- Page 1 600mm Pyramid Stainless Steel Canopy Manual MODEL CP6BLS Installation and Operation...
- Page 2 Canopy Installation and Operation Manual Dear Customer, We thank you for choosing this quality appliance and hope you enjoy many years of reliable service. Please ensure this manual is read carefully before installation and use. Keep this manual in a safe and accessible location should future reference be required. Regards Home Appliances CONTENT...
-
Page 3: Safety Warning
Canopy Installation and Operation Manual 3 …………………………………………………. Caution 4 …………………………………………………. Feature 5-8 ……………………………………………….. Installation 9 ………………………………………………….. Notice of installation 10 ……………………………………………..….. Safety Warning 11-16 …………………………………………..… Use 17 ………………………………………………… Maintenance NOTICE 1. Thank you for choosing our canopy rangehood. Please read the instruction manual carefully before use. -
Page 4: Safety Warnings
Canopy Installation and Operation Manual SAFETY WARNINGS Installation of this Integrated Canopy Rangehood must be carried by a qualified and competent installer. The manufacturer disclaims and liability for any damage or injury caused as a result of not following instruction of installation contained in this instruction manual. - Page 5 Canopy Installation and Operation Manual Flambe cooking cannot be carried out under the Integrated Canopy Rangehood and is not recommended for use over Barbeques. Ducting must be independent from any other form of ducting of other household heating sources. ...
- Page 6 Canopy Installation and Operation Manual (3). Installation If the model without Glass: 3.1 The cooker hood should be placed at a distance of 65-75cm (26-30inch) from the cooking surface for the best effect. See Pic 1. 3.2 Install the hook on a suitable place once the installation height is fixed, and keep it in line.
- Page 7 Canopy Installation and Operation Manual 3.7 Install the chimney and screw the T-piece metal outlet to the inside chimney, See Pic 7 and 8. 3.8 Adjust the height of the inside chimney to the position of the inside chimney bracket and fix on it by screw,after ajusting the position,fix the body with safety screw. See Pic 9.
- Page 8 Canopy Installation and Operation Manual Home Appliances – March 2012...
- Page 9 Canopy Installation and Operation Manual If the model with Glass: 3.1 The cooker hood should be placed at a distance of 65-75cm (26-30inch) from the cooking surface for the best effect. See Pic 1. 3.2 Install the hook on a suitable place once the installation height is fixed, and keep it in line.
- Page 10 Canopy Installation and Operation Manual Home Appliances – March 2012...
-
Page 11: Notice Of Installation
Canopy Installation and Operation Manual (4) NOTICE OF INSTALLATION 1. Before installation, please ensure the area is clean to avoid suction of the remaining bits of broken wood and dust. 2. It cannot share the same air ventilation tube with other appliance such as gas tube, warmer tube, and hot wind tube. - Page 12 Canopy Installation and Operation Manual (5) SAFETY WARNING Keep your children from using the cooker hood. Your cooker hood is for domestic use only, not suitable for barbecue, roast shop and other commercial use. Any installation work must be carried out by a qualified electrician or competent person.
- Page 13 Canopy Installation and Operation Manual （6） Speed adjustment .See pictures Electronic Button 1. Turn on the power; the buzzer will buzz five times. The sound shows that the appliance is powered. 2. Push the low button, the indicating light 1 on, the buzzer will buzz once, and the motor runs at low speed.
- Page 14 Canopy Installation and Operation Manual Push button 1. Push stop button, and the motor will stop. 2. Push the Low button, the buzzer will buzz once, and the motor runs at low speed. 3. Push the button, the buzzer will buzz once, and the motor runs at mid speed. 4.
- Page 15 Canopy Installation and Operation Manual LCD Electronic button Pic 7 1. Plug the hood; LCD will display 24-hour system with blue backlight. Backlight will be extinguished after 30 seconds without any operation. 2. Press “ ” button once; lights will be on and LCD will show “ ”.
- Page 16 Canopy Installation and Operation Manual until 59. When LCD shows 59; it doesn’t work by pressing “ ” button. Press “ ” button once; the number reduces by 01. When LCD shows 00; it doesn’t work by pressing “ ” button. After setting hour and minute; press “ ”...
- Page 17 Canopy Installation and Operation Manual LCD Touch control Pic 8 Power on: Switch on the power supply, and the backlight is lit, displaying “24- hour system”. The output is then blocked up,and the soot machine enters standby status. The backlight disappear automatically 30 seconds later under the condition of none operation.
- Page 18 Canopy Installation and Operation Manual key for the digit decrease. Namely: The variable is 01 each time it is pressed; the hour segment is with the largest digit of 23. If it exceeds 23, key is null and void. If it is equal to 00, then, the key is null and void.
-
Page 19: Maintenance
Canopy Installation and Operation Manual (7) MAINTENANCE 7.1 The cleaning of the carbon grease filter mesh The filter mesh is made of high-density stainless steel. Please do not use the corrosive detergent on it. Keeping this filter clean will keep the appliance running correctly. Please strictly follow the guidelines below. -
Page 20: Replacing Light
Canopy Installation and Operation Manual (8) REPLACING LIGHT 8.1 halogen light: Use a small flat blade screwdriver to remove the inner stainless steel ring ( when removing the inner ring, do so carefully so not to damage the range hood, as the glass lens could ;... - Page 21 Canopy Installation and Operation Manual （9） Abnormity and Solution Fault Cause Solution The leaf blocked Get rid of the blocking The capacitor damaged Replace capacitor Light on, but motor does not work The motor jammed bearing Replace motor damaged The internal with of motor off or Replace motor a bad smell from the motor Beside the above mentioned, check the following:...
