Page 1: Center Console
3070 Center Console OWNER’S MANUAL FISHING BOATS 3901 St. Lucie Blvd. Ft. Pierce, Florida 34946 3070 Center Console 921216 July 2004...
Page 2 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 3: Safety Information
IMPORTANT NOTE: Your boat uses internal combustion engines and flammable fuel. Every precaution has been taken by Pursuit Fishing Boats to reduce the risks associated with possible injury and damage from fire or explosion, but your own precaution and good maintenance procedures are neces- sary in order to enjoy safe operation of your boat.
Page 4 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 5: Boat Information
MODEL: SERIAL #: DEALER PURSUIT NAME: PHONE: DEALER/PHONE: REPRESENTATIVE: SALESMAN: ADDRESS: SERVICE MANAGER: ADDRESS: Pursuit Fishing Boats reserves the right to make changes and improvements in equipment, design and vendored equipment items, at any time without notification. 3070 Center Console...
Page 6 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 7: Certifications & Specifications
Intended Design Category: Ocean Inshore Offshore Sheltered Waters Weight and Maximum Capacities: Unladen Weight - Kilograms (Pounds) Maximum Load - Weight- Kilograms (Pounds) Number of People Maximum Rated Engine Horsepower - Kilowatts (Horsepower) Certifications: Certifications & Components Covered 3070 Center Console...
Page 8 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 9: Important Information
Pursuit is committed to the continuous improvement of our boats. As a result, some of the equipment described in this manual or pictured in the catalog may change or no longer be available. Pursuit reserves the right to change standard equipment, optional equipment and specifications without notice or obligation. If you have questions about the equipment on your Pursuit, please contact Pursuit Customer Relations.
Page 10 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 11: Owner's/Operator'sresponsibilities
U.S. Coast Guard regulations require certain equipment on each boat. The Coast Guard also sets minimum safety standards for vessels and associated equipment. To meet these standards some of the equipment must be Coast Guard approved. “Coast Guard Approved Equipment” has been determined to be in compliance with 3070 Center Console...
Page 12 Guard jurisdiction. These agencies may also require additional equipment that is not required by the Coast Guard. Your dealer or local boating authority can provide you with additional information for the equipment requirements for your boating area. 3070 Center Console...
Page 13: Table Of Contents
Steering System ................23 Trim Tabs ..................24 Control Systems Maintenance ............25 Chapter 3: Fuel System General .................... 27 Fuel System Management ............... 28 Fueling Instructions ................ 29 Oil Tanks ..................31 Fuel System Maintenance ............... 31 3070 Center Console...
Page 14 Bilge Drainage ................. 49 Fishbox .................... 50 Livewell Drains ................51 Rope Locker Drains ................. 51 Head Compartment Drains ............... 51 Drainage System Maintenance ............51 Chapter 8: Ventilation System Bilge Compartment Ventilation ............53 Maintenance ..................53 3070 Center Console...
Page 15 Collision ..................80 12.10 Grounding, Towing and Rendering Assistance ......81 12.11 Flooding or Capsizing ..............81 12.12 Transporting Your Boat ..............82 12.13 Trailering Your Boat ..............82 12.14 Man Overboard ................84 12.15 Trash Disposal ................84 3070 Center Console...
Page 16 Winterizing ..................95 14.3 Recommissioning ................98 Appendix A: Glossary of Terms ..................101 Appendix B: Maintenance Schedule and Log ..............109 Appendix C: Boating Accident Report ................115 Appendix D: Float Plan ....................117 Appendix E: Troubleshooting Guide ................119 Schematics .............. 3070 Center Console...
Page 17: Chapter 1: Propulsion System
