Specifications
Model
AV32R25EK*/AV32R250EK*
Item
Broadcasting systems
CCIR I
Colour systems
PAL
• The EXT terminals also support the NTSC 3.58/4.43 MHz system.
Channels and frequencies E21-E69
Sound-multiplex systems
NICAM (I) system
Teletext systems
FLOF (Fastext), WST (World Standard Text)
Power requirements
220 - 240 V AC, 50 Hz
Power consumption
Maximum: 200 W, Average: 127 W,
Standby: 3 W
Picture tube size
Viewable area 76 cm (measured
diagonally)
Audio output
Rated Power output: 10 W + 10 W + 10 W, 18 W (woofer)
(13 cm × 6.5 cm) oval × 2, (16 cm × 4 cm) oval × 1, 13 cm round woofer ×1
Speakers
EXT-1 terminal
Euroconnector (21-pin, SCART)
• Video input, Audio L/R inputs and RGB inputs are available.
• TV broadcast outputs (Video and Audio L/R) are available.
Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
• Video and Audio L/R outputs are available.
• T-V LINK functions are available.
Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
RCA connectors × 3
EXT-4 terminal
S-VIDEO connector × 1
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
RCA connectors × 2
• Variable audio L/R outputs are available.
• Variable out 0-1 Vrms, low impedance.
SURROUND REAR
SPEAKER terminals for external surround speakers.
terminal
• Surround rear sounds are output to the speakers.
• For impedance 8-ohm speakers only.
• Rated power output: 7.5 W + 7.5 W
Headphone jack
Stereo mini-jack (3.5 mm in diameter)
Dimensions (W × H × D)
946 mm × 562 mm × 551 mm
Weight
56.0 kg
Accessories
Remote control unit × 1 (RM-C60 (Gray) or RM-C52 (Brack) is supplied.)
AAA/R03 dry cell battery × 2
*: A basic model number. The actual model number may have characters added (such as "S" for silver)
showing the colour of the TV set.
We may change the design and specifications without notice.
Pictures displayed on the screen using this TV's ZOOM functions should not be shown for any
commercial or demonstration purpose in public places (cafes, hotels, etc.) without the consent of the
owners of copyright of the original picture sources, as this would be an infringement of copyright.
© 2003 VICTOR COMPANY OF JAPAN, LIMITED
AV28R25EK*/ AV28R250EK*
Maximum: 200 W, Average: 125 W,
Standby: 3 W
Viewable area 66 cm (measured
diagonally)
854 mm × 507.5 mm × 493.5 mm
43.0 kg
LCT1152-001D-U
0403-T-CR-JMUK
Colour Television
AV32R25EK
AV28R25EK
AV32R250EK
AV28R250EK
INSTRUCTIONS
Contents
Setting up your TV . . . . . . . . . . . . . . . . . 5
TV buttons and functions . . . . . . . . . . . 10
Teletext function . . . . . . . . . . . . . . . . . 16
Using the TV's menu . . . . . . . . . . . . . . 18
Additional menu operations . . . . . . . . . 35
Additional preparation . . . . . . . . . . . . . 39
Troubleshooting . . . . . . . . . . . . . . . . . . 42
Specifications . . . . . . . . . . . . Back cover
Advertisement
Table of Contents
Related Manuals for JVC AV28R250EK
Summary of Contents for JVC AV28R250EK
-
Page 1: Table Of Contents
(cafes, hotels, etc.) without the consent of the owners of copyright of the original picture sources, as this would be an infringement of copyright. © 2003 VICTOR COMPANY OF JAPAN, LIMITED AV28R25EK*/ AV28R250EK* Colour Television AV32R25EK... -
Page 2: Remote Control
Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. - Page 3 Warning DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or adaptor or consult your dealer.
- Page 4 • Never obstruct the ventilation of this equipment. Doing so may cause overheating and result in a malfunction or damage. • Never use makeshift stands or attempt to affix legs with wood screws. When using a manufacturer’s approved stand or legs, use only the fixtures provided and follow the installation instructions.
