AV-32WL1EU
AV-32WL1EI
AV-32WL1EK
Measuring
Item
instrument
Adjustment of Signal
H.CENTER generator
Remote
control unit
C
Adjustment Signal
of generator
H.SIZE
Remote
control unit
[ HORIZONTAL SIZE ]
ASPECT SIZE
H SIZE
Adjustment of Signal
EW-PIN generator
Remote
control unit
30
Test point Adjustment part
3.H-CENT.
D
4.H-SIZE
FULL
92%
5.EW-PIN
Straight
12. Receive the circle pattern signal.
13. Select 3.H-CENT and set the initial setting value.
14. Adjust H-CENT to make C=D .
15. Press the OK key and memorize the set value.
16. Receive the cross-hatch signal.
17. Select 4.H-SIZE and set the initial setting value.
18. Adjust H-SIZE and make sure that the horizontal screen size
of the picture size is in the bellow table.
19. Press the OK key and memorize the set value.
20. Input a NTSC VIDEO signal (60Hz) from the EXT terminal, and
make sure that the horizontal screen size is in the table below.
21. Press the OK key and memorize the set value.
16:9 ZOOM SUBTITLE
PANORAMIC
95%
22. Select 5.EW-PIN and set the initial setting value
23. Adjust EW-PIN and make the 2nd vertical lines at the left and
right edges of the screen straight. Also make sure that the 3rd
vertical lines are straight.
24. Press the OK key and memorize the set value.
No. 51733
Description
92%
