1.4 Rear Panel

CONNECTOR / BUTTON
Reset Default
Power Indicator
Video Output
LAN
Power Connector
DESCRIPTION
This button is hidden in the pinhole. Press and hold the reset button until the
network camera rebooted. This will reset all parameters, including the IP address
to factory default settings.
When the camera is power-supplied, this indicator will be on as red.
Connect to the video input connector of your monitor with a video cable (i.e. a RCA
cable with the BNC connector, or a coaxial cable for video output.
* The video cable is optional.
Connect the camera to the network with the supplied RJ45 cable.
Connect the DC 12V adapter for power supply.
2
