5. MAIN MENU

Right-click anywhere on the screen to show the main menu as follows, and right-click again to exit. For details
about the menu structure, please refer to "APPENDIX 5 MAIN MENU STRUCTURE" at page 58.
Main Menu

5.1 QUICK START

5.1.1 GENERAL

GENERAL
TIME SETUP
EXIT
1) CHANNEL TITLE
Select to display the channel title or not (ON / OFF).
2) EVENT STATUS
Select to display the event icons or not (ON / OFF).
Note: For details about each event icon, please refer to "4.1 Live Page" at page 12.
3) DATE DISPLAY
Select to display the date or not (ON / OFF).
4) IMAGE SIZE
Select one of the image sizes: FRAME, FIELD or CIF.
5) QUALITY
Select one of the 4 quality options: SUPER BEST, BEST, HIGH & NORMAL.
6) IMAGE PER SECOND
Select the images per second for MANUAL RECORD.
QUICK START
DATE SETUP
SYSTEM
EVENT INFORMATION
ADVANCE CONFIG
SCHEDULE SETTING
QUICK START
CHANNEL TITLE ON
EVENT STATUS ON
DATE DISPLAY ON
IMAGE SIZE CIF
QUALITY SUPER BEST
IMAGE PER SECOND 120
Click to set the status display, image settings, and date &
time.
Click to set the date display and daylight saving.
Click to set the system configurations.
Click to enter the event search menu.
Click to set CAMERA, DETECTION, ALERT,
NETWORK, SNTP, DISPLAY, RECORD, REMOTE,
DCCS, IVS & NOTIFY.
Click to set record timer and detection timer.
15
MAIN MENU