PROPULSION SYSTEM 1.1 General The Pursuit 3070 Center Console is designed to be powered with twin 2-cycle or 4-cycle outboard motors. Each manufacturer of the various outboard motors provides an owner’s information manual with its product. It is important that you read the manual(s) very carefully and become familiar with the proper care and operation of the engine and drive system.
Page 18: Engine Lubrication
DO NOT PAINT THE OUTBOARD MOTORS WITH ANTIFOULING PAINTS DESIGNED FOR BOAT HULLS. MANY OF THESE PAINTS CAN CAUSE SEVERE DAMAGE TO THE EN- GINES. CONTACT YOUR PURSUIT DEALER OR ENGINE MANUFACTURER FOR INFOR- MATION ON THE PROPER PAINTING PROCEDURES.
Page 19: Propellers
The propellers convert the engine’s power into thrust. They come in a variety of styles, diameters and pitches. The one that will best suit the needs of your Pursuit will depend somewhat on your application and expected average load. Propeller sizes are identified by two numbers stamped on the prop in sequence. The 1st number in the sequence (example 14 x 21) is the diameter of the propeller, and the 2nd number is the pitch.
Page 20 The ignition switch and instrument wire should be sprayed periodically with a contact cleaner/ lubricant. The ignition switches and all instruments, controls, etc. should be protected from the weather when not in use. Excessive exposure can lead to gauge and ignition switch failures. 3070 Center Console...
Page 21: Chapter 2: Helm Control Systems
Refer to the engine or control manuals for specific information on the controls installed on your Pursuit. The helm on your Pursuit is designed for a binnacle style control with a single lever for each engine that operates as a gear shift and a throttle. General...
Page 22: Neutral Safety Switch
Every control system has a neutral safety switch incorporated into it. This device prohibits the engine from being started while the shift lever is in any position other than the neutral position. Control or cable adjustments may be required to correct this condition should it persist. See your Pursuit dealer for necessary control and cable adjustments.
Page 23: Engine Stop Switch
WE STRONGLY RECOMMEND THAT THE LANYARD BE ATTACHED TO THE DRIVER WHENEVER THE ENGINES ARE RUNNING. Your Pursuit is equipped with an engine stop switch and lanyard. When the lanyard is pulled it will engage the switch and shut off the engines. If the engines will not start, it could be because the lanyard is not properly inserted into the engine stop switch.
Page 24: Trim Tabs
Trim tabs are extremely sensitive at high speeds. Adjust for this and be prepared to slow down if difficulties arise. When running into a chop, a slight bow down attitude will improve the ride. Be careful not to over trim. Handling difficulties may result. 3070 Center Console...
Page 25: Control Systems Maintenance
Generally, periodic lubrication of all moving parts and connections with a light waterproof grease is in order. Control system adjustments may become necessary. If adjustments become necessary, see your Pursuit dealer. INSPECT AND MAINTAIN STEERING SYSTEM REGULARLY. DO NOT ATTEMPT CON- TROL ADJUSTMENTS UNLESS YOU ARE FAMILIAR WITH SERVICING CONTROL SYS- TEM PROCEDURES.
Page 26 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 27: Chapter 3: Fuel System
FUEL SYSTEM 3.1 General The fuel system used in Pursuit boats is designed to meet or exceed the requirements of the U.S. Coast Guard, the Boating Industry Association, and The American Boat and Yacht Council in effect at the time of manufacture.
Page 28: Fuel System Management
3.2 Fuel System Management The outboard fuel system on the Pursuit 3070 Center Console has two fuel tanks and four manual “ON/OFF” fuel valves that are labeled to indicate the engine the valve will supply. Refer to the Schematics section of this manual.
Page 29: Fueling Instructions
LINE. DO NOT USE A FUEL THAT CONTAINS HARSH ADDITIVES OR IS AN ALCOHOL BLEND. ANY DAMAGE DONE TO THE FUEL SYSTEM THAT IS THE RESULT OF USE OF AN ALCOHOL BLEND IS NOT COVERED BY THE PURSUIT WARRANTY. REFER TO THE ENGINE MANUFACTURER OWNER’S MANUAL REGARDING FUEL REQUIREMENTS FOR YOUR ENGINES.