-
Page 5: Ext-2 Terminal
Setting up your TV Caution • Turn off all the equipment including the TV before connecting anything. Connecting the aerial and video cassette recorder (VCR) • The connecting cables are not provided. • For further details, refer to the manuals provided with the devices to be connected. If you are connecting a VCR, follow A A A A →... -
Page 6: Initial Settings
TV is in the standby mode. Press the # (standby) button on the remote control to turn your TV on. • If the JVC logo does not appear this is because your TV has already been turned on for the first time: use the “LANGUAGE”... - Page 7 2 Press the a button The LANGUAGE menu appears. 3 Press the 6 buttons to choose ENGLISH The on-screen display will then be in English. To receive SKY 1 you need a satellite tuner. You must have the satellite tuner set to SKY 1 before starting the AUTO PROGRAM function which follows.
- Page 8 To use T-V LINK functions: A “T-V LINK compatible VCR” means a JVC video cassette recorder with the T-V LINK logo, or with one of the following logos. However, these VCRs may support some or all of the features described earlier.
- Page 9 Direct Rec “What You See Is What You Record” You can easily record to VCR the images that you are watching on the TV. For details, read the manual for your VCR. Use your VCR controls. “VCR IS RECORDING” is displayed. In the following situations, the VCR will stop recording if the TV is turned off, if the TV channel or input is...
-
Page 10: Tv Buttons And Functions
TV buttons and functions WOOFER AUDIO OUT EXT- EXT- (8 ) EXT- SURROUND REAR Refer to the pages in brackets for details. 1 Remote control sensor 2 Power lamp (6, 10) 3 Main power button (6, 10) 4 Headphone jack (mini jack) (39) 5 P p buttons/ q buttons (11) 6 r (Volume) button (10) 7 EXT-4 terminal (25, 39) -
Page 11: Remote Control Buttons And Functions
Remote control buttons and functions MENU 1 Muting button 2 Number buttons 3 ZOOM button 4 3D button 5 Information button 6 TV button 7 5 buttons 8 Standby button 9 Colour buttons 0 a button - 6 buttons = VCR/DVD/Teletext control button ~ VCR P DVD switch g (Text) button Turn the TV on or off from... -
Page 12: Muting The Sound
To watch the TV channel, see “CHILD LOCK” on page 28. • If the picture is tilted, correct it. See “PICTURE TILT (not AV28R25EK/ AV28R250EK)” on page 21. Adjust the volume Press the 5 buttons to adjust the volume. -
Page 13: Zoom Function
To return to a TV channel: Press the b button, the 6 buttons or the number buttons. To use the programme number PR 0 (AV): When the TV and VCR are connected only by the aerial cable, choosing the programme number PR 0 (AV) allows you to view images from the VCR. - Page 14 Remote control buttons and functions FULL: This uniformly stretches the left and right sides of a normal picture (4:3 aspect ratio) to fill the wide TV screen. • For 16:9 aspect ratio pictures that have been squeezed into a normal picture (4:3 aspect ratio), use the FULL mode to restore the picture to its original shape.
-
Page 15: Displaying The Current Time
P (Text) position. 2 Press the VCR/DVD control button to control your VCR or DVD player • If your device is not made by JVC, these buttons will not work. • Even if your device is made by JVC, some of these buttons may not work, depending on the device you are using. -
Page 16: Teletext Function
Teletext function Basic operation You can view two types of teletext broadcasts on the TV: FLOF (Fastext) and WST. 1 Choose a TV channel with a teletext broadcast 2 Set the VCR P DVD switch to the P (Text) position 3 Press g (Text) button to display the teletext Pressing g (Text) button changes the... - Page 17 Hold You can hold a teletext page on the screen for as long as you want, even while several other teletext pages are being received. Press the N button +ROG LQGLFDWLRQ To cancel the Hold function: Press the N button again. Sub-page Some teletext pages include sub-pages that are automatically displayed.
