- Page 1 DVI • 3000HD U S E R M A N U A L www.gefen.com...
- Page 3 ASKING FOR ASSISTANCE Technical Support: Telephone (818) 884-6294 (800) 545-6900 Fax (818) 884-3108 Technical Support Hours: 8:00 AM to 5:00 PM Monday through Friday. Write To: Gefen Inc. C/O Customer Service 6265 Variel Ave. Woodland Hills, CA 91367-9897 Notice Gefen Inc. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. The DVI 3000HD is a trademark of Gefen Inc. © 2007 Gefen Inc., All Rights Reserved...
-
Page 4: Table Of Contents
TABLE OF CONTENTS Introduction and Operation Notes Features How It Works DVI•3000HDS Panel Layout DVI•3000HDS Panel Function Descriptions DVI•3000HDR Panel Layout DVI•3000HDR Panel Functions Descriptions Terminology System Specifications Warranty... -
Page 5: Operation Notes
INTRODUCTION Thank you for purchasing the new ex•tend•it DVI•3000HD series by Gefen, Inc. The DVI•3000HD by Gefen allows users the benefits of extending a DVI display, USB, and RS232 up to 6.25 miles away. In a growing number of applications, broadcast sta- tions, production facilities and even military divisions need to sercurely remote control a computer. Remote controlling a computer over the internet can be slow and inaccurate; but with the DVI•3000HD, you have a physical connection to your CPU. It is as if you are locally connected to the computer. OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE DVI•3000HD SYSTEM... -
Page 6: Features
FEATURES Features • Up to 6.25 miles extension at 1280x1024 • Remote controls your computer over long distances • Increases productivity • Elimiates computer noise where you work • Supports VESA Standard resolutions and HDTV resolutions • Supports DDWG standard for DVI compliant monitors... -
Page 7: How It Works
HOW IT WORKS CONTENTS The DVI•3000HD system consists of: --- (1) DVI•3000HDS sender unit --- (1) DVI•3000HDR receiver unit --- (2) 12 VDC power supplies --- (2) DVI cable M-M (6FT) --- (1) USB cable (6FT) --- (1) User Manual HOW IT WORKS The DVI•3000HD sender unit sits next to your computer. The cables supplied with the DVI•3000HD connects your DVI source(s) and USB to the send unit. The DVI•3000HD receiver unit sits next to your DVI display and workstation - up to 6.25 miles away. The displays and USB plug into the back of the DVI•3000HD receiver unit. A two strand SC- SC Single mode fiber cable connect the DVI•3000HD-S and the DVI•3000HD-R units to each other. -
Page 8: Dvi•3000Hds Panel Layout
DVI•3000HDS PANEL LAYOUT... - Page 9 POWER LIGHT - Lights when power is supplied to the unit USB IN - USB Input from computer DVI IN - DVI Input connects to your computer RS-232 IN - RS-232 Serial port connects to your computer DVI STATUS LIGHT - Lights when DVI signal is present LINK STATUS LIGHT - Lights when link between sender and receiver is active DUPLEX SC OUT - SC connector connects to DVI-3000HDR RESET BUTTON - Resets DVI-3000HDS Unit POWER - 12 VDC external power supply...
-
Page 10: Dvi•3000Hdr Panel Layout
DVI•3000HDR PANEL LAYOUT... - Page 11 DVI•3000HDR PANEL FUNCTIONS POWER LIGHT - Lights when power is supplied to the unit USB Out - USB Output connects to USB devices DVI OUT - DVI output connects to the monitor RS-232 OUT - RS-232 output connects to your RS-232 device or serial port LINK STATUS LIGHT - Lights when link between sender and receiver is active DUPLEX SC - SC connector connects to DVI-3000HDS RESET BUTTON - Resets DVI-3000HDR Unit POWER - 12 VDC external power supply...
-
Page 12: Terminology
TERMINOLOGY Short form for Display Data Channel. It is a VESA standard for communication between a monitor and a video adapter. Using DDC, a monitor can inform the video card about its properties, such as maximum resolution and color depth. The video card can then use this information to ensure that the user is presented with valid options for configuring the display DDWG Digital Display Working Group DDWG are the creators of the DVI specification. Digital Visual Interface. Connection standard developed by Intel for connecting computers to digital monitors such as flat panels and DLP projectors. -
Page 13: Specifications
SPECIFICATIONS Video Amplifier Bandwidth ................1.20 Gbps Input Video Signal...................1.2 volts p-p Input DDC Signal..................5 volts p-p (TTL) Single Link Range ..................1280x 1024 DVI Connector................. DVI-D (19 pin) female USB Input..................USB type "B" connector USB Output................. two USB type "A" connectors Link Connector......................SC Power Supply......................12V DC Power Consumption per unit..............15 watts (max) Dimensions................8.4" W x 1.75" H x 4.4" D Shipping Weight......................7 lbs. -
Page 14: Warranty
WARRANTY Gefen Inc. warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen Inc. is notified within two (2) year from the date of shipment, Gefen Inc. will, at its option repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications. Equipment that fails under conditions other than those covered will be repaired at the current price of parts and labor in effect at the time of repair. Such repairs are warranted for ninety (90) days from the day of reshipment to the Buyer. - Page 16 6265 Variel Avenue Woodland Hills, CA 91367 1-800-545-6900 818-884-6294 fax: 818-884-3108 www.gefen.com gsinfo@gefen.com...
