Installation and Operation Instructions for Vented Gas
Log Set - DragonFire Hearth Kits
Models A18CFLRN/P, A24CFLRN/P, A30CFLRN/P
DECORATIVE GAS APPLIANCE FOR INSTALLATION IN SOLID FUEL BURNING FIREPLACES
IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT,
CAUSING PROPERTY DAMAGE, INJURY, OR LOSS OF LIFE.
DO NOT STORE GASOLINE OR OTHER FLAMMABLE VAPORS OR LIQUIDS NEAR THIS OR ANY
OTHER APPLIANCE.
•
SHUT OFF ALL GAS TO THE APPLIANCE.
•
OPEN WINDOWS; DO NOT TOUCH ANY ELECTRICAL SWITCHES. DO NOT USE ANY PHONE IN
YOUR BUILDING.
•
DO NOT TRY TO LIGHT ANY APPLIANCE; EXTINGUISH ANY OPEN FLAME
•
IMMEDIATELY PHONE YOUR GAS SUPPLIER FROM A NEIGHBOR'S PHONE. FOLLOW THE SUPPLI-
ER'S INSTRUCTIONS.
•
IF YOU CANNOT REACH THE GAS SUPPLIER, PHONE THE FIRE DEPARTMENT.
ATTENTION
INSTALLATION AND SERVICE MUST BE PER-
FORMED BY A QUALIFIED AGENCY, INDI-
VIDUAL, FIRM, CORPORATION, OR COMPANY,
EXPERIENCED IN THE INSTALLATION, REPAIR,
AND SERVICING OF THIS TYPE OF GAS APPLI-
ANCE. DO NOT MODIFY, ALTER OR TAMPER
WITH ANY PART OF THIS HEATER, CONTROL,
OR LOGS. INSTALLER, CHECK LOCAL CODES
BEFORE INSTALLING THIS LOG SET. IN SOME
AREAS OF THE COUNTRY GAS LOG SETS ARE
RESTRICTED.
Design Certified to ANSI Z21.60 and CGA 2.26 Standards
FOR YOUR SAFETY:
WHAT TO DO IF YOU SMELL GAS:
CFM Specialty Home Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
www.majesticproducts.com • www.vermontcastings.com
SAVE THIS MANUAL FOR FUTURE REFERENCE
W A R N I N G
INSTALLER PLEASE NOTE:
DO NOT BEGIN INSTALLATION OF THIS GAS
LOG SET UNTIL ALL INSTRUCTIONS HAVE BEEN
READ AND UNDERSTOOD. AFTER INSTALLA-
TION, LEAVE THESE INSTRUCTIONS WITH THE
OWNER.
READ THESE INSTRUCTIONS AND FOLLOW
THE WARNINGS. PLEASE RECORD YOUR
GAS LOG'S MODEL NUMBER FOR FUTURE
REFERENCE:
OWNER PLEASE NOTE:
C E RT I F I E D
20003903 4/05 Rev. 9
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vermont Castings A18CFLRN/P
Summary of Contents for Vermont Castings A18CFLRN/P
- Page 1 Installation and Operation Instructions for Vented Gas Log Set - DragonFire Hearth Kits Models A18CFLRN/P, A24CFLRN/P, A30CFLRN/P DECORATIVE GAS APPLIANCE FOR INSTALLATION IN SOLID FUEL BURNING FIREPLACES Design Certified to ANSI Z21.60 and CGA 2.26 Standards W A R N I N G IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, INJURY, OR LOSS OF LIFE.