-
Page 18: Using The Tv's Menu
Using the TV’s menu This TV has a number of functions you can operate using menus. To use all your TV’s functions, you need to understand the basic menu operating techniques fully. Basic operation 1 Press the a button to display the MENU (main menu) When the headphones are not connected to the TV:... -
Page 19: Picture Setting
PICTURE SETTING TINT You can select one of three TINT modes (three kinds of picture settings) to adjust the picture settings automatically. COOL: A cool white colour base with a boost in the colour and contrast levels that creates a more vivid picture. -
Page 20: Picture Features
Using the TV’s menu PICTURE FEATURES AUTO VNR VNR Stands for “video noise reduction”. AUTO: This mode reduces any “noise” (interference or snowing) in the current picture. The function also adjusts the optimum sharpness of the picture (SHARP). MIN: The AUTO VNR function is cancelled. If you set the mode to AUTO but feel that the sharpness of the original picture has not been reproduced fully, change the mode to MIN. -
Page 21: Sound Setting
2 Press the 6 buttons to choose a ZOOM mode PICTURE TILT (not AV28R25EK/AV28R250EK) Sometimes the Earth’s own magnetic field may make the picture tilt. If this happens, you can correct the picture tilt. 1 Choose PICTURE TILT. Then press... -
Page 22: Digital Surround
Using the TV’s menu BALANCE You can adjust the volume balance between the left and right speaker. 2 : turn the left speaker’s volume level up. 3 : turn the right speaker’s volume level up. • When the DOLBY PRO LOGIC function or PRO LOGIC 3D-PHONIC function is operating, the “BALANCE”... -
Page 23: Dolby Pro Logic
• The PRO LOGIC 3D-PHONIC function does not work properly except for Dolby Surround encoded programmes. • You can turn the PRO LOGIC 3D- PHONIC function on or off by pressing button. Change the setting of the PRO LOGIC 3D-PHONIC function 1 Choose PRO LOGIC 3D-PHONIC. -
Page 24: Headphone Surround
Using the TV’s menu Other surround functions You can enjoy enhanced sound with one of the following four surround functions: DANCE CLUB: This function creates a dance club atmosphere. It does not work properly for mono sound. CONCERT HALL: This function creates a concert hall atmosphere. -
Page 25: Ext Setting
Other surround functions You can enjoy enhanced sounds while using headphones with one of the following four surround functions: DANCE CLUB: This function creates a dance club atmosphere. It does not work properly for mono sound. CONCERT HALL: This function creates a concert hall atmosphere. - Page 26 Using the TV’s menu To cancel the y (S-VIDEO input) setting: Press the yellow button and turn off y (S-VIDEO input) mark. The regular video signal (composite signal) pictures are resumed. • The EXT-1 terminal does not support S-VIDEO signal (Y/C signal) and you cannot set y (S-VIDEO input) in the EXT-1 terminal.
-
Page 27: Sleep Timer
• During dubbing, you cannot turn off the TV. Turning off the TV also turns off the output from the EXT-2 terminal. • When you choose an EXT terminal as an output, you can view a TV programme or a picture from the other EXT terminal while dubbing the picture from a device connected to the EXT terminal onto a VCR connected... -
Page 28: Blue Back
Using the TV’s menu BLUE BACK You can set the TV to automatically change to a blue screen and mute the sound if the signal is weak or absent, or when there is no input from an external device. This function is turned on. OFF: This function is turned off. -
Page 29: Auto Program
If you have forgotten the ID number: Perform step 1 of “To set the CHILD LOCK function”. After confirming the ID number, press the b button to exit the menu. • Even if you reset the lock temporarily, it does not mean that the CHILD LOCK function set for the TV channel is cancelled. - Page 30 Using the TV’s menu • To cancel the AUTO PROGRAM function, press the b button. After the TV channels have been registered in the programme numbers (PR), the EDIT menu appears. • You can now edit the programme numbers (PR) using the EDIT/ MANUAL function.
