1. BEFORE USING THIS DVR

1.1 Package Content

DVR
IR Remote Controller
IR Receiver Extension Cable
CD Manual
HDD screws

1.2 Front Panel

1) LED Indicators
DVR is powered on.
HDD is reading or recording.
An alarm is triggered.
Timer recording is on.
Under playback status
2) CH1 ~ 16 / 1 ~ 8 / 1 ~ 4
Press the channel number buttons to select the channel to display.
3) SLOW
In the playback mode, press to show slow playback.
4) ZOOM
Press to enlarge the picture of selected channel in the FRAME or FIELD recording mode.
5)
Press to show the 4 channel display mode.
6) SEQ
Press to display each channel in full screen one by one starting from CH1. When the last channel is displayed, it
will repeat from CH1 again. To exit this mode, press "SEQ" again.
7) LIST (Event List Search)
Press to quickly search the recorded files by event lists: RECORD / MOTION / ALARM / TIME / HUMAN
DETECTION / IVS / STATISTIC, or select FULL LIST to show all the event logs.
To quickly search the time you want, select "QUICK SEARCH". For details, please refer to "5.4.1 QUICK
SEARCH" at page 20.
8) SEARCH
(Selected Models Only)
Press to enter the time search menu. For details, please refer to "5.4.1 QUICK SEARCH" at page 20.
9) MENU
Press "MENU" to enter the main menu.
10) ENTER
Press "ENTER" to confirm the setting.
11) (PLAY)
Press to playback the latest recorded data.
Manual for IR Remote Controller
DVR Quick Start
Adapter & Power cord
9 or 25 Pin DSUB Connector
USB Mouse
1
BEFORE USING THIS DVR