Page 30 TO REDUCE THE RISK OF A FIRE AND/OR EXPLOSION, DO NOT START THE ENGINE(S) WHEN FUEL FUMES ARE PRESENT. FUEL FUMES ARE DANGEROUS AND HARMFUL TO YOUR HEALTH. MAKE SURE ALL GASOLINE ODORS ARE INVESTIGATED IMME- DIATELY. 3070 Center Console...
Page 31: Oil Tanks
3.4 Oil Tanks (2-Cycle Engines) The remote oil tanks are equipped with deck fills located in the splashwell area. Pursuit provides, adjacent to the oil fill, an oil tank indicator system to assist in preventing an overfill of the oil tank. A light on the oil tank will turn on when the selected tank is full.
Page 32 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 33: Chapter 4: Electrical System
ELECTRICAL SYSTEM 4.1 General Your Pursuit is equipped with a 12-volt DC electrical system and may be equipped with an optional AC system. The AC system draws current from shore power outlets at dockside. The DC system draws current from on- board batteries.
Page 34: Dc Distribution System
24-Hour Essential Circuits: Used for protection of circuits that are not switched off by battery master switches. Medium Duty Circuit Breaker: Used to protect high amperage circuits and panel feeds. Heavy Duty Circuit Breaker: Used to protect the windlass circuit. 3070 Center Console...
Page 35: 12-Volt Dc Panels
Depressing the bottom on the switch Upper Helm Switch Panel activates the anchor light. Spreader Lights Activates the flood lights located on the optional T-top. These lights provide additional lighting for the rear of the cockpit. 3070 Center Console...
Page 36 Accessory Switch This switch is supplied to protect additional equipment that may be installed. If no accessories are activated by this switch it remains wired in the panel in reserve. Horn Activates the boat horn. 3070 Center Console...
Page 37 Additional switch panels are located in various locations in the cockpit and helm areas of the boat. Most of these panels are equipped with one switch and one circuit breaker. The following are descriptions of additional panels that may be on your Pursuit and the accessories they control: Helm Seat The switches are located on the leaning post next to each seat.
Page 38: Ac Systems
All AC outlets are protected by ground fault interrupters to protect against electrical shock. A cord set is provided to supply power from the shore power outlet to the boat’s AC system. 3070 Center Console...
Page 39 DO NOT OPERATE THE AC ELECTRICAL SYSTEM FROM SHORE POWER WITH RE- VERSE POLARITY. REVERSE POLARITY WILL DAMAGE THE SYSTEM AND EXPOSE PASSENGERS TO ELECTROCUTION HAZARDS. THIS CONDITION COULD ALSO CAUSE A FIRE IN THE ELECTRICAL SYSTEM. 3070 Center Console...
Page 40 Indicates the voltage supplied to the panel. Battery Charger Supplies electrical current directly to the automatic battery charger which is accessed through the starboard access hatch in the storage compartment in the console. The battery charger automatically charges and 3070 Center Console...
Page 41: Electrical System Maintenance
WHEN REPLACING LIGHT BULBS IN MARINE LIGHT FIXTURES, ALWAYS USE A BULB WITH THE SAME RATING AS THE ORIGINAL. USING A DIFFERENT BULB COULD CAUSE THE FIXTURE TO OVERHEAT AND MELT OR SHORT CIRCUIT. 3070 Center Console...
Page 42 AND CLEANED AS REQUIRED. DO NOT ALLOW CORROSION TO BUILD ON CONNEC- TIONS. THE AC AND DC ELECTRICAL SYSTEMS ALWAYS SHOULD BE DISCONNECTED FROM THE POWER SOURCE BEFORE INSPECTING OR SERVICING THE SYSTEM. NEVER SER- VICE ANY COMPONENT OF AN ELECTRICAL SYSTEM WHILE IT IS ENERGIZED. 3070 Center Console...
Page 43: Chapter 5: Fresh Water System
WORKS ON DEMAND AND WILL NOT SHUT OFF AUTOMATICALLY WHEN THE TANK IS EMPTY. THIS CAN RESULT IN DAMAGE TO THE PUMP. ALWAYS TURN THE WA- TER PRESSURE BREAKER OFF WHEN THE FRESH WATER SYSTEM IS NOT IN USE. 3070 Center Console...
Page 44: Head Compartment Drainage Operation
THE FRESH WATER SYSTEM MUST BE PROPERLY WINTERIZED PRIOR TO WINTER LAY-UP. SEE THE SECTION ON WINTERIZING. THE FRESH WATER SYSTEM SWITCH SHOULD BE PLACED IN THE “OFF” POSITION WHENEVER LEAVING THE BOAT UNATTENDED OR WHEN THE FRESH WATER SYS- TEM IS NOT IN USE. 3070 Center Console...
Page 45: Chapter 6: Raw Water System
