User Manual
Introduction
The Ethernet Smart Cable, ZENETSC0100ZACG, allows you to connect the Z8 Encore!
ZNEO ™, or eZ80Acclaim!
II) host-system using an Ethernet connection.
This user manual provides instructions for installing Ethernet Smart Cable hardware.
Instructions are also provided for Ethernet-equipped host PCs that are not network-con-
nected. Once the Ethernet Smart Cable is connected, you can proceed with debugging as
described in the development kit documentation.
Kit Contents
Refer to the Ethernet Smart Cable Packing List, PAK0019, for details on kit contents.
Software and Hardware Requirements
•
A host PC with ZDS II version 4.10.0 or later for Z8 Encore!
ZNEO™. Refer to the development kit quick start guide for ZDS II host system
requirements. You can download the latest version of ZDS II from www.zilog.com.
•
An available 10/100 Mbps Ethernet connection.
Supported Target Environments
Development Board
®
Z8 Encore!
ZNEO™
®
eZ80Acclaim!
* Add this current for Ethernet Smart Cable requirement on your target's power supply.
ZiLOG Worldwide Headquarters • 532 Race Street • San Jose, CA 95126
Telephone: 408.558.8500 • Fax: 408.558.8300 •
Ethernet Smart Cable
User Manual
®
development board to a ZiLOG Developer Studio II (ZDS
System Clock
Min
Max
32 kHz
20 MHz
10 kHz
20 MHz
5 MHz
50 MHz
®
, eZ80Acclaim!
Power Supply
Current*
Min
Max
2.7 V
3.6 V 2 mA
2.7 V
3.6 V 2 mA
3.0 V
3.6 V 2 mA
www.zilog.com
UM020701-0506
®
,
®
, or
Advertisement
Table of Contents
Related Manuals for ZiLOG ZENETSC0100ZACG
Summary of Contents for ZiLOG ZENETSC0100ZACG
-
Page 1: Kit Contents
Ethernet Smart Cable User Manual UM020701-0506 Introduction The Ethernet Smart Cable, ZENETSC0100ZACG, allows you to connect the Z8 Encore! ® ® ZNEO ™, or eZ80Acclaim! development board to a ZiLOG Developer Studio II (ZDS II) host-system using an Ethernet connection. -
Page 2: Installing The Ethernet Smart Cable
Ethernet Smart Cable User Manual Page 2 Installing the Ethernet Smart Cable The Ethernet Smart Cable is optimized for use on an Ethernet network in which a DHCP server assigns IP addresses. The following sections provide instructions for connecting the Ethernet Smart Cable to a DHCP-based network, or directly to an Ethernet-equipped host The Ehternet Smart Cable’s factory default settings are: •... - Page 3 Ethernet Smart Cable User Manual Page 3 Figure 1. Ethernet Smart Cable, Front View Figure 2. Ethernet Smart Cable, Rear View UM020701-0506 Installing the Ethernet Smart Cable...
- Page 4 Ethernet Smart Cable User Manual Page 4 3. Start ZDS II. 4. Open one of the projects listed in the samples directory of your ZDS II installation. 5. Select . The window appears. Project –› Settings Project Settings 6. Select the tab.
- Page 5 Ethernet Smart Cable User Manual Page 5 Figure 3. The Network Dialog UM020701-0506 Installing the Ethernet Smart Cable...
- Page 6 Ethernet Smart Cable User Manual Page 6 5. In the panel labeled , double-click the LAN or High-Speed Internet Local Area Connec- icon. The dialog box appears, as shown in Figure 4. tion Local Area Connection Status Figure 4. The Local Area Connection Status Dialog Installing the Ethernet Smart Cable UM020701-0506...
- Page 7 Ethernet Smart Cable User Manual Page 7 6. In the dialog box, click the button. The Local Area Connection Status Properties Local dialog box appears, as shown in Figure 5. Area Connection Properties Figure 5. The Local Area Connection Properties Dialog 7.
- Page 8 Ethernet Smart Cable User Manual Page 8 Figure 6. The Internet Protocol Properties Dialog 8. Enter an IP address of and a subnet mask of . These 192.168.1.21 255.255.255.0 values place the PC on the same network as the Ethernet Smart Cable, and do not con- flict with the IP address of the Ethernet Smart Cable.
- Page 9 Ethernet Smart Cable User Manual Page 9 To change the Ethernet Smart Cable default settings: 1. Obtain the Ethernet Smart Cable IP address. 2. Open your web browser to the IP address located in Step 1. The Ethernet Smart Cable home web page appears (see Figure 7). tab provides access to Ethernet Smart Cable network settings.
- Page 10 Ethernet Smart Cable User Manual Page 10 Figure 8. Ethernet Smart Cable Password Web Page 3. Once you have changed the configuration in the tab, click the Submit button. Settings A message acknowledging that changes have been made appears beneath the web page.
-
Page 11: Connecting To The Target Board
® Design for Debug Technical Note (TN0036). Troubleshooting Tips If a hardware failure is suspected, contact a local ZiLOG representative for assistance. Before submitting a problem report to ZiLOG Customer Support, follow the instructions below. ZDS II Cannot See the Ethernet Smart Cable If ZDS II cannot see the Ethernet Smart Cable: •... -
Page 12: Zilog Customer Support
Ethernet Smart Cable User Manual Page 12 ZiLOG Customer Support For additional troubleshooting, see the ZDS II Online Help. For more information on hardware and software development tools, log on to ZiLOG Customer Support online. Download the latest released version of... - Page 13 Fax: 408.558.8300 www.zilog.com Document Disclaimer ZiLOG is a registered trademark of ZiLOG Inc. in the United States and in other countries. All other products and/or service names mentioned herein may be trademarks of the companies with which they are associated.
