PARTS LIST

CAUTION
!
! The parts identified by the
the safety .
! The parts not indicated in this Parts List and those which are filled with lines in the Parts No. columns will not be supplied.
! P. W. Board Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied.
ABBREVIATIONS OF RESISTORS, CAPACITORS AND TOLERANCES
RESISTORS
C R Carbon Resistor
F R Fusible Resistor
P R Plate Resistor
V R
Variable Resisto
HV R High Voltage Resistor
MF R Metal Film Resistor
MG R Metal Glazed Resistor
MP R Metal Plate Resistor
OM R Metal Oxide Film Resistor
CMF R Coating Metal Film Resistor
UNF R Non-Flammable Resistor
CH V R Chip Variable Resistor
CH MG R Chip Metal Glazed Resistor
COMP. R Composition Resistor
Linear Positive Temperature Coefficient
LPTC R
Resistor
F G
± 1% ± 2%
symbol are important for the safety. Whenever replacing these parts, be sure to use specified ones to secure
r
TOLERANCES
J K M
± 5% ± 10% ± 20%
CAPACITORS
C CAP. Ceramic Capacitor
E CAP. Electrolytic Capacitor
M CAP. Mylar Capacitor
HV CAP. High Voltage Capacitor
MF CAP. Metalized Film Capacitor
MM CAP. Metalized Mylar Capacitor
MP CAP. Metalized Polystyrol Capacitor
PP CAP. Polypropylene Capacitor
.
Polystyrol Capacitor
PS CAP
TF CAP. Thin Film Capacitor
MPP CAP. Metalized Polypropylene Capacitor
TAN. CAP. Tantalum Capacitor
CH C CAP. Chip Ceramic Capacitor
BP E CAP. Bi-Polar Electrolytic Capacitor
CH AL E CAP. Chip Aluminum Electrolytic Capacitor
Chip Aluminum Bi-Polar Capacitor
CH AL BP CAP.
Chip Tantalum Electrolytic Capacitor
CH TAN. E CAP.
Chip Tantalum Bi-Polar Electrolytic Capacitor
CH AL BP E CAP.
N R
+30%
± 30%
-10%
No.51733
AV-32WL1EU
AV-32WL1EI
AV-32WL1EK
H Z P
+50% +80% +100%
-10% -20% -0%
35
