Environmental; Ground; Power Input; Battery Standby - Simplex 4004 Installation & Operation Instructions

Environmental

Ground

Power Input

Battery Standby

4004 System Features

The 4004 is designed to operate in the following conditions:
•
32 - 120° F /0 - 49° C
•
UL - 85% relative humidity (non-condensing)
ULC - 93% relative humidity (non-condensing)
The 4004 FACP must be grounded properly. Readings of less than 0.70 VAC
must be measured between ground and neutral. A system ground needs to be
provided for Earth Detection and transient protection devices. This connection
must be made to an approved, dedicated Earth connection per NFPA 70, Article
250, and NFPA 78. To ground the 4004, connect a 12 AWG copper ground
wire from safety ground (electrical distribution panel) to the green grounding
screw on the FACP.
The 4004 system is designed for either 120 VAC, 60 Hz or 220/240VAC, 50/60 Hz.
The battery standby provides for power loss connections. The batteries mount in
the 4004 control panel and provide at least 60 hours of standby operation for a
fully configured system.
Note: 60 hours of standby operation is based on using 10 Ah batteries, without
four-wire detectors or other non-alarm loads attached to the system,
followed by five minutes in alarm. A fully configured system using 6.2
Ah batteries, without four-wire detectors or other non-alarm loads
attached to the system, provides at least 24 hours of standby operation,
followed by five minutes in alarm.
•
Expandable from two to a maximum of 8-IDCs
•
2 Notification Appliance Circuits (NACs)
•
4 Amps of Power to meet ADA Requirements
•
Surface or Semi-Flush Installation
•
Single Piece Chassis
•
Zone (IDC) Disconnect Switches with Abort Enable Features
•
Alarm Output Disconnect Switch
•
One Person Walk Test
•
Chronological Event Display
•
Indicator (Lamp) Test Feature
•
Low and Depleted Battery Detection
•
Active Status Reminder
•
Non-volatile Memory
•
5-IDC Point Type Selections
•
Six Alarm Silence Inhibit Timer Selections
•
Four Auto-Silence Timer Selections
•
Four Coded Signal Selections
•
Available with Optional
- City Circuits
- Class A (Style D/Style Z) Converters
- Full Function Remote Annunciator Interface
- Simplex 4003 Voice Control Panel and 4009 NAC Extender
1-2
