GB
Contents
1
Technical data ________________________________________________________ 31
2
Declaration of conformity _______________________________________________ 33
3
Appliance overview_____________________________________________________ 33
3.1
Overview of display _____________________________________________________ 37
3.1.1
Display weight ______________________________________________________________ 38
3.1.2
Display basic price ___________________________________________________________ 38
3.1.3
Display sales price____________________________________________________________ 38
3.2
Keyboard overview _____________________________________________________ 39
4
Basic Information (General) _____________________________________________ 40
4.1
Proper use _____________________________________________________________ 40
4.2
Improper Use __________________________________________________________ 40
4.3
Warranty _____________________________________________________________ 40
4.4
Monitoring of Test Resources _____________________________________________ 41
5
Basic Safety Precautions ________________________________________________ 41
5.1
Pay attention to the instructions in the Operation Manual _____________________ 41
5.2
Personnel training ______________________________________________________ 41
6
Transport and storage __________________________________________________ 41
6.1
Testing upon acceptance _________________________________________________ 41
6.2
Packaging _____________________________________________________________ 41
7
Unpacking, Setup and Commissioning _____________________________________ 42
7.1
Installation Site, Location of Use __________________________________________ 42
7.2
Unpacking_____________________________________________________________ 42
7.2.1
Setup ______________________________________________________________________ 42
7.2.2
Scope of delivery ____________________________________________________________ 43
7.3
Mains connection _______________________________________________________ 43
7.4
Battery power supply____________________________________________________ 43
7.5
Initial Commissioning ___________________________________________________ 43
7.6
Adjustment ____________________________________________________________ 44
7.7
Verification ____________________________________________________________ 46
7.7.1
Jumper and seals _____________________________________________________________ 47
KERN RPB
Version 1.0 12/2005
Operating Manual
Price calculating balance
Advertisement
Table of Contents
Related Manuals for KERN RPB 6K2M
Summary of Contents for KERN RPB 6K2M
-
Page 1: Table Of Contents
KERN RPB Version 1.0 12/2005 Operating Manual Price calculating balance Contents Technical data ________________________________________________________ 31 Declaration of conformity _______________________________________________ 33 Appliance overview_____________________________________________________ 33 Overview of display _____________________________________________________ 37 3.1.1 Display weight ______________________________________________________________ 38 3.1.2 Display basic price ___________________________________________________________ 38 3.1.3... - Page 2 Operation ____________________________________________________________ 48 Switch on/off and set zero ________________________________________________ 48 Simple weighing ________________________________________________________ 48 Weighing with taring ____________________________________________________ 49 Weighing with price determination ________________________________________ 50 8.4.1 Manual input of a basic price ___________________________________________________ 50 8.4.2 Saving and calling up a basic price _______________________________________________ 50 AUTO CLEAR _________________________________________________________ 52 Display background illumination _________________________________________ 52 AUTO SLEEP-function _______________________________________________ 53...
-
Page 3: Technical Data
1 Technical data KERN RPB 6K2M RPB 6K2HM RPB 15K5M Readability (d) Weighing range (max) 6 kg 6 kg 15 kg Minimum load 40 g 40 g 100 g Verification value Verification class Reproducibility Linearity ± 4 g ± 4 g ±... - Page 4 KERN RPB 15K5HM RPB 30K10M RPB 30K10HM Readability (d) 10 g 10 g Weighing range (max) 15 kg 30 kg 30 kg Minimum load 100 g 200 g 200 g Verification value 10 g 10 g Verification class Reproducibility 10 g...
-
Page 5: Declaration Of Conformity
KERN RPB Mark applied EU Directive Standards 89/336/EEC EMC EN 50081-1 EN 50082-1 73/23/EEC Low Voltage EN 60950 Date: 27.12.2005 Signature: Gottl. KERN & Sohn GmbH Management Gottl. KERN & Sohn GmbH, Ziegelei 1, D-72336 Balingen, Tel. +49-[0]7433/9933-0,Fax +49-[0]7433/9933-149 RPB-BA-defsi-0510... - Page 6 Model: KERN RPB EU Directive Standards EC-type-approval certificate no. Issued by 90/384/EEC EN 45501 T6860 Date: 27.12.2005 Signature: Gottl. KERN & Sohn GmbH Management Gottl. KERN & Sohn GmbH, Ziegelei 1, D-72336 Balingen, Tel. +49-07433/9933-0,Fax +49-074433/9933-149 RPB-BA-defsi-0510...
-
Page 7: Appliance Overview
3 Appliance overview Models without vertical display: Air bubble Battery Mains cable connection compartment ON/OFF switch Second display on customer's side RPB-BA-defsi-0510... - Page 8 Models with vertical display: Mains cable connection Air bubble Rotatable vertical display ON/OFF switch Backside RPB-BA-defsi-0510...
