iRobot Roomba Combo Owner's Manual

iRobot Roomba Combo Owner's Manual

10 max robor+autowash dock
Hide thumbs Also See for Roomba Combo:

Advertisement

Quick Links

Download this manual
10 Max
robot
AutoWash dock
Owner's Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the Roomba Combo and is the answer not in the manual?

Questions and answers

Related Manuals for iRobot Roomba Combo

Summary of Contents for iRobot Roomba Combo

  • Page 1 10 Max robot AutoWash dock Owner's Guide...

  • Page 2: Important Safety Information

    Read operator’s manual General symbol for recycling Keep out of Risk of fire Class II equipment Rated power input, d.c. Separate Supply Unit reach of children Caution Class III equipment Rated power input, a.c. Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...
  • Page 3 • Do not allow your robot or dock to become wet. robot, otherwise known as beater bars. Using your robot on a carpet • Clean cliff sensors for buildup. For more information, visit global.irobot.com...

  • Page 4: Cleaning Solution

    • Full tank is heavy. To avoid risk of injury, take additional care when inserting or removing the tanks. Do not allow children to insert or remove the tank. Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...
  • Page 5 • Do not use non-rechargeable batteries. Use only the rechargeable battery supplied with the product. For replacement, purchase identical iRobot battery or contact iRobot Customer Care for alternative battery options. • Do not open, crush, heat above 80°C (176°F) or incinerate. Follow the •...

  • Page 6: Get Started

    Get started Download the iRobot Home App Position the dock Scan the QR code with the camera on your mobile device or find the iRobot Home App in your app store. Good Wi-Fi® Coverage • Follow step-by-step instructions to set up your robot.
  • Page 7 • Install the removable ramp by aligning with the dock. • Remove stickers from Pad Washing Filter. • Press down to snap into place. • Install Pad Washing Roller from left to right by aligning the roller peg into place. For more information, visit global.irobot.com...
  • Page 8 Only certain cleaning solutions can be safely used with your robot. A full list of compatible cleaning solutions can be found on http://answers.irobot.com/s/roomba-combo-cleanser or by visiting the app. Please do not use other cleaning solutions or bleach- based products. Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...
  • Page 9 Your robot comes with a partial charge, but we recommend that you charge the robot for 3 hours prior to starting the first cleaning job. If the light ring is swirling white, the robot is not ready and is still waking up. For more information, visit global.irobot.com...

  • Page 10: About Your Robot

    About your robot Top view Mopping pad plate IR pad sensor Wall follow sensor Filter Clean button Pad track Camera Pad attachments Edge-sweeping brush Pad shelf Tank cap Dust bin Water tank Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...

  • Page 11: Bottom View

    Bottom view Cliff sensors Brush caps Front caster wheel Multi-surface brushes Charging contacts Floor type sensor Nozzle Bin release button Brush frame release tab Floor tracking sensor Debris evacuation port Refill port For more information, visit global.irobot.com...

  • Page 12: Front View

    Dirty tank Forced air outlet Wheel switch Debris bag drawer Pull tab Wheel track Debris evacuation port Refill nozzle Charging contact Removable ramp Visual docking target LED indicators IR window Clean tank Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...

  • Page 13: Back View

    Pad Washing System view Back view Bottom view Pad washing roller Cord attachment Debris tube access panel Pad washing filter Cord wrap Pad washing basin Carrying handle Drainage port Cord management channel Liquid overflow basin For more information, visit global.irobot.com...

  • Page 14: Standby Mode

    Pulsing white at rear: fully charged and asleep robot in a cool, dry place. Dock Charging LED indicator On: Robot on dock charging Off: robot not on dock, robot not charging, or dock is asleep Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...

  • Page 15: Cleaning Pattern

    Once complete, it will resume the cleaning job where it left off. Flashing blue: Dirt Detect™ mode engaged Your robot is able to recognize and avoid objects. However, it is still recommended to remove excess obstacles before cleaning. For more information, visit global.irobot.com...
  • Page 16 After 90 minutes of inactivity off the dock, the robot will automatically end its cleaning job. If you are unsure if the robot is finished or paused, visit the iRobot Your robot is able to both vacuum and mop at the same time.
  • Page 17 If you start a cleaning job from off the dock, the robot will still NOTE: end its job on the dock. If it can’t find its dock, it will end wherever it started in your home. For more information, visit global.irobot.com...
  • Page 18 Place tanks back in the dock and close the door, making sure it is completely closed. Attach mopping pad to robot. Return the robot to the AutoWash dock and press the Clean button on your robot. Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...
  • Page 19 The drying process will last for a few hours. You may hear a low hum coming from the dock while the dryer is active. Visit the iRobot Home app to manually start or stop Pad Washing and Drying or to customize pad washing settings.
  • Page 20 If you place your robot on the dock by hand, it will not empty Open bin door to empty bin. automatically. In this case, use the iRobot Home App or hold the clean button down for 2-5 seconds. Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...
  • Page 21 To keep your robot at optimal performance, make sure you periodically perform the following care & maintenance. There are additional instructional videos in the iRobot Home App. If you notice the robot picking up less debris from your floor, empty the bin, clean the filter, and clean the brushes.
  • Page 22 Make sure bin is completely dry. Reinsert filter and place bin back in the robot. IMPORTANT: The bin is not dishwasher safe. Do not wash the filter. Remove the filter before washing the bin. Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...