- Page 31 1 Choose EDIT/MANUAL, then press the a button • For programme number PR 0, “AV” appears in the programme numbers (PR) list. • An EXT terminal number does not appear in the programme numbers (PR) list. • The CH number is a number unique to the TV and corresponding to the channel number of a TV channel.
- Page 32 Using the TV’s menu 4 Press the 2 button to change the programme number (PR) of a TV channel to a new programme number (PR) 1 Press the 6 buttons to choose a TV channel Every time you press the 6 buttons, the programme number (PR) changes and the picture of the TV channel stored in the programme number (PR) appears on the...
- Page 33 3 Press the number buttons to enter the remaining CH number The TV shifts to registration mode. When the registration is completed, the picture of the TV channel appears on the screen. • The CH number is a number given to each broadcast frequency that carries a TV channel.
- Page 34 Using the TV’s menu CH NUMBER • When you want to use the INSERT function on page 32, find the CH number corresponding to the channel number of the TV channel from this table. If you want to know a particular TV channel’s channel menu, look in TV listings magazines or contact the broadcaster.
-
Page 35: Additional Menu Operations
Additional menu operations Downloading data to a VCR You can send the latest programme numbers (PR) data to a VCR with the T-V LINK function. • You can only do this when a T-V LINK compatible VCR is connected to the EXT- 2 terminal. - Page 36 Additional menu operations 7 Follow “Downloading data to a VCR” on page 35 to transmit the programme number (PR) data to the VCR 8 If you have another TV channel you want to unscramble using a decoder, repeat steps 2 to 7 If the DECODER (EXT-2) function has been set to “ON”...
- Page 37 Using the TV speakers as the centre speakers for the PRO LOGIC 3D-PHONIC function When the PRO LOGIC 3D-PHONIC function is operating, the front speakers and TV speakers are all used. The TV speakers take the role of a centre speaker. It makes spoken dialogues more vivid and easier to listen to.
- Page 38 Additional menu operations 4 Press the 6 buttons to choose TV SPEAKER. Then press the 5 buttons to choose the TV speaker setting When you are connecting only surround speakers: Set TV SPEAKER to L/C/R. When you are connecting both an audio system and surround speakers: Set TV SPEAKER to CENTRE.
-
Page 39: Additional Preparation
Additional preparation Connecting external equipment Connect the equipment to the TV, making the correct rear panel and front panel connections. Before connecting anything: • Read the manuals that came with the equipment. Depending on the equipment, the connection method may be different from the diagram. -
Page 40: Connecting Headphones
Additional preparation Equipment which can output the S-VIDEO signal (Y/C signal) such as an S-VHS VCR Connect the equipment to an EXT terminal (but not the EXT-1 terminal). You can choose between an S-VIDEO signal (Y/C signal) and a regular video signal (composite signal). -
Page 41: Removing And Fitting The Woofer Unit
External surround speakers You can connect external surround speakers to the TV so that you can use the “DOLBY PRO LOGIC” on page 23. Before using the DOLBY PRO LOGIC function, however, follow the description “Setting the DOLBY PRO LOGIC function” on page 37. 1 Amplifier 2 Front speakers (magnetic-shielded type) 3 Surround speakers (impedance 8 ohm type) -
Page 42: Troubleshooting
Troubleshooting If a problem arises while you are using the TV, please read this troubleshooting guide carefully before you ask to have the TV repaired. You may be able to fix it easily by yourself. For example, if the mains plug is disconnected from the mains outlet, or the TV aerial has problems, you may think there is a problem with the TV itself. -
Page 43: Poor Sound
• A picture may be tilted due to the earth’s own magnetic field. If so, use the “PICTURE TILT (not AV28R25EK/ AV28R250EK)” on page 21 to correct the tilt. • The TV may make a crackling sound due to a sudden change in temperature. The picture or sound may be normal.
