- Page 1 900mm Island Canopy Manual MODEL ICF9BLS Installation and Operation...
- Page 2 CANOPY INSTALLATION AND OPERATION MANUAL...
-
Page 3: Table Of Contents
We thank you for choosing this quality appliance and hope you enjoy many years of reliable service. Please ensure this manual is read carefully before installation and use. Keep this manual in a safe and accessible location should future reference be required. Regards Home Appliances CONTENT 2……………………………………….Notice 3……………………………………….Feature 4………………………………………..Installation 6………………………………………..Notice of installation 6………………………………………..Safety Warning... -
Page 4: Notice
NOTICE 1. Thank you for choosing our cooker hood. Please read the instruction manual carefully before use. 2. The installation work must be undertaken by a qualified and competent fitter. 3. The manufacturer disclaims all liability for any damage or injury caused as a result of not following instructions for installation contained in the following text. -
Page 5: Feature
(2)FEATURE 1. The cooker hood uses high quality materials, and is made with a streamlined design. 2. Equipped with a large power low noise electric motor and centrifugal leaf, it produces strong suction, low noise, non stick grease filter and easy to clean. 3. -
Page 6: Installation
(3) INSTALLATION 1. The ceiling must can bear at least 40kgs weight, and the thickness of the ceiling must be 30MM, see pic 2, drill 1*170mm round hole in the ceiling. 2. According to the hanging board, drill 12 holes in the ceiling, see pic 2, 12pcs of ST6*40mm big flat screws will be used to fix the hanging board on the ceiling, and then 8pcs of M4*10 screws and M4 nut with gasket will be used to connect the angle iron... -
Page 8: Notice Of Installation
(4) NOTICE OF INSTALLATION 1. Before installation, please ensure the area is clean to avoid suction of the remaining bits of broken wood and dust. 2. It cannot share the same air ventilation tube with other appliance such as gas tube, warmer tube, and hot wind tube. 3. -
Page 9: Use
（6） USE Electronic Button 1. Turn on the power; the buzzer will buzz five times. The sound shows that the appliance is powered. 2. Push the low button, the indicating light 1 on, the buzzer will buzz once, and the motor runs at low speed. Push it again and the motor will stop. 3. - Page 10 Push button 1. Push stop button, and the motor will stop. 2. Push the Low button, the buzzer will buzz once, and the motor runs at low speed. 3. Push the button, the buzzer will buzz once, and the motor runs at mid speed.
- Page 11 LCD Electronic button Pic 7 1. Plug the hood; LCD will display 24-hour system with blue backlight. Backlight will be extinguished after 30 seconds without any operation. 2. Press “ ” button once; lights will be on and LCD will show “ ”.
- Page 12 pressing “ ” button. Press “ ” button once; the number reduces by 01. When LCD shows 00; it doesn’t work by pressing “ ” button. After setting hour; you can start setting minute by pressing “ ” button again. on LCD flashes;...
- Page 13 LCD Touch control Pic 8 Power on: Switch on the power supply, and the backlight is lit, displaying “24-hour system”. The output is then blocked up,and the soot machine enters standby status. The backlight disappear automatically 30 seconds later under the condition of none operation. Press “Indicator”...
- Page 14 Long press timer key for 2-3 seconds, time segment , and the first two hour bit segment flash, use key for the digit increase, and use key for the digit decrease. Namely: The variable is 01 each time it is pressed; the hour segment is with the largest digit of 23.
-
Page 15: Maintenance
(7) MAINTENANCE 7.1 The cleaning of the carbon grease filter mesh The filter mesh is made of high-density stainless steel. Please do not use the corrosive detergent on it. Keeping this filter clean will keep the appliance running correctly. Please strictly follow the guidelines below. -
Page 16: Abnormity And Solution
G. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. (8) ABNORMITY AND SOLUTION 8.1 LED light replacing Remove the filters, and push the light downwards, and unplug the wiring connector. - Page 17 8.2 Some solution Fault Cause Solution The leaf blocked Get rid of the blocking The capacitor damaged Replace capacitor Light on, but motor does not work The motor jammed bearing Replace motor damaged The internal with of motor off or Replace motor a bad smell from the motor Beside the above mentioned, check the following:...
- Page 18 The hanging screw not tight Tighten the hanging enough screw and make it horizontal...
