JVC AV-32WL1EU Service Manual page 25

Measuring
Item
instrument
Adjustment Remote
of SUB control unit
COLOURⅠ Ⅰ Ⅰ Ⅰ
Test point Adjustment part
10.COLOUR
PAL COLOUR
SECAM COLOUR
[Except for the AV-
32WL1EK]
NTSC 3.58 COLOUR
NTSC 4.43 COLOUR
No. 51733
Description
[Method of adjustment without measuring instrument]
1. Receive PAL broadcast.
2. Select 2.V/C from the SERVICE MENU.
3. Select 10.COLOUR with the FUNCTION UP/DOWN key.
4. Set the initial setting value for PAL COLOUR with the
FUNCTION LEFT/RIGHT key.
5. If the colour is not the best with the initial set value, make
fine adjustment until you get the best colour.
6. Press the OK key and memorize the set value.
1. Receive a SECAM broadcast. Make fine adjustment of SECAM
COLOUR in the same manner as for above.
1. Input a NTSC 3.58MHz COMPOSITE VIDEO signal from the
EXT terminal.
2. Make similar fine adjustment of NTSC 3.58 COLOUR in the
same manner as for above.
1. When NTSC 3.58 is set, NTSC 4.43 will be automatically set at
the respective values.
AV-32WL1EU
AV-32WL1EI
AV-32WL1EK
25