ALWAYS TURN THE RAW WATER PUMP SWITCH TO THE “OFF” POSITION WHEN LEAVING THE BOAT UNATTENDED. DO NOT RUN THE HIGH PRESSURE PUMP DRY FOR EXTENDED PERIODS AS DAMAGE TO THE PUMP WILL RESULT. Washdown Hose Connector 3070 Center Console...
Page 46: Livewell
Spray pumps and thru-hull valves with a protective oil periodically. • The fishboxes and livewells should be drained and cleaned after each use. • Operate all thru-hull valves at least once a month to keep them operating properly. 3070 Center Console...
Page 47 THE BATTERIES MUST BE PROPERLY CHARGED. OPERATING ANY PUMPS FROM A BATTERY WITH A LOW CHARGE MAY LEAD TO A PUMP FAILURE. THE RAW WATER SYSTEM MUST BE PROPERLY WINTERIZED PRIOR TO WINTER LAY- UP. SEE THE SECTION ON WINTERIZING. 3070 Center Console...
Page 48 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 49: Chapter 7: Drainage Systems
7.2 Cockpit Drains Your Pursuit has two scupper drains located in the rear of the cockpit. Water is channeled away from all hatches by a gutter or drain rails. The water then drains overboard through the scupper drains. Check the drain system frequently to ensure it is free flowing and that the hoses on the thru-hull fittings are secure and not leaking.
Page 50: Fishbox
The fishbox below the cockpit floor is drained overboard by a macerator pump-out system. The macerator is activated by a momentary switch located in a switch panel in the cockpit below the gunwale. The fishboxes should be flushed out and cleaned after each use. 3070 Center Console...
Page 51: Livewell Drains
You can also use a garden hose to flood the bilge until the water level is high enough to activate the pump. • Flush all gravity drains with fresh water to keep them clean and free flowing. 3070 Center Console...
Page 52 Operate the thru-hull valves once a month and service as required. ALL DRAINS AND PUMPS MUST BE PROPERLY WINTERIZED BEFORE WINTER LAY- NEVER USE HARSH CHEMICAL DRAIN CLEANERS IN MARINE DRAIN SYSTEMS. PERMANENT DAMAGE TO THE HOSES AND FITTINGS MAY RESULT. 3070 Center Console...
Page 53: Chapter 8: Ventilation System
8.1 Bilge Compartment Ventilation All 3070 Center Console models are equipped with ventilation for the bilge compartment. A flow of air into the bilge compartment is provided by four vents located on either side of the cockpit, under the gunwale boards.
Page 54 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 55: Deck
ALL FITTINGS MUST BE PERIODICALLY INSPECTED FOR LOOSE FIT OR WEAR AND DAMAGE. ANY PROBLEMS SHOULD BE CORRECTED IMMEDIATELY. PURSUIT BOATS ARE NOT EQUIPPED WITH HARDWARE DESIGNED FOR TOWING PUR- POSES. THE MOORING CLEATS ARE NOT TO BE USED FOR TOWING ANOTHER VES- SEL OR HAVING THIS BOAT TOWED.
Page 56: Hull
Hull Swim Platform Your Pursuit is equipped with an integral swim platform and engine mounting system located in the stern of the boat. There are inspection deck plates in the splashwell to provide access to the stern bilge and engine mounting bolts.
Page 57: Cockpit
There are two tackle lockers built into the rear of the leaning post. The tackle station doors can be locked to secure the tackle lockers when the boat is unattended. Leaning Post and Tackle Station 3070 Center Console...
Page 58 THE TRANSOM DOOR AND GATE OPEN MAY ALLOW PERSONS TO FALL OVERBOARD AND INTO BOAT PRO- PELLERS OR TO BE LOST IN OPEN WATER. PERIODICALLY INSPECT THE TRANSOM DOOR FITTINGS FOR WEAR, DAMAGE OR LOOSE FIT. ANY PROBLEMS SHOULD BE INSPECTED AND CORRECTED IMMEDIATELY. 3070 Center Console...
Page 59: T-Top
If you intend to add equipment or make modifications to the T-top, you should contact Pursuit Customer Relations to make sure the equipment you would like to add or the intended modification will not void the warranty on the T-top.
Page 60 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 61: Interior Equipment
The pump should not run more than once every three hours after the last flush for recharging the system. Please refer to the toilet manufacturer owner’s manual for more information on the operation of the marine head system. 3070 Center Console...
Page 62 See the manufacturer owner’s manual for additional operating and maintenance information. THE HEAD AND MACERATOR DISCHARGE SYSTEM MUST BE PROPERLY WINTERIZED BEFORE WINTER LAY-UP. SEE THE SECTION ON WINTERIZING. 3070 Center Console...
