Viking Installation Guide
®
Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
For product information,
call 1-888-VIKING1 (845-4641)
or visit the Viking Web site at
vikingrange.com
Professional Freestanding Dual Fuel Ranges
F20533F EN
(121712)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Professional Freestanding Dual Fuel Ranges and is the answer not in the manual?

Questions and answers

Summary of Contents for Viking Professional Freestanding Dual Fuel Ranges

  • Page 1 Viking Installation Guide ® Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-VIKING1 (845-4641) or visit the Viking Web site at vikingrange.com Professional Freestanding Dual Fuel Ranges F20533F EN (121712)
  • Page 2: Table Of Contents

    Table of Contents IMPORTANT– Read and Follow! Warnings & Important Safety Instructions_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 3 •...
  • Page 3 IMPORTANT– Read and Follow! DANGER DANGER DANGER WARNING Moving hazard. Gas leak hazard. Chemical hazard. Fire/explosion hazard. IF THE INFORMATION IN To avoid risk of severe To avoid risk of personal injury To avoid risk of property THIS MANUAL IS NOT personal injury;...
  • Page 4: Dimensions

    Dimensions Dimensions Dual Fuel 30”, 36”, 48” and 60” W. Ranges Dual Fuel 30”, 36”, 48” and 60” W. Ranges 28-1/16” (71.2 cm) 1-5/8” (4.1 cm) ( 1 5 ” 2 . 4 26-7/16” (67.2 cm) 1” - 7 / (2.5 cm) ( 1 2 8 ”...
  • Page 5: Specifications

    Specifications Specifications Dual Fuel 30” and 36” W. Ranges Dual Fuel 48” and 60” W. Ranges Description 30” W. Models 36” W. Models Description 48” W. Models 60” W. Models Overall width 47-7/8” 60” Overall width 29-7/8” 35-7/8” (75.9 cm) (91.1 cm) (121.6 cm) (152.4 cm)
  • Page 6: Clearance Dimensions (Proximity To Cabinets)

    Clearance Dimensions Clearance Dimensions (Proximity to Cabinets) (Wood/Composite Overlay) • This range may be installed directly CAUTION adjacent to existing 36” (91.4 cm) high The bottom of a standard hood base cabinets. should be 30” (76.2 cm) min. to To prevent possible damage to cabinets / C o 36”...
  • Page 7: Electrical & Gas Requirements

    (7.0 cm) or moisture. The range is designed specifically for 2” dia. • Viking Range Corporation will NOT (5.1 cm) natural gas or liquid propane (LP) gas. warranty any problems resulting from GFI Before beginning installation verify that outlets which are not installed properly or...
  • Page 8: General Information

    Viking Authorized used, then rinsed and wiped dry. Solutions Service Center before continuing operation.
  • Page 9: Leg Installation

    Leg Installation Electrical Connection (3-wire) Note: If you have a 4-wire connection, see following section for 4-wire connection instructions. WARNING WARNING Electrical shock hazard. Electrical shock hazard. To avoid risk or electrical To avoid risk of electrical shock, shock, personal injury or death; personal injury or death;...
  • Page 10: Electrical Connection (3 Wire)

    Electrical Connection (3-wire) Electrical Connection (4-wire) (cont.) WARNING WARNING Electrical shock hazard. Electrical shock hazard. To avoid risk or electrical To avoid risk of electrical shock, shock, personal injury or death; personal injury or death; verify grounding product to the frame your appliance has been of the unit may or may not be permitted properly grounded in accordance with...
  • Page 11: Electrical Connection (4 Wire)

    Electrical Connection (4-wire) Leveling/Adjustments/Alignment (cont.) Feed supply cord up through hole in bottom Attach ground lead (green) Measure the four corners in cutout area to verify if For uneven or sloped floors, level unit with metal shims flooring is level. of range back.
  • Page 12: Connecting Gas & Electrical

    Leveling/Adjustments/Alignments Anti-tip Device Installation (cont.) (cont.) Attach bracket with Set the high corner of range so that the top of side trim is Mark and drill holes where bracket will be located. mounting hardware provided. 3/8” (0.95 cm) above countertop. Level range to high corner. Connecting Gas &...
  • Page 13: Standoff Bracket Removal

    Standoff Bracket Removal (48” and 60”W. VDSC Models Only) Door Replacement and Adjustment Note: Standoff brackets can only be removed if range is installed against a NON-COMBUSTIBLE wall. DANGER FIRE HAZARD Standoff brackets provide a 3/4” barrier between back of range and rear wall.
  • Page 14: Final Preparation

    DO NOT use If buildup occurs, DO NOT use steel wool, a metal knife, spatula, or any other Contact Viking Range Corporation, 1-888-VIKING1 (845-4641), for the nearest service parts abrasive cloths, cleansers, or powders! material tool to scrape stainless steel!
