Hunter Ceiling Fans Installation And Operation Manual page 16

®
Wall Switch Wire For
Separate Control of Light Fixture
Black
Power
Wires
In
White
Ceiling
Bare or Green
2 x 4 Brace
Approved
Connectors
Green Ground
Wire from Hanger
Pipe (not present
with flush mounting
option)
16
(Note: Wall switch
must be acceptable
as a general-use
switch.)
Outlet Box
Green
1
2
Black/White
3 Wires
From Fan
Figure 6a - Wiring The Fan
Ceiling
Plate
Connections:
1 Connect Blk/Wht Wire from fan
to Wall Switch Wire for separate
control of light fixture, or
2 Connect Blk/Wht Wire from fan
to Ceiling Black Wire if there
is no separate Wall Switch Wire
for the light fixture.
41524-01 9-5-2001