Page 63: Head Compartment Features
There is also access to the bilge below the bottom step in the head compartment. Hanging Locker A hanging locker is located on the forward bulkhead in the head compartment between the sink and the cabin door. 3070 Center Console...
Page 64: Video And Sound System
The stereo amplifier is located behind the galley bulkhead. The amplifier has controls to adjust the sound system response. Refer to the amplifier owner's manual. CD Changer (Optional) The CD changer is mounted on the forward face of the hanging locker . Refer to the CD changer owner's manual. 3070 Center Console...
Page 65: Safety Equipment
You should also read the book entitled "Sportfish, Cruisers, Yachts - Owner's Manual" included with this manual. Your Pursuit could be equipped with engine alarms and cabin monitoring equipment. These systems are designed to increase your boating safety by alerting you to potentially serious problems in the primary power systems, the engine compartment, and the cabin.
Page 66: Neutral Safety Switch
11.4 Engine Stop Switch Your Pursuit is equipped with a engine stop switch and lanyard. When the lanyard is pulled it will engage the switch and shut off the engines. WE STRONGLY RECOMMEND THAT THE LANYARD BE ATTACHED TO THE DRIVER AND THE STOP SWITCH WHENEVER THE ENGINES ARE RUNNING.
Page 67: Required Safety Equipment
Throwable devices must be immediately available for use. All Pursuit boats must be equipped with at least one Type I, II or III PFD for each person on board, plus one throwable device (Type IV).
Page 68 (fog, rain, haze, etc.) Navigation lights are intended to keep other vessels informed of your presence and course. Your Pursuit is equipped with the navigation lights required by the U.S. Coast Guard at the time of manufacture. It is up to you to make sure they are operational and turned on when required.
Page 69: Additional Safety Equipment
Portable Radio Flashlight and Batteries Mirror Searchlight Sunburn Lotion Tool Kit Ring Buoy Whistle or Horn Anchor Chart and Compass Boat Hook Spare Propellers Mooring Lines Food and Water Binoculars Sunglasses Marine Hardware Extra Clothing Spare Parts 3070 Center Console...
Page 70 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 71: Operation
OPERATION 12.1 General Before you start the engines on your Pursuit, you should have become familiar with the various component systems and their operation, and have performed a “Pre-Cruise System Check." A thorough understanding of the component systems and their operation is essential to the proper operation of the boat. This manual and the associated manufacturers’...
Page 72: Rules Of The Road
Both boats should reduce their speed and turn to the right so as to pass port side to port side, providing enough clearance for safe passage. The boats should sound the appropriate signals. 3070 Center Console...
Page 73: Pre-Cruise Check
Be sure all necessary safety equipment is on board and operative. This should include items like the running lights, spotlight, life saving devices, etc. Please refer to the Safety Equipment chapter for additional information on safety equipment. 3070 Center Console...
Page 74 Drain Plugs Engine Oil Propellers Fuel Filters Propeller Nuts Fuel Hose and Clamps • Make sure all fire extinguishers are in position and in good operating condition. BE SURE THE SHIFT CONTROL IS IN THE NEUTRAL POSITION. 3070 Center Console...
Page 75: Operating Your Boat
Alcohol reduces night vision, and the ability to distinguish red from green. YOU SHOULD ALWAYS STAY ALERT. THE USE OF DRUGS, ALCOHOL OR OTHER SUB- STANCES WHICH IMPAIR JUDGMENT POSES A SERIOUS THREAT TO YOU AND OTH- ERS. THE BOAT OPERATOR IS RESPONSIBLE FOR THE BEHAVIOR OF PASSENGERS. 3070 Center Console...
Page 76 AFTER OPERATION: • If operating in saltwater, wash the boat and all equipment with soap and water. Flush the engines using fresh water. Please refer to the engine owner's manual for instructions on flushing your outboard engines. 3070 Center Console...
Page 77: Fishing
