2.0

Installation and Set Up

2.1 Installation Checklist
This checklist summarizes the installation and setup procedures for the AP20.
Table 2: AP20 Installation and Setup
Completed
AP20 Installation & Operating Guide
AP20 Installation and Operating Guide
Task Description
Install AP20 in Equipment Rack
CONNECT CABLING:
Power Cable
Audio input cables to AP20
Audio output cable from AP20 Analog Out
to Audio Power Amps
Automation cabling
ADJUST AND TEST
Theater Equipment Check
Assign channels
Verify channel assignments
Set levels to establish a baseline
Perform the EQ
Perform Subwoofer Parametric EQ
Final Adjustments (fine tuning)
Verify Sound Performance
Set up macros for automation
SYSTEM SECURITY
Save AP20 configuration to USB flash
drive
Set Password to Prevent Unauthorized
Access, if Appropriate.
Refer to:
Chassis Rack Mounting and Connection,
page 28
(Depends on audio sources)
Appendix B, Interface Wiring Diagrams.
Appendix B, Interface Wiring Diagrams.
Check speakers, amplifiers, auditorium
conditions
Theater Equipment Check, page 35
On AP20: Menu (System) > Format >
Channel Profile > Channel Names
Assign Channels on AP20, page 35
Listen in auditorium
Verify Channel Assignments in
Auditorium, page 37
Set levels to establish a baseline, page
39
Perform the EQ, page 40
Subwoofer EQ – Parametric EQ, page
42
Final Adjustments, page 44
Listen in auditorium
Creating a Macro, page 98
Saving and Restoring Configuration
Files, page 58
Access Control, page 60
Document # 9301H39200 Ver. 1.25
Page 25
