Opto-Isolated USB Smart Cable
User Manual
Page 2
Supported Host Environments
•
A host running ZiLOG Developer Studio II (ZDSII) software version 4.9.4 or later.
See your development kit Quick Start guide for ZDSII host system requirements.
Download the latest version of ZDS II for your system by visiting us on the web at
http://www.zilog.com/software/zds2.asp.
Note:
Windows NT hosts are not supported by the USB Smart Cable.
•
One USB high-speed or full-speed port on the host chassis or a powered hub. The
USB Smart Cable cannot operate properly on an unpowered hub (i.e., a hub without a
separate AC adapter).
Supported Target Environments
Development Board
Z8 Encore! ®
Z8 Encore! MC™
Installing the USB Smart Cable and Driver
The first time you connect a USB Smart Cable to your system, you need to help Windows
load the appropriate driver from the ZDSII installation directory or CD-ROM. You can
download ZDSII software from www.ZiLOG.com. You only need to help Windows locate
the driver once. The procedure depends on your Windows operating system version.
If you previously installed the USB Smart Cable as part of another ZiLOG Development
Kit, you do not need to install the driver. Plug your USB Smart Cable into an available
USB port and the system will install the driver automatically.
Note:
If you have downloaded the latest version of ZDS II, please install it first
before proceeding.
Windows XP
1. Connect the USB Smart Cable to the host PC for the first time.
The Found New Hardware Wizard should activate automatically.
Supported Host Environments
System Clock
Min
Max
32KHz
20MHz
32KHz
20MHz
Power Supply
Current
Min
Max
2.7V
3.6V
25 mA
2.7V
3.6V
25 mA
UM019502-0606