The following is a list of safety precautions for tower operation: • Do not operate the boat from the tower in rough sea conditions. The boat’s motions are exaggerated in the tower and this motion may become excessive in rough seas. 3070 Center Console...
Page 78: Docking, Anchoring And Mooring
If you are new to boat handling, you should take lessons from an experienced pilot to learn how to maneuver your boat in tight quarters in less than ideal conditions. You should also practice away from the dock during windy conditions. 3070 Center Console...
Page 79 Approach the mooring heading into the wind or current. Shift to neutral when you have just enough headway to reach the buoy. Position a crew member on the bow to retrieve the mooring with a boat hook and secure the line. Keep the engines running until the line is secured. 3070 Center Console...
Page 80: Controls, Steering Or Propulsion System Failure
If your boat is involved in a collision with another boat, dock, piling or a sandbar, your first priority is to check your passengers for injuries and administer first aid if necessary. Once your passengers' situations are 3070 Center Console...
Page 81: Grounding, Towing And Rendering Assistance
U.S. Coast Guard or a commercial towing company, to safely accomplish the towing task. THE MOORING CLEATS ON PURSUIT BOATS ARE NOT DESIGNED OR INTENDED TO BE USED FOR TOWING OR LIFTING PURPOSES. THESE CLEATS ARE SPECIFICALLY DESIGNED AS MOORING CLEATS FOR SECURING THE BOAT TO A DOCK, PIER, ETC.
Page 82: Transporting Your Boat
It is much easier for the Coast Guard, aircraft, or other boats to spot, than people in the water. 12.12 Transporting Your Boat The Pursuit 3070 Center Console is a large boat and should only be trailered by professionals that have the knowledge and equipment to move large boats without causing damage. Please contact your dealer or the Pursuit Customer Relations Department if you are planning to transport your boat and have any questions in regard to the proper equipment and support for the hull.
Page 83 Too little weight on the hitch will cause the rig to fishtail and will make controlling the tow vehicle difficult. Contact your Pursuit dealer or the trailer manufacturer for the correct weight on the hitch for your trailer.
Page 84: Man Overboard
Responsible boaters store refuse in bags and disposed of it properly on shore. You should make sure your passengers are aware of the local waste laws and the trash management procedure on your boat. 3070 Center Console...
Page 85: Chapter 13: Routine Maintenance
PARING THE HULL FOR BOTTOM PAINT. SANDING OR SANDBLASTING AND THE NO TICE USE OF A COATING OTHER THAN STANDARD ANTIFOULING PAINT OR EPOXY BAR- RIER COATINGS ARE NOT RECOMMENDED AND WILL VOID THE FIVE YEAR HULL BLISTER WARRANTY. 3070 Center Console...
Page 86 If the fiberglass should become damaged and need repair, contact your dealer for an authorized repair person to make the repairs. DO NOT WAX NONSKID AREAS AS THIS COULD MAKE THEM SLIPPERY AND CONSE- QUENTLY INCREASE THE POSSIBILITY OF INJURY. 3070 Center Console...
Page 87 Once a month coat the entire frame with a metal protector made for anodized aluminum to protect against pitting and corrosion caused by the harsh effects of saltwater. The anodized aluminum used on your Pursuit was coated with a metal protector called Aluma Guard at the factory. Aluma Guard is a nonabrasive marine metal protector that protects anodized aluminum, stainless steel, brass, and chrome.
Page 88 Water or a jelly like substance in the fuel filters is an indication of possible phase separation from the use of alcohol blended fuels. Please contact your Pursuit dealer or engine manufacturer for additional information regarding fuels and additives. 3070 Center Console...
Page 89: Upholstery, Canvas And Enclosures
Vinyl curtains should be stored either rolled or flat, without folds or creases. Folding the curtains will make permanent creases that could cause the vinyl to crack. DO NOT USE ANY POLISH CONTAINING LEMON SCENTS OR LEMON. THE LEMON JUICE WILL ATTACK THE VINYL AND SHORTEN ITS LIFE. 3070 Center Console...
Page 90: Cabin Interior
