Owner's Manual
Ironman 125e Elliptical
Customer Service
1.800.750.IRON
1.800.750.4766
4009 Distribution Drive
Suite 250
Garland, TX 75041
www.ironmanfitness.com
CAUTION! Read all precautions
and instructions in this manual
before using this equipment.
315-00123
Rev A 10/07
Model Name : 125E
Serial Number :
Write down for future reference
Serial Number Decal Location
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ironman Fitness Ironman Elliptical 125E
Summary of Contents for Ironman Fitness Ironman Elliptical 125E
- Page 1 Owner’s Manual Ironman 125e Elliptical Customer Service 1.800.750.IRON 1.800.750.4766 4009 Distribution Drive Suite 250 Garland, TX 75041 www.ironmanfitness.com CAUTION! Read all precautions and instructions in this manual before using this equipment. Model Name : 125E Serial Number : Write down for future reference 315-00123 Serial Number Decal Location Rev A 10/07...
-
Page 2: Table Of Contents
Table of Contents Important Safety Information Parts Identifier Assembly Console Instructions Monitoring Your Heart Rate Moving Instructions Warm-Up Exercises Parts List Exploded View Warranty Information... -
Page 3: Important Safety Information
3. The unit should only be used on a level surface and is intended for indoor use only. The unit should not be placed in a garage, patio, or near water and should never be used while you are wet. Ironman Fitness recommends a mat be placed under the unit to protect floor or carpet and for easier cleaning. -
Page 4: Before You Start
To avoid the risk of electrical shock, always keep the console dry. Do not spill liquids on the con- sole. Ironman Fitness recommends a sealed water bottle for beverages consumed while using the unit. Please review the following drawing below to familiarize yourself with the listed parts. -
Page 5: Assembly
Assembly INSTRUCTIONS FOR ASSEMBLY: Unpack the box in a clear area. Check to make sure all components are present and in good condition. Do not dispose of the packing material until the assembly is completed. Tools have been provided for you to use when assembling this product. Locate the hardware pack and identify the following parts required for assembly. - Page 6 Assembly Assembly Part Identifier...
- Page 7 Assembly FIGURE 1 Step 1: Attach the Front Stabilizer (54) onto Main Frame (1) with the carriage screws (35), cap nuts (33), and arc washers (34). FIGURE 2 Step 1: Attach the rear frame w/aluminum rails (2) to the main frame (1) and secure it with carriage bolts (35), arc washers (34) and cap nuts (33).
- Page 8 Assembly Figure 3 FIGURE 3 Step 1: Secure left pedal (5a) to left pedal tube (4a) with screws (47), nylock nuts (49) and washers (48). Then secure left pedal tube (4a) to unit by lin- ing up the pedal tube to the axle with screws (50), nylock nuts (49) and washer (48).
- Page 9 Assembly FIGURE 5 Figure 5 Step 1: Install the left sleeve (6a) to the axle on the upright tube (3) and secure with washer (46), nut (45), and nut cap (44). Connect the pulse wire (42) with the pulse wire (87). Connect pulse wire (88) to the second connector on the pulse wire (87).
- Page 10 Assembly Congratulations! You have completed assembly of your new 125E Elliptical...
-
Page 11: Console Overview
Console Overview CONSOLE BUTTONS ENTER/RESET: Used to enter edit mode for a setting when using target training. If held for over 3 seconds, will reset console, and change all of the settings back to 0. PULSE RECOVERY: Used to enter "Pulse Recovery" mode during workout. This will begin the fitness test. Fitness Test is described in more detail in the following pages. -
Page 12: General Information
Console Overview SPEED: Display current training speed from 0.0 to maximum 99.9 MPH. DISTANCE: Count up - No preset target, Distance will count up from 0.00 to maximum 99.90 with each Increment 0.1 MPH. Count down - If training with preset target, Distance will count down from preset to 0.00. - Page 13 Console Overview FITNESS TEST: (Pulse Recovery Feature) The fitness test compares your pulse rate before and after training. You will notice that your fitness will improve with regular exercise. Press the PULSE RECOVERY button immediately after your workout. Grasp the Pulse Grips. Timer will count down from 60 seconds.
