USB Smart Cable

Zilog's USB Smart Cable, ZUSBSC0100ZACG, allows you to connect
ZLF645, Z8 Encore!
development board to a high-speed or full-speed USB port on Zilog
Developer Studio II (ZDS II) host system.
This user manual provides instructions for installing USB Smart Cable
hardware and the associated drivers. When the USB Smart Cable is con-
nected and the driver installed, you can proceed with debugging as
described in the development kit documentation.

Kit Contents

The kit contents for the USB Smart Cable include:
•
•
•

Supported Host Environments

The supported host environments are:
•
•
UM018112-0908
®
, Z8 Encore! XP
USB Smart Cable
Six-conductor ribbon cable
User manual
A host PC with ZDS II v4.9.0 or later version for Z8 Encore! and
eZ80Acclaim!, or ZDS II v4.10.0 for ZNEO, or ZDS II v4.11.0 for
ZLF645. For ZDS II host system requirements refer to the develop-
ment kit quick start guide.
One USB high-speed or full-speed port on the host chassis or a pow-
ered Hub.
USB Smart Cable
User Manual
® ®
, ZNEO , or eZ80Acclaim!
USB Smart Cable
1
®
