SERVICE MANUAL
AV-32WFT1EPS
AV-32WFT1EKS
Since some details of the AV-29RFCS/AV29RF6CSC service
manual (No.51754, Jul. 2000) were changed, we are informing
you of these changes and of the new descriptions.
CHANGED ITEMS
EXPLODED VIEW PARTS LIST (Page 58)
REF. No.
105
LC30597-006A-U
VICTOR COMPANY OF JAPAN, LIMITED
HOME NETWORK BUSINESS UNIT. 12, 3-chome, Moriya-cho, Kanagawa-ku, Yokohama, Kanagawa-prefecture, 221-8528, Japan
COLOUR TELEVISION
Supplementary
PARTS No.
PREVIOS
NEW
LC30597-007B
COPYRIGHT
2002 VICTOR COMPANY OF JAPAN, LTD.
PARTS NAME
DESCRIPTION
For AV-32WFT1EPS/EKS
CONTROL SHEET
(Not Interchangeable)
AV-32WFT1EPS
AV-32WFT1EKS
BASIC CHASSIS
JK
No.51694L
Feb. 2002
