- Page 1 THE HW-19 JR TURNTABLE SETUP AND INSTRUCTION MANUAL VPI INDUSTRIES INC., 77 CLIFFWOOD AVE #3B, CLIFFWOOD N.J. 07721 PHONE: 732-583-6895 EMAIL: SALES@VPIINDUSTRIES.COM www.vpiindustries.com...
- Page 2 Save the carton and all internal fillers and plastic bags. If you should ever need to carry or ship the HW-19 JR any distance, there is much less chance of it suffering damage in transit if it is properly packed in its original carton.
- Page 3 diameter) groove. Replace the Motor Cover Plate. Make sure each post has a lock washer atop it before putting the Cover Plate in place. Making the caps finger-tight is all that is required. MOUNTING THE TONEARM If you have a pre-cut arm board: Confirm that it is the correct board for the arm you are mounting.
- Page 4 FINAL ASSEMBLY Place the dustcover on the JR by slipping the hinge flanges into the sockets on the rear of the base. Close the cover. Each of its front corners should rest on one of the small round pads on the base’s front corners. If necessary, push gently on the front of the cover until it does so.
- Page 5 Under most circumstances, you will then be able to walk around while a record is playing with out the arm hopping around. Use of the VPI SDS is strongly recommended (Commercial Message!). It is our experience that a couple of benefits are derived. First, the SDS isolates the turntable’s motor from the incoming electric line providing ultra-stable line voltage and frequency.
- Page 6 MAINTENANCE The drive belt on the HW-19 JR is made of pyrothane and, under ordinary conditions, will provide long service. Dusting the belt every three months with talcum powder will provide for a smoother start up and turn off. For optimum performance we recommend installing a new drive belt every two years.
- Page 7 (3) years from the date of purchase by the original retail purchaser. VPI’s sole obligation under this warranty is limited to the repair or replacement, at VPI’s option, of any part(s) found to be defective. VPI’s obligation to repair or replace defective parts is the purchaser’s sole and exclusive remedy, and VPI shall not be liable for any direct or indirect injury and/or property damage arising out of the use of the product or defect in or failure of the product.