-
Page 9: Overview Of Display
3.1 Overview of display Operator display balance: Weight Basic price Sales price Vertical display for models with tripod: Weight Basic price Sales price RPB-BA-defsi-0510... -
Page 10: Display Weight
3.1.1 Display weight Here, the weight of your goods is displayed. The arrows above the symbols show: Battery very low Net weight Stability display Zeroing display 3.1.2 Display basic price Here, enter your basic price in €/kg or €/100 g via keyboard. The basic price can be switched to €/kg or €/100 g. -
Page 11: Keyboard Overview
3.2 Keyboard overview Choice Function • Number keys, enter basic price /PLU • Delete key • Saving and calling up the three most frequently used PLU values • Saving and calling up the other PLU values • Taring key • Save •... -
Page 12: Basic Information (General)
The balance may only be used according to the described conditions. Other areas of use must be released by KERN in writing. 4.3 Warranty Warranty claims shall be voided in case •... -
Page 13: Monitoring Of Test Resources
Infor- mation is available on KERN’s home page (www.kern-sohn.com with regard to the monitoring of balance test substances and the test weights required for this. In KERN’s accredited DKD calibration laboratory test weights and balances may be... -
Page 14: Unpacking, Setup And Commissioning
7 Unpacking, Setup and Commissioning 7.1 Installation Site, Location of Use The balances are designed in a way that reliable weighing results are achieved in common conditions of use. You will work accurately and fast, if you select the right location for your balance. Therefore, observe the following for the installation site: •... -
Page 15: Scope Of Delivery
7.2.2 Scope of delivery Serial accessories: • Balance • Weighing plate • Power cable • Protective cover • Battery • Operating Manual 7.3 Mains connection Power supply is carried out by means of the supplied power cable (220 V, 50-60 Hz). 7.4 Battery power supply The battery is charged via the internal power supply. -
Page 16: Adjustment
7.6 Adjustment As the acceleration value due to gravity is not the same at every location on earth, each balance must be coordinated - in compliance with the underlying physical weighing principle - to the existing acceleration due to gravity at its place of location (only if the balance has not already been adjusted to the location in the factory). - Page 17 The required adjustment weight is displayed: LQAD 6 HLOS Zero point will be saved. Carefully place adjusting weight in the centre of the weighing plate ---- The adjustment process is started. SPAnPASS The adjustment process has been success- fully completed. CAL F1 Remove adjustment weight, in case of an adjustment error or incorrect adjustment...
-
Page 18: Verification
7.7 Verification General introduction: According to EU directive 90/384/EEC balances must be officially verified if they are used as follows (legally controlled area): a) For commercial transactions if the price of goods is determined by weighing b) For the production of medicines in pharmacies as well as for analyses in the medical and pharmaceutical laboratory c) For official purposes. -
Page 19: Jumper And Seals
7.7.1 Jumper and seals 1. Bottom of the balance Access to conductor plate: • Place your balance upside down • Remove seal • For verified balances, the jumper is on a pin • For adjustment the jumper must be set on both pins Position jumper for adjustment Position of seal... -
Page 20: Operation
8 Operation 8.1 Switch on/off and set zero Operation Display 1. Switch on balance As soon as the weight display shows "0" Press ON/OFF switch and hold briefly (at in all the three display windows your bal- the bottom right side of the balance) ance is ready to weigh. -
Page 21: Weighing With Taring
8.3 Weighing with taring The dead weight of any weighing container may be tared away by pressing a button, so that the following weighings show the net weight of the goods to be weighed. Operation Display Place empty tare container on the weigh- ing plate. -
Page 22: Weighing With Price Determination
8.4 Weighing with price determination As soon as the goods to be weighed are placed on the balance and the basic price has been set the price is calculated automatically and displayed in the provided field. 8.4.1 Manual input of a basic price Display Operation Weight [kg]... - Page 23 Saving a basic price via the M4-key: Display Operation Weight [kg] Basic price Price [ € ] Enter your basic price via keyboard, either in €/kg or 0.000 2.00 0.00 in €/100 g SAWE 3 sec. Enter the numbers of your desired PLU or leave the value 00 for [PLU4] The basic price is saved at...
-
Page 24: Auto Clear
8.5 AUTO CLEAR Use the key to activate the AUTO-CLEAR function; at the same time the arrow above "AUTO CLEAR" appears in the display. Remove the goods to be weighed from the weighing plate, this way the set basic price will remain. For activated AUTO-CLEAR function the set basic price is automatically deleted when the balance is unloaded. -
Page 25: Auto Sleep-Function
10 AUTO SLEEP-function With activated AUTO SLEEP function the balance will go into sleep mode after a de- fined period of time if the load is not changed or no key is pressed. Automatic activa- tion of the display through load change or if any key is pressed. Operation Display Switch on balance and press the... -
Page 26: Service, Maintenance, Disposal
Spilled weighing goods must be removed immediately. 11.2 Service, maintenance The appliance may only be opened by trained service technicians who are authorized by KERN. Before opening, disconnect from power supply. 11.3 Disposal Disposal of packaging and appliance must be carried out by operator according to valid national or regional law of the location where the appliance is used. -
Page 27: Instant Help
12 Instant help In case of an error in the program process, briefly turn off the balance and disconnect from power supply. The weighing process must then be restarted from the beginning. Fault Possible cause • The balance is not switched on. The displayed weight does not glow.
