Summary of Contents for Euromaid INLEM3
- Page 1 User Manual Off Board Flat Canopy Rangehood INLCP92BG - HOOD INLEM3 / INLRCM3 - MOTOR...
-
Page 2: Table Of Contents
Content 1…………………………………..………………………………Safety instructions 2…………………………………..………………………………Installation 3…………………………………..………………………………Start using your Rangehood 4…………………………………..………………………………Troubleshooting 5…………………………………..………………………………Maintenance and cleaning 6…………………………………..………………………………Environment protection SAFETY INSTRUCTIONS This manual explains the proper installation and use of your Rangehood, please read itcarefully before using even if you are familiar with the product. The manual should be keptin a safe place for future reference. - Page 3 Things not to do: instructions and all measurements ● Do not try to use the Rangehood followed. without the grease filters or if the filters ●All installation work must be carried out are excessively greasy! by a competent person or qualified ●Do not install above a cooker with a electrician.
- Page 4 during operation. Be careful to avoid touching the heating elements. Children younger than 8 years old should stay away unless they are under permanent supervision. ●Rangehood is for domestic use only. ●There shall be adequate ventilation of the room when the Rangehood is used at the same time as appliances burning gas or other fuels.
- Page 5 IMPORTANT INFORMATION Points to consider for installation 1. Before installation, please ensure the area is clean to avoid suction of the remaining bits of debris and dust. 2. Please ensure that the fan motor is firmly secured to either a flat surface such as an MDF panel affixed across the ceiling rafters, or fixed to the ceiling rafters themselves.
- Page 6 INSTALLATION - ROOF CAVITY MOTOR VERSION Schematic diagram 1. Connect the Rangehood main body with the external cabinet by control wire, to achieve power on and off, and also speed switching. 2. The control wire is separated into 3 parts, the first two parts are fixed onto the main body and external cabinet, while the middle part is extension wire.
-
Page 7: Installation
MOUNTING OF THE V-FLAP If the Rangehood does not have an assembled V-flap 1, you should mount the half- parts to its body. The images only show an example of how to mount the V-flap, the outlet may be various according to different models and configuration. To mount the V-flap 1 you should: •... - Page 8 2. The Rangehood should be placed at a distance of 65~75cm above the cooking surface for best effect. 3. Install the hook on a suitable place once the installation height is fixed, and keep it in line. The fixed position of the inside chimney bracket is the place of chimney. See pic 2.
- Page 9 5. Fix the outside chimney bracket on the outside chimney by 2 pcs 4*8mm screws, and be sure that the inside chimney can be adjusted the height in it freely, put the chimneys onto the Rangehood. See pic 5. 6. Equip the chimneys, fix the outside chimney bracket with 2 pcs 4*40mm screws, and use 2 pcs 4*30mm screws to fix the hood body.
- Page 10 10. Screw 4 pcs 4*30mm screws to fix the external cabinet onto the ceiling. See pic 11 & 12. 11. Install the expansion pipe and fix it with cable tie. See pic 13. 12. Equip the expansion pipe to the outlet, and fix with cable tie. Lead one end of the expansion pipe which install on the external cabinet outlet to the outside.
- Page 11 Note: You need to loosen the connecting wire before repair, follow the steps as below: a. Rotate the lock catch of the connecting wire following the arrow direction. b. Pull out the connector. 13. Adjust the height of the inside chimney to the position of the inside chimney bracket and fix on it by 2 pcs ST4*8mm screws.
- Page 12 INSTALLATION - EXTERNAL WALL HUNG MOTOR VERSION Schematic diagram 1. Connect the Rangehood main body with the external cabinet by control wire, to achieve power on and off, and also speed switching. 2. The control wire is separated into 3 parts, the first two parts are fixed onto the main body and external cabinet, while the middle part is extension wire.
- Page 13 MOUNTING OF THE V-FLAP If the Rangehood does not have an assembled V-flap 1, you should mount the half- parts to its body. The images only show an example of how to mount the V-flap, the outlet may be various according to different models and configuration. To mount the V-flap 1 you should: •...
- Page 14 2. The Rangehood should be placed at a distance of 65~75cm above the cooking surface for best effect. 3. Install the hook on a suitable place once the installation height is fixed, and keep it in line. The fixed position of the inside chimney bracket is the place of chimney. See pic 2.
- Page 15 5. Fix the outside chimney bracket on the outside chimney by 2 pcs 4*8mm screws, and be sure that the inside chimney can be adjusted the height in it freely, put the chimneys onto the Rangehood. See pic 5. 6. Equip the chimneys, fix the outside chimney bracket with 2 pcs 4*40mm screws, and use 2 pcs 4*30mm screws to fix the hood body.
- Page 16 10. Install the expansion pipe onto the main body outlet and fix it with cable tie. Connect the motor extension wire both end with the external cabinet control wire and main body top control wire. The plastic base of the control wire should be plugged to the bottom, and make the bucket to tight status.
- Page 17 11. Adjust the height of the inside chimney to the position of the inside chimney bracket and fix on it by 2 pcs ST4*8mm screws. See pic 11. 12. Installation is finished. See Pic 12. HINTS FOR EXHAUST DUCT INSTALLATION The following rules must be strictly followed to obtain optimal air extraction: •...
-
Page 18: Start Using Your Rangehood
WARNING: For safety reason, please use only the same size of fixing or mounting screw which are recommended in this instruction manual. Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. Start Using Your Rangehood LED touch control 1. -
Page 19: Troubleshooting
TROUBLESHOOTING Fault Possible Cause Solution Fan switch turned off Select a fan switch position. Light on, but motor Fan switch failed Contact service centre. does not work Motor failed Contact service centre. House fuses blown Reset/Replace fuses. Light does not work, motor does Power cord loose or Refit cord to power outlet. - Page 20 CONTROL PANEL SURFACE The inlay control panel can be cleaned using warm soapy water. Ensure the cloth is clean and well wrung before cleaning. Use a dry soft cloth to remove any excess moisture left after cleaning. Important Using neutral detergents and avoid using harsh cleaning chemicals, strong household detergents or products containing abrasives, as this will affect the appliance appearance and potentially remove any printing of artwork on the control panel and will void manufactures’...
- Page 21 BULB REPLACEMENT Important : The bulb must be replaced by the manufacturer, its service agent or similarly qualified persons. Always switch off the electricity supply before carrying out any operations on the appliance. When handling bulb, make sure it is completely cooldown before any direct contact to hands.
-
Page 23: Environment Protection
ENVIRONMENTAL PROTECTION: This product is marked with the symbol on the selective sorting of waste electronic equipment. This means that this product must not be disposed of with household waste but must be supported by a system of selective collection in accordance with Directive 2012/19/EU. - Page 24 Distributed by: Glen Dimplex Australia Pty Ltd 1340 Ferntree Gully Road, Scoresby VIC 3179 Tel: 1800 444 357 Email: customercare@hapl.com.au Website: www.euromaid.com.au...