A flow of air into the bilge compartment is provided by vents. Periodic inspection and cleaning of the ventilation ducts are necessary to ensure adequate air circulation. 3070 Center Console...
Page 91: Drainage System
Operate the thru-hull valves once a month and service as required. NEVER USE HARSH CHEMICAL DRAIN CLEANERS IN MARINE DRAIN SYSTEMS. PER- MANENT DAMAGE TO THE HOSES AND FITTINGS MAY RESULT. ALL DRAINS AND PUMPS MUST BE PROPERLY WINTERIZED BEFORE WINTER LAY- NOTICE 3070 Center Console...
Page 92 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 93: Chapter 14: Seasonal Maintenance
Your dealer or the engine manufacturer can provide additional information on fuel degradation and fuel stabilizers recommended for your engine. For more recommendations for your specific area, check with your local Pursuit dealer. • Drain water from the fresh water system.
Page 94 ERLY SUPPORT THE HULL. ALWAYS MAKE SURE THE BUNKS AND ROLLERS ARE ADJUSTED SO THEY ARE NOT PUTTING PRESSURE ON THE LIFTING STRAKES AND ARE PROVIDING ENOUGH SUPPORT FOR THE HULL. HULL DAMAGE RESULTING FROM IMPROPER CRADLE OR TRAILER SUPPORT IS NOT COVERED BY THE PURSUIT WARRANTY. 3070 Center Console...
Page 95: Winterizing
Be sure to open all hot and cold water faucets, including the fresh water spray head in the stern bait station sink and the water supply valve for the head. Make sure antifreeze has flowed through all of the fresh water drains. 3070 Center Console...
Page 96 Remove all electronics. Coat all wire connectors and bus bars in the helm compartment with a protecting oil. Clean the aluminum frame with soap and water and dry thoroughly. Apply an aluminum metal protector to the entire frame to reduce corrosion and pitting. 3070 Center Console...
Page 97 If the boat is to be stored indoors or outdoors, open all drawers, clothes lockers, cabinets, and doors a little. If possible, remove the upholstery, mattresses, clothing, and rugs. Then hang a commercially available mildew protector in the cabin. 3070 Center Console...
Page 98: Recommissioning
• Check and lubricate the steering system. • Clean and wash the boat. • Install all upholstery, cushions and canvas. 3070 Center Console...
Page 99 This ensures that the cooling pump is operating. • Carefully monitor the gauges and check for leakage and abnormal noises. • Operate the boat at slow speeds until the engine temperature stabilizes and all systems are operating normally. 3070 Center Console...
Page 100 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 101: Appendix A: Glossary Of Terms
Bow: The front end of a boat's hull. Bow Line: A line that leads forward from the bow of the boat. Bow Rail: Knee high rails of solid tubing to aid in preventing people from falling overboard. 3070 Center Console...
Page 102 Dry-dock: A dock that can be pumped dry during boat construction or repair. lectrical Ground: A connection between an electrical connector and the earth. Engine Beds: Sturdy structural members running fore and aft on which the inboard engines are mounted. 3070 Center Console...
Page 103 Hatch: An opening in the deck with a door or lid to allow for access down into a compartment of a boat. Head: A toilet on a boat. Heat Exchanger: Used to transfer the heat that is picked up by the closed cooling system to the raw cooling water. 3070 Center Console...
Page 104 Lunch hook: A small light weight anchor typically used instead of the working anchor. Normally used in calm waters with the boat attended. idships: The center of the boat. Marina: A protected facility primarily for recreational small craft. Marine Ways or Railways: Inclined planes at the water’s edge onto which boats are hauled. 3070 Center Console...
Page 105 Roll: A boat’s sideways rotational motion in rough water. Rope Locker: A locker, usually located in the bow of a boat, used for stowing the anchor line or chain. 3070 Center Console...
Page 106 Stuffing Box: Prevents water from entering at the point where the propeller shaft passes through the shaft log. Superstructure: Something built above the main deck level. Swamps: When a boat fills with water from over the side. 3070 Center Console...