-
Page 14: Monitoring Your Heart Rate
Monitoring Your Heart Rate Monitoring Your Heart Rate To obtain the greatest cardiovascular benefits from your exercise workout, it is important to work within your target heart rate zone. The American Heart Association (AHA) defines this tar- get as 60%-75% percent of your maximum heart rate. Your maximum heart rate may be roughly calculated by subtracting your age from 220. -
Page 15: Target Heart Rate Zone
Monitoring Your Heart Rate TARGET HEART RATE ZONE 100% Serious athletic training range Cardiovascular conditioning range Fat burning range... -
Page 16: Moving Instructions
Moving Instructions CAUTION! TO REDUCE THE POSSIBILITY OF INJURY WHILE LIFTING, BEND YOUR LEGS AND KEEP YOUR BACK STRAIGHT. AS YOU LEAN THE UNIT, LIFT USING YOUR LEGS, NOT YOUR BACK. First, kneel down and grasp the rear support tube with both hands as shown in Figure 1. Next, with a firm grasp on rear support tube stand up bringing the rear of the bike up in the air and tilt the unit until it rolls freely on the transport wheels. -
Page 17: Warm-Up Exercises
Warm Up Exercises EXERCISE GUIDELINES WARNING! Before beginning this or any exercise program, you should consult your physician. This is especially important for individuals over the age of 35 or individuals with pre-existing health problems. Flexibility is a key to fitness. Stretch all major muscle groups at least two to three times per week after a 5 to 10 minute warmup. -
Page 18: Warm Up Exercises
Warm Up Exercises WARNING! Before beginning this or any exercise program, you should consult your physician. This is especially important for individuals over the age of 35 or individuals with pre-existing health problems. Wrist Extensor Extend your right arm in front of you with your palm up and your elbow straight. - Page 19 Warm Up Exercises WARNING! Before beginning this or any exercise program, you should consult your physician. This is especially important for individuals over the age of 35 or individuals with pre-existing health problems. Calf Stretch Face a solid structure such as a wall with your left foot ahead of your right, toes straight ahead.
-
Page 20: Exploded View
Exploded View... -
Page 21: Parts List
Parts List Ref # Parts # Description 323-00529 FRAME, REAR HT440EL/125E 302-01462 BOLT PACK, HT440EL/125E 323-00531 TUBE, PEDAL LEFT 27X40X1.5X950 HT440EL/125E 323-00532 TUBE, PEDAL RIGHT 27X40X1.5X950 HT440EL/125E 306-00794 PEDAL, LEFT HT440EL/125E 306-00795 PEDAL, RIGHT HT440EL/125E 323-00533 HANDLEBAR, LOWER LEFT HT440EL/125E 323-00534 HANDLEBAR, LOWER RIGHT HT440EL/125E 323-00535... -
Page 22: Warranty Information
Warranty Information PLEASE READ THESE WARRANTY TERMS AND CONDITIONS FULLY AND CAREFULLY BEFORE USING YOUR IRONMAN FITNESS EQUIPMENT. BY USING THE EQUIPMENT, YOU ARE CONSENTING TO BE BOUND BY THE FOLLOWING TERMS AND CONDITIONS. Frame: Lifetime Electronics and *Parts: 1 yr... - Page 23 Notes...
- Page 24 Customer Service 1.800.750.IRON 1.800.750.4766 Ironman Fitness 4009 Distribution Drive Suite 250 Garland, TX 75041 www.ironmanfitness.com IRONMAN, IRONMAN TRIATHLON and M-DOT are registered trademarks of the World Triathlon Corporation. This product is licensed by the Ironman Triathlon.