  • Page 23: Charging Contacts

    Pull to remove the edge-sweeping brush. Remove any hair or debris, then reinstall the brush. CAMERA WINDOW PAD SHELF & IR PAD SENSOR IMPORTANT: Do not spray cleaning solution or water onto the sensors or sensor openings. For more information, visit global.irobot.com...
  • Page 24 A front wheel clogged with hair and debris could result in damage to your floor. If the wheel is not spinning freely after you have cleaned it, please contact Customer Care. Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...

  • Page 25: Hand Washing

    HAND WASHING Thoroughly wash the pad with warm water. MACHINE WASHING Wash using the warm cycle, then air dry. Do not put in dryer. Do not wash with delicates. For more information, visit global.irobot.com...
  • Page 26 Clean if visibly dirty *  Replacement frequency may vary. Parts should be replaced if visible wear appears. If you think you need a replacement part, please contact iRobot Customer Care for more information. Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...
  • Page 27 Reinstall the Debris Bag Drawer and close the door making sure it is completely closed. IMPORTANT: To achieve optimal Lift the latch on the tanks to open. performance with your robot and dock, clean and/or replace your robot’s filter as needed. For more information, visit global.irobot.com...
  • Page 28 Tanks are not dishwasher safe. Wash the filter and roller under warm water. Mild soap and a sponge may be used for stubborn debris. Pat dry before reinstalling. Reinstall the filter. Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...
  • Page 29 Inspect the components to make sure that they are clear of debris. Wipe with a clean, dry cloth. CHARGING CONTACTS VISUAL DOCKING TARGET IR WINDOW NOTE: To expose the charging contacts, press and hold the wheel switches. IMPORTANT: Do not spray cleaning solution or water onto the sensors or sensor openings. For more information, visit global.irobot.com...

  • Page 30: Troubleshooting Your Robot

    BATTERY SAFETY & SHIPPING the light ring indicator red. Press the clean button for details. Check the iRobot For best results, only use the iRobot Lithium Ion Battery that comes with your robot. Home App for further support. Red light ring...
  • Page 31 Your dock will tell you if something is wrong via the LED indicators on the top of Dirt Disposal LED indicator (continued) the dock. If the dock is not performing as expected, check the iRobot Home app Flashing red: clog in the dock evacuation path for errors.
  • Page 32 If the protector operates, the motor will stop running. If this happens, unplug the unit, allow to cool for 30 minutes, clear any obstructions from the evacuation port and evacuation tube, and plug the unit back in. Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...

  • Page 33: Regulatory Information

    • ISED Radiation Exposure Statement: This product complies with the Canadian Standard RSS-102 for mobile device RF exposure limits, set forth for an Changes or modifications not expressly approved by iRobot Corporation could uncontrolled environment and is safe for the intended operation as described void the user’s authority to operate the equipment.
  • Page 34 RCA-Y2 IFT: NEIRRV23-27863 Argentina Radio RCA-Y2 CONTAINS C-28835 iRobot Corporation, 8 Crosby Drive, Bedford, MA 01730 USA https://global.irobot.com For battery recycling go to call2recycle.org or call 1-800-822-8837. Roomba Combo® 10 Max + AutoWash dock Owner’s Guide...
  • Page 35 Av. Guadalupe No. 150 Col. Guadalupe Proletaria Deleg. Gustavo A. Madero, Ciudad de México, C.P. 07670 Tel: 01 800 5037 866 Correo: servicio.irobot@gmail.com Horario de Atención: lunes a viernes de 9:00 am a 18:00 pm ONLY INCLUDE THIS PAGE IN ESXL DOCUMENTS For more information, visit global.irobot.com...
  • Page 36 Roomba Combo are registered trademarks of iRobot Corporation. Dirt Detect is a trademark of the iRobot Corporation. Wi-Fi and the Wi-Fi logo are registered trademarks of Wi-Fi Alliance. Apple and App Store are trademarks of Apple Inc., registered in the U.S. and other countries.
  • Page 37 Don't return to store. Let us help. Download the iRobot Home app or visit global.irobot.com for product support or to iRobot USA Customer Care Hours contact your local support center. If you need further assitance in the US & Canada, Monday to Friday, 9AM —...
