Summary of Contents for Euromaid INLC60
- Page 1 User Manual Off Board T-Shape Canopy Rangehoods INLC60 & INLC90...
- Page 2 Company / Installers Name: _____________________________________________ Licence Number: ______________________________________________________ Telephone Number: ____________________________________________________ Plumbing date of installation: ___________________________________________________________________________ Plumbers installers details: Company / Installers Name: _____________________________________________ Licence Number: ______________________________________________________ Telephone Number: ____________________________________________________ Page ii INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual...
- Page 3 For further details please contact our Customer Care team on 1800 444 357 or email: customercare@hapl.com.au Thank you Regards, Home Appliances INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual Page iii...
-
Page 4: Table Of Contents
Contents Notice Safety Warnings Caution Features Schematic Diagram Installation Operation Maintenance Bulb Replacement Troubleshooting and Possible Solutions Supplied Accessories HAPL Ducting Kit Solutions... -
Page 5: Notice
4. The Rangehood operates on 220/240V, 50Hz. External fan motor Extension pipe (ducting) Main body of rangehood INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual Page 1... -
Page 6: Safety Warnings
• Please ensure that the warranty card and purchase receipt for your Rangehood are kept in a safe place if you require service assistance. Page 2 INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual... -
Page 7: Caution
Children should be supervised to ensure that they do not play with the Rangehood. • If the power cord is damaged, it must be replaced by a recommended service agent to avoid a hazard. INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual Page 3... -
Page 8: Features
Equipped with a large power low noise electric motor and centrifugal fan, it produces strong suction and low noise. • With the isolated low voltage circuit board control, 12vAC input, the lights are therefore safer. Page 4 INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual... -
Page 9: Schematic Diagram
2. The supplied 3 metre extension ducting will connect the main body and external motor, and cooking residues will be extracted and discharged to outside via a ducting kit. Power cable Extension cable from main body to motor INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual Page 5... -
Page 10: Installation
See Pic 5. 6. Install the chimney and fix the outside chimney bracket, See Pic 6. After adjusting the position, fix the body with safety screws. See Pic 7. Page 6 INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual... - Page 11 10. Fix the external motor on the ceiling or on the wall by using 4 pcs ST4*30mm screws, See Pic 12 & 13 11. Connect the extension pipe (ducting), See Pic 14 12. Connect the power cord to the motor with extension cable, See Pic15 INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual Page 7...
- Page 12 Four (4) metres for connection between the hood body and fan motor. – Three (3) metres for connection between the fan motor and outside. Correct Incorrect The fan motor must be secured using the supplied bracket and screws Page 8 INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual...
-
Page 13: Operation
4. Push the light button, and the button will be backlit, and the two LED lights will be illuminated. Push it again and the LED lights will turn off. INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual Page 9... -
Page 14: Maintenance
Change the carbon filters as per Pic. 18 • Please use non-abrasive cleaners on the main body of the Rangehood. Note: Ensure the power to the Rangehood has been turned off before cleaning. Page 10 INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual... -
Page 15: Bulb Replacement
Please note: Alternatively, you can change the bulb from the inside of the Rangehood, take out the metal filter and have the bulb replacement from inside of the Rangehood. INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual Page 11... -
Page 16: Troubleshooting And Possible Solutions
Choose a new place and resemble the doors or windows machine For product enquires including warranty support, please contact our Customer Care team on 1800 444 357 or via email, customercare@hapl.com.au Page 12 INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual... -
Page 17: Supplied Accessories
QTY - hood body QTY - motor Wall plug Screw (4mm x 40mm) Screw (4mm x 30mm) Screw (4mm x 8mm) Outlet flap Hook outer chimney bracket inner chimney bracket INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual Page 13... -
Page 18: Hapl Ducting Kit Solutions
Metal Roof Ducting Kit - DKRM *Please contact HAPL on 1800 805 300 for information regarding your local retailer of the recommended ducting kit solutions from Home Appliances. Page 14 INLC60 & INLC90 Off Board T-Shape Canopy Rangehoods User Manual... - Page 20 For all product enquiries (including warranty support), please contact our Customer Care team on 1800 444 357 or via email: customercare@hapl.com.au...
