- Page 1 User Manual CPT6S - 60cm Pyramid Canopy Stainless Steel CPT6MB - 60cm Pyramid Canopy Matte Black CPT9S - 90cm Pyramid Canopy Stainless Steel CPT9MB - 90cm Pyramid Canopy Matte Black www.euromaid.com.au...
-
Page 3: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS ........................4 Important..............................4 Warning ..............................4 Safety Precautions ............................ 5 Unpacking ..............................5 Caution! ..............................5 INSTALLATION ........................... 6 Specifications ............................6 Included in the Box ........................... 7 Electrical Connection..........................7 Recommended Clearances ........................8 Ducting Options ............................8 Rangehood Installation (Ducted Method) .................... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS This rangehood must only be installed in accordance with the instructions provided. Incorrect installation may cause harm to persons, damage property and void the product’s warranty. This rangehood complies the safety standard AS/ NZS60335.2.31 and AS/NZS 60335.1 Important •... -
Page 5: Safety Precautions
Safety Precautions • Take care when the Range Hood is operating simultaneously with an open fireplace or burner that depend on natural ventilation as the Range Hood removes air from the room, which a burner or fireplace may need for combustion. •... -
Page 6: Installation
INSTALLATION Specifications CPT6S / CPT6MB CPT9S / CPT9MB Product Width 600mm 900mm Product Depth 500mm 500mm Product Height 645 – 1025mm 645 – 1025mm Weight Extraction 700m 700m Lighting 1 x LED 2 x LED’s Filter Qty & Type 2 x Baffle... -
Page 7: Included In The Box
Included in the Box 1 x Wall Bracket 1 x Rangehood (Rangehood) 1 x Flue Extension 1 x Main Flue (Outer) Bracket 1 x Extension Flue (Inner) 1 x Stability Bracket 1 x User Manual (Main Flue) 1 x Packet of fasteners, wall plugs and safety screws Electrical Connection... -
Page 8: Recommended Clearances
Recommended Clearances Recommended Clearances Install the Range Hood in accordance with the manufacturer’s instructions. For optimum performance, we recommend that all Range Hood clearances be a 650-750mm minimum of 650mm to a maximum of 750mm between the top of the cooking surface to the underside of the Range Hood. -
Page 9: Rangehood Installation (Ducted Method)
Rangehood Installation (Ducted Method) Check the area where the range hood is to be fitted, to ensure that it is structurally sound and will support the weight of the appliance. Do not install direct onto plaster board using 'Wall mates' or other similar anchors. - Page 10 5. Hang the rangehood on the wall by tilting it on a slight angle and lifting it onto the bracket so that protruding hooks interlock with the mounting holes at the top of the rangehood Fig. 3 (refer 6. Slide the flue extension into the main flue and fix the stability bracket to the main flue (refer Fig.4).
-
Page 11: Rangehood Installation (Recirculating Method)
Rangehood Installation (Recirculating Method) Note: IA150BRSK Recirculation kit is required for the below steps Check the area where the range hood is to be fitted, to ensure that it is structurally sound and will support the weight of the appliance. Do not install direct onto plaster board using 'Wall mates' or other similar anchors. - Page 12 3. Hang the rangehood on the wall by tilting it on a slight angle and lifting it onto the bracket so that protruding hooks interlock with the mounting holes at the top of the rangehood (refer Fig. 3 4. Attach the flexible ducting included with the recirculation kit to the spigot of the rangehood and secure with a cable tie.
- Page 13 10. Plug in the rangehood to a pre-existing GPO. If a GPO is required, ensure one is installed by a qualified electrician and is placed within the dimensions of the flue, so it is hidden from view 11. Raise the deflector and connected ducting up towards the top of the flue extension and secure with 2 fixing screws on each side.
-
Page 14: Carbon Installation And Changeover (Recirculating Mode Only)
Carbon Filter Installation and Changeover (Recirculating Mode Only) Note: CF110 Carbon Filter set is required for the below steps. If the recirculating installation is utilised then carbon filters must be fitted to aid in the removal of grease, smoke and cooking odours from the air before it is recirculated into the room. The round carbon filters attach to each side of the motor. -
Page 15: Operation
OPERATION Controller Layout Decrease Increase Light Countdown Power Display Speed Speed On/Off Timer On/Off Operating the Rangehood NOTE: It is recommended to start the Range Hood prior to commencing to cook and leave the Range Hood in operation for 15 minutes after cooking is finished in order to eliminate cooking vapours and odours. -
Page 16: Maintenance & Cleaning
MAINTENANCE & CLEANING Cleaning the Rangehood To ensure the Range Hood continues to operate effectively, regular maintenance and cleaning is required. Before maintenance or cleaning is carried out, the cooker hood should be disconnected from the mains power supply. Ensure that the cooker hood is switched off at the wall socket and the plug removed. -
Page 17: Troubleshooting
Troubleshooting Fault Possible Cause Solution Motor has failed. Contact service agent. Lights on but motor is not Possible PCB issue. Contact service agent. working. Disconnect power and clear Fan is obstructed. and obtrusions. House fuses blown Reset/Replace fuses. Lights and motor not working. Refit mains power cable to Mains power cable is loose or power outlet. -
Page 18: Specifications
SPECIFICATIONS CPT6S / CPT6MB CPT9S / CPT9MB Duct Outlet Size 150mm Carbon Filter CF110 (Sold Separately) Recirculating Kit IA150BSRK (Sold Separately) Flue Extension IAPXMBE1 - 900mm Extension (Sold Separately) Voltage 220 - 240 V ～ /50Hz Light Power 1 x 1.5W 2 x 1.5W... -
Page 19: Manufacturer Guarantee
(Phone number 09 274 8265) Euromaid in respect of the product. 1. Euromaid Express Warranty Subject to the exclusions below, we warrant that the product will not have any electrical or mechanical breakdowns within: a. In the case of Euromaid... - Page 20 3. Consumer guarantees Our goods come with guarantees that cannot be excluded under the Australian / New Zealand Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
-
Page 21: Notes
NOTES ____________________________________________________________________________________________________ ____________________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________... - Page 22 ____________________________________________________________________________________________________ ____________________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________...
- Page 23 ____________________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________...
- Page 24 READ THE INSTRUCTION BOOKLET BEFORE INSTALLING AND USING THE APPLIANCE. The manufacturer will not be responsible for any damage to property or to persons caused by incorrect installation or improper use of the appliance. The manufacturer is not responsible for any inaccuracies, due to printing or transcription errors, contained in this manual.