-
Page 2: Technical Information
WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read these directions thoroughly before installation. For assistance or additional infor- mation, consult your gas log dealer, qualified installer, service agency or gas supplier. WARNING WARNING If not installed, operated, and maintained in Do not use this appliance or any part that has accordance with the manufacturer’s instruc-... -
Page 3: Fireplace Specifications
Before You Begin -- ATTENTION! A. The appliance should be inspected before use and at least annually by a professional service person. More frequent cleaning may be required due to excessive lint from carpeting, bedding material, etc. It is imperative that control compartments, burners and circulating air passageways of the appliance be kept clean. -
Page 4: Pre-Installation Checklist
Pre-Installation Check List Is the gas supply inlet pressure correct? NG: Min. 5.0” w.c./ Max. 10.5” w.c. LP: Min. 11.0” w.c.;Max. 14.0” w.c. Does the firebox meet the minimum size dimensions below? Is your fireplace plumbed with gas on the right side (facing) of the fireplace? If not, see page 10. -
Page 5: Tools Required
Tools Required 8” adjustable crescent wrench; Pipe thread sealant compound or teflon tape; 12” pipe wrench or channel lock pliers. Gas Plumbed on Left Hand Side of Fireplace NOTE: Your gas log set is assembled at the factory to be installed in a fireplace plumbed with the gas on the right side (facing). -
Page 6: Connection To Gas Supply
Damper Stop Installation: For Use with All Other Fireplaces The Damper Stop provided keeps your damper from acciden- Figure 3 tally closing during operation of your set. This Damper Stop must be installed onto your Damper at all times. NOTE: The damper clamp is designed to hold the damper plate open 3 inches. -
Page 7: Remote Installation
Figure 5b CFM158 Remote Installation CFM158 R-CFLR Gas Supply Connection Connect remote (GWSK or MRC 1, 2, 3) wires 4/3/01 sta to ON/OFF/RS switch. (Fig. 6) If the MRC (remote) is used, the receiver can be placed to the front right of the gas valve to ensure safe operation. -
Page 8: Grate And Log Placement
Grate and Log Placement 1) Place the Elevated Grate Steps onto the back Grate of the Grate and attach the Fettel to front of Grate Grate Clip Steps as shown in Figure 8. 2) Place the Grate over the Burner Pan so the front legs of the Grate are 1”... -
Page 9: For Your Safety Read Before Lighting
Leak Test Procedures Create a mixture of equal parts soap and water. Apply to all the joints of the pipe fittings from the gas supply pipe to the burner. Turn on the gas supply valve for no longer than 3-5 seconds. If bubbles appear in the soap solution applied to the joints, there is a leak. -
Page 10: Match Lighting
Match Lighting 1) Follow the “Lighting the Pilot” instructions steps 1 thru 4 above. 2) Push the control dial in all the way and hold. Immediately light the pilot with a match. Continue to hold the pilot for about one minute after the pilot is lit. Pilot should remain lit. If the pilot goes out, repeat Lighting the pilot steps 1 thru 4 above and this step 2. - Page 11 Troubleshooting Burner Flame is too High (8-12” Above Top Logs) or too Low: Incorrect gas supply, pressure, or burner orifice used: Make sure the gas pressure coming into the fireplace falls between the minimum and maximum pressures allowed with this gas set (refer to tables on Page 4).
- Page 12 3a,b 20a,b 26a,b 28a,b CFM Specialty Home Products reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. A18/24/30CFL 3903 CFL parts DragonFire with Remote Pilot 11/04 Ref. Description A18CFLR A24CFLR A30CFLR...
- Page 13 A18/24/30CFL DragonFire with Remote Pilot (continued) Ref. Description A18CFLR A24CFLR A30CFLR Front Right Log 20004602 20004605 20004605 Bag of Lava Rock 4310010 4310010 4310010 Bag of Silica Sand (Pan material for Natural Gas only) 4310006 4310006 4310006 Bag of Vermiculite (Large size) 4310007 4310007 4310007...
- Page 14 20003903...
- Page 15 A and B below with respect to its ARE HEREBY EXPRESSLY INCLUDED. IN NO EVENT Vermont Castings Decorative Gas Appliances (the “Gas Ap- SHALL ANY IMPLIED WARRANTY PRESCRIBED BY LAW pliance”), including CFM Specialty Home Products supplied...
- Page 16 CFM Specialty Home Products 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777 www.majesticproducts.com • www.vermontcastings.com...