Page 107 Windlass: A winch used to raise and lower the anchor. Windward: Toward the direction from which the wind is coming. acht Basin: A protected facility primarily for recreational small craft. Yaw: When a boat runs off her course to either side. 3070 Center Console...
Page 108 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 109: Appendix B: Maintenance Schedule And Log
& & & & i f l e t l l l i f n i t g l i & , s t & o i t & i r t & u l f 3070 Center Console...
Page 110: Maintenance Log
MAINTENANCE LOG Date Dealer Service/Repairs Hours 3070 Center Console...
Page 111 MAINTENANCE LOG Service/Repairs Date Hours Dealer 3070 Center Console...
Page 112 MAINTENANCE LOG Service/Repairs Date Hours Dealer 3070 Center Console...
Page 113 MAINTENANCE LOG Service/Repairs Date Dealer Hours 3070 Center Console...
Page 114 MAINTENANCE LOG Service/Repairs Date Dealer Hours 3070 Center Console...
Page 115: Appendix C: Boating Accident Report
[ ] Yes [ ] No Adjusted [ ] Yes [ ] No NAME AND ADDRESS OF OWNER OF DAMAGED Sized [ ] Yes [ ] No PROPERTY Include any comments of PFD’s under ACCIDENT DESCRIPTION on other side of form 3070 Center Console...
Page 116: Boating Accident Report
Causes based on (check one) Name of Reviewing Office Date Received [ ] This report [ ] Investigation and this report [ ] Investigation [ ] Could not be determined Primary Cause of Accident Secondary Cause of Accident Reviewed By 3070 Center Console...
Page 117: Appendix D: Float Plan
Appendix D: Float Plan Pursuit recommends filling out a float plan each time you use your boat for an offshore day trip or a long cruise. Leave this information with a responsible person ashore, like a close friend or relative that you know well.
Page 118 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 119: Appendix E: Troubleshooting Guide
• Propeller may be damaged & need repair. • The propeller or propeller shaft is bent. Repair or replace damaged components. • The running gear is fouled by marine growth or rope. Clean running gear. • The engine is not trimmed Properly. Trim engine. 3070 Center Console...
Page 120: Troubleshooting Guide
Inspect and replace the fuel filter. • The electronic engine control system on the engine is malfunctioning. Repair the engine control system. • The fuel injection system on the engine is malfunc- tioning . Repair the fuel injection system. 3070 Center Console...
Page 121: Accessory Problems
• The in-line fuse near the battery switch has blown. does not activate the pump. Replace the fuse. • The pump impeller is jammed by debris. Clean pump impeller housing. • The pump is defective. Replace pump. 3070 Center Console...
Page 122 THIS PAGE WAS LEFT BLANK INTENTIONALLY 3070 Center Console...
Page 123: Schematics
SCHEMATICS 12-Volt DC Wiring Schematic 3070 Center Console...
Page 124 3070 Center Console...
Page 125 3070 Center Console...
Page 126 3070 Center Console...
Page 127 3070 Center Console...
Page 128 3070 Center Console...
Page 129 3070 Center Console...
Page 130 Fuel Selector Valves 3070 Center Console...
Page 131 3070 Center Console...
Page 132 3070 Center Console...
Page 133 3070 Center Console...
Page 134 3070 Center Console...
Page 135 3070 Center Console...
Page 136 3070 Center Console...
Page 137 3070 Center Console...
Page 138 3070 Center Console...

PURSUIT 3070 Center Console Owner's Manual

Chapter 1: Propulsion System

Chapter 2: Helm Control Systems

Chapter 3: Fuel System

Chapter 4: Electrical System

Chapter 5: Fresh Water System

Chapter 6: Raw Water System

Chapter 7: Drainage Systems

Chapter 8: Ventilation System

Chapter 9 :Exterior Equipment

Chapter 10 Interior Equipment

Chapter 11 Safety Equipment

Chapter 12 Operation

Chapter 13: Routine Maintenance

Chapter 14: Seasonal Maintenance

Appendix A: Glossary of Terms

Appendix B: Maintenance Schedule and Log

Appendix C: Boating Accident Report

Appendix D: Float Plan

Appendix E: Troubleshooting Guide

Schematics

Quick Links

3070 Center Console

Troubleshooting

Need help?

Questions and answers

Related Manuals for PURSUIT 3070 Center Console

Summary of Contents for PURSUIT 3070 Center Console

Table of Contents
