door panel.
  • Page 15: Interlock Details

    Door Interlock Details MC Series Ovens 32Z3329 Issue 4 Page 15...
  • Page 16: Membrane Panel Circuit

    Membrane Panel Circuit You will need: A Digital Multi-meter (D.M.M.) Procedure: 1. Isolate the oven from the mains supply. 2. Remove the Logic Assembly from the Control Panel Housing. 3. Unplug the membrane “tail” from the Logic PCB Assembly. 4. Using a D.M.M., check for continuity between the correct terminals when the pads are pressed.
  • Page 17: Input Wiring Details

    INPUT WIRING DETAILS MC Series Ovens 32Z3329 Issue 4 Page 17...
  • Page 18: Part Number Identification List

    30M0015 Choke Cover 30M0016 30M0016 30M0016 Control Pnl Cover ( see note 1.) 30M0017 30M0017 30M0017 Note 1. Part 17 supplied as MC-Series Membrane 40M0956 40M0956 40M0956 MC 1800, remove Display Screen 30M0019 30M0019 30M0019 label for MC1000 & MC1400...
  • Page 19 Part Number Identification Chart: MC series ovens Description MC1000 MC1400 MC1800 Part No Part No Part No Rear Air Guide 30M0046 30M0046 30M0046 Upper Air Duct 30M0047 30M0047 30M0047 Cooling Fan Assembly 30M0048 30M0048 30M0048 Gold Resistor 30Z0283 30Z0283 30Z0283 Magnetron Thermostat 30M0051 30M0051...
  • Page 20: Wiring Diagram Mc-Series

    CIRCUIT DIAGRAM: MC Series ovens MC Series Ovens 32Z3329 Issue 4 Page 20...
  • Page 21: Manual Corrections And Modifications

    Address Page on which error occurs (if applicable) - MC Series: Description of error Suggestion for improvement to manual Please return this form to: Engineering Department Merrychef Ltd Station Road West Ash Vale Aldershot Hampshire GU12 5XA Or Fax it on:...
