Battery Installation and Removal

Installing Battery in scooba
Rotate battery into its slot, making sure the yellow battery tabs fit inside the
guide holes. Listen for a click as the battery snaps into place.
Insert yellow tabs into guide holes
removing Battery from scooba
Grip the battery, making sure to push the release tab, then rotate up.
Battery
Release
Tab
Push release tab
10
iRobot Scooba Owner's Manual
Guide Hole
Yellow
Battery Tab
Rotate battery down until it clicks
Rotate battery up
