4.5.2.2 Delete Macro
To delete a macro, highlight it on the list and select the "Delete Macro" button.
Any actions contained in the Macro script must be removed before it can be deleted.
Highlight the actions on the list and select the "Remove" button.
Caution. A macro may be deleted even if it is associated with an Event and assigned to an
Automation button.
4.5.2.3 Copy Macro
This feature is useful to create a macro similar to an existing macro without reentering all the events.
After the macro is copied, just change or edit events that should be different.
To copy a Macro, first highlight the source macro, then press the Copy Macro button. A keyboard will
appear to enter the name of the new macro. After entering the new macro name, press OK to return to
the Macro list with the new macro added.
4.5.2.4 Actions For "Macro name"
Allows you to edit action items in the specified macro. Tap in the box below the Actions For " " label
and, by turning the front panel fader, select the desired Macro item. The Marco name appears between
the quotes (" "). Now, tap the desired command button below the event box.
Available commands for macro events are:
Add Before: Add a new event before the highlighted selection.
Add After: Add a new event after the highlighted selection.
Delete: Delete the highlighted event. Select OK after popup message appears to confirm.
Edit: Edit the currently selected event
Copy: Copy the currently selected event. A copy of the selected event will appear below
the current event on the list.
Move Up: Move the placement of the selected event one position up the list.
Move Down: Move the placement of the selected event one position down the list.
